GE DS3800HAMC In Stock | New Surplus Mark IV Cooling Pack

Description

Product Core Brief

• Model: DS3800HAMC
• Brand: GE (General Electric)
• Series: Mark IV Speedtronic Turbine Control System
• Core Function: Provides mounting card for heat sink assemblies in the Mark IV Speedtronic system.
• Type: Heat Sink Mounting Card
• Key Specs: Heat sink mounting card; VME form factor; aluminum construction; black anodized finish.
• Condition: New Original (New Surplus) — not refurbished.

Key Technical Specifications

• Function: Heat sink mounting card
• Material: Aluminum (black anodized)
• Mounting: VME rack
• Weight: 0.2 kg
• Operating Temperature: –30 to +65 °C ambient

Quality Inspection Process (SOP Transparency)

This is what every DS3800HAMC goes through before it ships:

Incoming Verification: The OEM packing slip is matched against the shipping manifest. Visual inspection includes checking the GE holographic label (or classic Speedtronic logo), verifying the heat sink mounting card has no dents or damage, and examining the black anodized finish for any scratches or wear.

Live Functional Test: The heat sink mounting card is installed in a test rack with a known-good module and verified to fit correctly. Thermal performance is checked by running the module at full load and measuring the heat sink temperature—must be within spec.

Mechanical Inspection: The heat sink mounting card is inspected for proper fit and alignment. The mounting holes are checked for thread integrity.

Final QC & Packaging: The QC report lists the fit test, thermal performance, and visual inspection results. The heat sink mounting card goes into a new anti-static bag with a tamper-evident seal, then into a double-walled carton with foam inserts. A “QC Passed” label with the test date and technician’s ID goes on the outer box. All test data and photos are available on request.

Field Replacement Pitfalls

The DS3800HAMC is the heat sink mounting card. Here’s the field-tested list:

Thermal Paste Application
The HAMC requires thermal paste between the heat sink and the module. ❗ Apply thermal paste before installation.

Heat Sink Damage
The HAMC is made of aluminum and can be damaged if dropped. ❗ Handle the heat sink with care.

Airflow Obstruction
The HAMC relies on convection cooling. ❗ Ensure the heat sink has adequate airflow.

Mounting Screws
The HAMC is mounted with screws. ❗ Use the correct torque for the mounting screws.

Module Compatibility
The HAMC is designed for specific Mark IV modules. ❗ Verify the module compatibility before installation.

Get these five right and you’ll cut rework time by 90%.

New Original vs. Refurbished: Why It Matters

The DS3800HAMC is a legacy heat sink mounting card. Refurbishment risk is low.

New Original (New Surplus) means this unit came from GE’s production line, sealed in an ESD-safe bag. The heat sink mounting card is new and undamaged. The serial number traces to GE’s production database.

Refurbished risk: The heat sink mounting card may have been damaged or have old thermal paste residue. I saw a refurbished HAMC in a plant that had old thermal paste on it—the module overheated. The refurbished heat sink cost 80; the new surplus unit was 120. The module failure cost $10,000.

Real cost: A failed heat sink can cause a module to overheat and fail. The cost of a module failure is tens of thousands of dollars. A new surplus heat sink is cheap insurance.

What we provide: We include a photo of the OEM packing slip. The anti-static bag is sealed with a tamper-evident label. The QC test report lists the fit test and thermal performance. You get a 12-month warranty.

Pricing context: Our price sits 30-50% above refurbished alternatives but 20-40% below GE’s current factory list price.

Performance Benchmarks & Test Results

Measured during our QC test. Conditions: test rack with a Mark IV backplane simulator and a CXCIA CPU module, 24.0 VDC supply (Fluke 8845A), ambient 24 °C.

• Fit Test: Heat sink mounting card fit correctly on the module.
• Thermal Performance: Module temperature stabilized at 55 °C. Heat sink temperature stabilized at 45 °C. Within spec.
• Visual Inspection: No dents, scratches, or damage.
• MTBF (Published): GE’s datasheet listed 500,000 hours at 40 °C for the HAMC. Based on field data, expect 20-30 years of service under normal conditions.
