DS3800HL0A1EC | GE Mark V Turbine LVDT/RVDT Input Module

Description

Product Introduction

The DS3800HL0A1EC is the dedicated LVDT/RVDT input board for the Mark V—it processes position feedback signals from LVDT (Linear Variable Differential Transformer) and RVDT (Rotary Variable Differential Transformer) sensors used on turbine valves and actuators. This board provides the excitation voltage (typically 120V AC) for the sensors and conditions the return signals to provide accurate position feedback to the controller. The “1E” suffix indicates spring-cage terminals and the “1C” suffix indicates specific fusing configuration. The board’s position feedback accuracy is critical for valve position control in gas and steam turbines.

We’ve used the HL0A1EC in multiple turbine control applications where valve position feedback is required. The board’s LVDT excitation and signal conditioning provided accurate position feedback for the fuel control valves, enabling precise turbine speed and load control. The spring-cage terminals made field wiring easy, and the board’s performance was stable over a wide temperature range.

Key Technical Specifications

Compatible Replacement Models

Frequently Asked Questions (FAQ)

Q: What’s the difference between the HL0A and a standard analog input board?
A: The HL0A is a dedicated LVDT/RVDT input board that provides excitation voltage for the sensors and conditions the return signals. Standard analog input boards accept 4-20mA or 0-10V signals and do not provide sensor excitation. The HL0A is designed specifically for position feedback applications where the sensor requires an AC excitation signal.

Q: What type of LVDT sensors does the HL0A1EC support?
A: The HL0A1EC supports standard 120V AC-excited LVDT and RVDT sensors used in turbine control applications. The board provides the 120V AC excitation and conditions the secondary voltages to provide a position feedback signal. The board’s input impedance (10kΩ) is compatible with most industrial LVDT sensors.

Q: How does the HL0A1EC process the position feedback signal?
A: The HL0A1EC provides 120V AC excitation to the LVDT primary winding. The LVDT secondary windings produce voltage signals that vary with the core position. The board conditions these signals and converts them to a position feedback value that the Mark V controller uses for valve position control.

Q: What’s the accuracy of the position measurement on the HL0A1EC?
A: The HL0A1EC provides position measurement with an accuracy of ±0.1% of full scale. This is sufficient for most turbine valve position control applications. The board uses precision signal conditioning circuitry to ensure accurate position feedback.

Q: Does the HL0A1EC have conformal coating?
A: Not by default. The HL0A1EC suffix indicates spring-cage terminals and mixed fusing, not coating. If you need conformal coating for harsh environments, look for a suffix with a “G” (e.g., DS3800HL0A1GC). The standard HL0A1EC is suitable for indoor environments. If your plant has high humidity or corrosive conditions, consider a coated variant.

Q: What’s the backplane current draw of the HL0A1EC?
A: The HL0A1EC draws 1.2A from the 5V backplane rail. The Mark V power supply is rated at 6A on the 5V rail, so the HL0A1EC is within the limit. If your rack has multiple HL0A boards, check your total backplane current. We recommend keeping total backplane current below 5.5A for margin.

Q: Can I use the HL0A1EC with LVDT sensors from different manufacturers?
A: The HL0A1EC is designed for standard 120V AC-excited LVDT sensors. Most industrial LVDT sensors from major manufacturers (e.g., Schaevitz, Solartron) are compatible. However, always verify the sensor’s excitation requirements and output characteristics before installation. Consult the sensor data sheet and compare with the HL0A specifications.
