YOKOGAWA F3NC02-0N

Description

Product Description

The YOKOGAWA F3NC02-0N is a high-performance network communication module designed for integration into Yokogawa’s FA-M3 and PLC series. This module serves as a critical interface, enabling seamless and reliable data exchange between the host controller and various field devices or supervisory systems over a standard Ethernet network. The primary function of the YOKOGAWA F3NC02-0N is to facilitate open connectivity, supporting protocols such as Modbus/TCP, allowing for easy integration with SCADA, HMI, and other third-party control systems. Engineered for industrial durability, this module ensures stable communication in demanding environments, which is a hallmark of Yokogawa’s commitment to robust automation solutions. Implementing the YOKOGAWA F3NC02-0N effectively future-proofs control architectures by bridging legacy PLC systems with modern Ethernet-based industrial networks.

Product Parameters

• Product Series: FA-M3 / PLC Series Communication Module
• Interface Type: 10BASE-T/100BASE-TX Ethernet (RJ45)
• Supported Protocols: Modbus/TCP (Client/Server), FA-M3 Tool Port, FTP
• Number of Connections: Up to 32 simultaneous TCP connections
• Power Supply: 5VDC from the base unit (backplane)
• Operating Temperature: 0 to 55 °C
• Storage Temperature: -25 to 75 °C
• Relative Humidity: 5 to 95% (non-condensing)
• Vibration Resistance: Conforms to JIS C0040 standard
• Shock Resistance: Conforms to JIS C0041 standard
• Certifications: CE, UL, cULus

Advantages and Features

• Open Network Integration: The YOKOGAWA F3NC02-0N excels in providing open-standard Ethernet communication, breaking down proprietary barriers and simplifying connectivity with a wide array of software and hardware.
• High Reliability & Determinism: Designed for mission-critical applications, it offers stable and deterministic data transmission, minimizing packet loss and ensuring timely data exchange for precise control.
• Dual Protocol Support: It natively supports both the widely adopted Modbus/TCP for interoperability and the dedicated FA-M3 protocol for high-speed, reliable communication with programming and monitoring tools.
• Robust Industrial Design: Built to withstand typical industrial challenges like temperature fluctuations, vibration, and electrical noise, ensuring long-term operation without failure.
• Easy Configuration: Configuration is streamlined through dedicated software, allowing for quick setup of IP addresses, network parameters, and communication parameters without extensive programming overhead.

Application Cases in Application Fields

• Water/Wastewater Treatment: Used to connect FA-M3 PLCs controlling filter beds and chemical dosing stations to a central SCADA system for remote monitoring of flow rates, pH levels, and tank levels via Modbus/TCP.
• Pharmaceutical Manufacturing: Integrates batch process control systems (controlled by Yokogawa PLCs) with manufacturing execution systems (MES) for recipe management and data logging, ensuring compliance with regulatory standards.
• Automotive Production Lines: Facilitates communication between robotic cell controllers (as Modbus/TCP clients) and the main line PLC, enabling synchronized operation and real-time fault reporting.
• Building Management Systems (BMS): Acts as a gateway, allowing HVAC and lighting control panels based on FA-M3 PLCs to be integrated into a facility-wide IP network for centralized energy management.

Comparisons with Competing Products

Compared to standard third-party Ethernet adapters or basic communication modules from some competitors, the YOKOGAWA F3NC02-0N offers distinct advantages. Unlike generic modules, it is fully hardware- and software-optimized for the FA-M3 series, ensuring 100% compatibility and leveraging the PLC’s internal bus at optimal speeds. While some competitor modules may only support a single protocol, the F3NC02-0N’s dual-protocol architecture provides greater flexibility. Its rugged industrial specifications often exceed those of generic commercial-grade Ethernet devices, providing superior longevity in harsh plant environments. The deep integration with Yokogawa’s engineering tools also simplifies diagnostics and maintenance compared to using a separate, unintegrated gateway device.

Selection Suggestions and Precautions

• Selection Suggestions:
  1. Confirm that your host controller is a compatible Yokogawa FA-M3 or PLC series CPU unit.
  2. Verify that your network infrastructure (switches, cables) meets industrial Ethernet standards for reliable operation.
  3. Ensure the Modbus/TCP functionality matches your system architecture needs (determine if the PLC will act as a Server, Client, or both).
  4. Check for available slot space on the PLC base unit for module installation.
• Precautions:
  1. Network Security: When connecting the YOKOGAWA F3NC02-0N to an enterprise network, implement appropriate cybersecurity measures such as firewalls, network segmentation, and VLANs to protect the control system from unauthorized access.
  2. IP Address Planning: Carefully plan and assign static IP addresses to avoid network conflicts.
  3. Firmware Updates: Check for the latest firmware version from Yokogawa’s official support site to benefit from performance improvements and bug fixes.
  4. Environmental Limits: Do not install the module in environments that exceed its specified temperature, humidity, or vibration ratings, as this may void warranties and lead to premature failure.
  5. Always refer to the official YOKOGAWA F3NC02-0N manual for detailed wiring, configuration, and safety instructions.
