YOKOGAWA AVR10D-A22010

Description

YOKOGAWA AVR10D-A22010 is a single-phase voltage relay or monitoring module designed for precise overvoltage and undervoltage protection in industrial control panels and electrical distribution systems. This device from Yokogawa ensures the stability and safety of electrical equipment by continuously monitoring the supply voltage and disconnecting the load when the voltage exceeds or falls below preset thresholds. Detailed technical specifications can be found on the product page: YOKOGAWA AVR10D-A22010. The reliability of the YOKOGAWA AVR10D-A22010 is critical for preventing damage to sensitive machinery due to voltage sags, surges, or fluctuations.

Product Description

The YOKOGAWA AVR10D-A22010 is a dedicated voltage monitoring relay that provides a robust and accurate solution for protecting electrical installations. It operates by measuring the single-phase AC line voltage through its input terminals. The AVR10D-A22010 compares this measured value against user-configured upper and lower limits. If the voltage deviates from the acceptable range for a preset time delay, the relay changes the state of its output contacts. These contacts can be used to trigger alarms, activate breakers, or shut down equipment, thereby preventing operational issues or damage. The compact design and DIN-rail mounting make the YOKOGAWA AVR10D-A22010 easy to integrate into various panel layouts. Its primary role is to act as an intelligent safeguard, enhancing the resilience of any system where voltage quality is a concern.

Product Parameters

• Brand and Manufacturer: YOKOGAWA.
• Product Type: Single-Phase Voltage Monitoring Relay.
• Rated Input Voltage: Likely designed for a standard voltage such as 220V AC (as suggested by ‘A220’ in the model number). Specific range (e.g., 100-240V AC) should be verified.
• Monitoring Functions: Overvoltage protection and Undervoltage protection.
• Setting Ranges: Adjustable setpoints for both high and low voltage thresholds, typically via potentiometers or DIP switches on the device.
• Time Delays: Adjustable delays for trip and reset actions to prevent nuisance tripping from transient events.
• Output Contacts: Typically one or more changeover relay contacts (SPDT) with a specified rating (e.g., 5A, 250V AC).
• Power Supply: Often operates directly from the monitored voltage line, but separate auxiliary supply versions may exist.
• Indication: LED indicators for power, normal operation, and alarm/trip status.
• Mounting: Standard DIN-rail mount (e.g., TH35).
• Standards Compliance: Meets relevant industrial and safety standards (e.g., CE, UL).

Advantages and Features

The key advantage of the YOKOGAWA AVR10D-A22010 is its high measurement accuracy and reliability from a brand renowned for precision instrumentation. It offers excellent immunity to electrical noise, ensuring stable operation in harsh industrial environments. The device features simple, tool-free adjustment of setpoints and delays, making commissioning and maintenance straightforward. Its compact footprint saves valuable panel space. A significant feature is its ability to protect against both overvoltage conditions, which can stress insulation and components, and undervoltage conditions, which can cause motors to overheat and contactors to chatter. The robust design of the YOKOGAWA AVR10D-A22010 ensures a long service life and consistent performance, providing peace of mind for critical voltage-sensitive applications.

Application Cases in Various Fields

• Industrial Motor Control Panels: Protecting three-phase motors from damage caused by single-phasing or unbalanced voltage conditions that often manifest as undervoltage on one leg.
• HVAC and Building Management Systems: Safeguarding compressors, fans, and chiller systems from operating outside safe voltage parameters.
• Power Generation and Distribution: Monitoring generator output voltage or incoming utility supply at substations and switchgear.
• Process Automation: Protecting sensitive controllers, PLCs, and instrumentation racks from power quality issues that could disrupt continuous processes.
• Renewable Energy Systems: Monitoring grid-tie or off-grid inverter output voltage in solar or wind power installations.

Comparison with Competing Products

Compared to generic voltage monitors from other manufacturers (e.g., Omron, Schneider Electric, Siemens), the YOKOGAWA AVR10D-A22010 stands out due to Yokogawa’s heritage in high-precision measurement. While competitors offer functionally similar devices, the AVR10D-A22010 may provide superior accuracy, stability over temperature, and finer adjustment resolution. Some competitors might integrate additional functions like phase-sequence or asymmetry detection in three-phase variants, but for pure single-phase voltage monitoring, the YOKOGAWA product is a premium, focused solution. Its build quality and reliability are often considered top-tier, though it may come at a slightly higher price point than entry-level alternatives.

Selection Suggestions and Precautions

1. Verify Voltage Range: Confirm that the input voltage rating of the AVR10D-A22010 matches your system’s nominal voltage (e.g., 220V AC, 50/60Hz).
2. Define Setpoints Carefully: Determine the precise overvoltage and undervoltage thresholds for your protected equipment. Consult equipment manuals for allowable voltage tolerances.
3. Set Appropriate Time Delays: Configure the trip delays to be longer than typical short-duration transients (like motor starts) to avoid unnecessary shutdowns, but short enough to provide effective protection.
4. Check Output Contact Rating: Ensure the relay’s output contact capacity (in amps) is sufficient for the load you are switching (e.g., a coil of a larger contactor or an alarm circuit).
5. Correct Wiring: Follow the wiring diagram precisely. Ensure connections are tight and use appropriate wire gauges. Proper grounding is essential.
6. Purchase and Documentation: Source the YOKOGAWA AVR10D-A22010 from authorized distributors to guarantee authenticity and access support. Always refer to the official manual for installation and configuration.
