YASKAWA JAMSC-B2507AV

Description

1. Product Overview

2. Product Parameters

2.1 Core Input Specifications

• Number of Channels: 16 differential analog inputs
• Input Signal Types: 4–20 mA DC, 0–10 V DC, 1–5 V DC (configurable per channel)
• Resolution: 16-bit (for 4–20 mA/0–10 V inputs)
• Accuracy: ±0.1% of full scale (FS) at 25°C; ±0.2% FS over operating temperature range
• Sampling Rate: 10 ms per channel (scan time)
• Isolation: 2500 VAC between channels, 2500 VAC between inputs and backplane

2.2 Electrical Parameters

• Power Supply: 24 VDC ±10% (from PLC backplane)
• Power Consumption: ≤8 W (full channel load)
• Output Interface: Yaskawa JAMSC backplane bus (digital data to CPU)
• Overvoltage Protection: 30 V DC (input channels)
• Reverse Polarity Protection: Yes (power supply)

2.3 Environmental & Mechanical Parameters

• Operating Temperature: 0°C to +60°C
• Storage Temperature: -20°C to +70°C
• Relative Humidity: 5%–95% (non-condensing)
• Protection Rating: IP20 (panel-mounted)
• Dimensions: 100 mm × 120 mm × 60 mm (L×W×H)
• Mounting: DIN rail (35 mm) or panel mounting via screws

2.4 Certification & Compatibility

• Certifications: CE, UL 508, RoHS, FCC Class A
• Compatible Systems: Yaskawa JAMSC-100/200 PLC racks, MP2300/MP3300 motion controllers
• Software Compatibility: Yaskawa SigmaWin+, MotionWorks IEC

3. Advantages & Features

1. High-Resolution Signal Processing: YASKAWA JAMSC-B2507AV’s 16-bit resolution ensures precise conversion of analog sensor signals, enabling accurate monitoring and control of critical process parameters (e.g., ±0.01 mA precision for 4–20 mA inputs).
2. Multi-Signal Compatibility: Each channel of YASKAWA JAMSC-B2507AV can be independently configured for 4–20 mA, 0–10 V, or 1–5 V inputs, eliminating the need for multiple specialized modules and reducing system complexity.
3. Robust Noise Immunity: Built-in optical isolation and EMI filtering protect YASKAWA JAMSC-B2507AV from industrial electrical noise (e.g., from VFDs or motors), ensuring reliable signal acquisition in harsh environments.
4. Easy Configuration & Diagnostics: YASKAWA JAMSC-B2507AV supports online configuration via Yaskawa’s software tools, with built-in diagnostic features (e.g., open-circuit detection, overrange alerts) to simplify troubleshooting and reduce downtime.
5. Space-Saving Design: The compact DIN-rail mountable form factor of YASKAWA JAMSC-B2507AV maximizes panel space utilization, making it ideal for small to medium-sized control cabinets in industrial automation systems.

4. Application Fields & Cases

4.1 Application Fields

• Process Control: Chemical plants, water/wastewater treatment, food/beverage production, pharmaceutical manufacturing
• Manufacturing: Automotive assembly lines, packaging machinery, metalworking equipment, semiconductor fabrication
• Energy Management: Power plant monitoring, renewable energy systems (solar/wind), HVAC control
• Building Automation: Smart factory infrastructure, lighting control, elevator systems

4.2 Typical Cases

1. Chemical Reactor Control: A specialty chemical manufacturer integrated YASKAWA JAMSC-B2507AV into its reactor control system to monitor temperature (4–20 mA RTD inputs) and pressure (0–10 V transducer inputs). The module’s high accuracy enabled tight process control, reducing product variability by 15% and increasing yield by 8%.
2. Automotive Assembly Line Monitoring: An automotive OEM used YASKAWA JAMSC-B2507AV to process signals from torque sensors and position encoders on its robotic assembly lines. The module’s fast sampling rate (10 ms) ensured real-time feedback to the PLC, improving assembly precision and reducing defect rates by 20%.
3. Water Treatment Plant Automation: A municipal water treatment facility deployed YASKAWA JAMSC-B2507AV to monitor flow rates (4–20 mA), pH levels (1–5 V), and turbidity (0–10 V) across multiple treatment stages. The module’s diagnostic features detected a faulty pH sensor early, preventing a system shutdown and saving $50,000 in downtime costs.

5. Competitor Comparison

6. Selection Suggestions & Precautions

6.1 Selection Suggestions

1. Input Signal Requirements: YASKAWA JAMSC-B2507AV is ideal for mixed-signal applications (4–20 mA + 0–10 V); for 4–20 mA-only needs, select Yaskawa JAMSC-B2506AV (cost-optimized 16-channel module).
2. System Compatibility: Verify compatibility with Yaskawa JAMSC PLC racks or MP Series motion controllers before installation; use Yaskawa’s configuration software to ensure proper communication.
3. Environmental Conditions: Choose optional extended-temperature models (-20°C to +70°C) for outdoor or extreme-temperature installations (e.g., oil refineries, mining sites).

6.2 Precautions

1. Wiring Guidelines: Use shielded twisted-pair cables for analog inputs, with shielding grounded at the module end only to eliminate ground loops. Tighten terminal screws to 0.5 N·m to prevent signal loss.
2. Calibration Requirements: Calibrate YASKAWA JAMSC-B2507AV annually using a precision signal generator (e.g., Fluke 725) to maintain accuracy; recalibrate after major system upgrades or component replacements.
3. Noise Reduction: Install YASKAWA JAMSC-B2507AV at least 30 cm away from high-voltage equipment (e.g., contactors, transformers) or VFDs to minimize EMI interference.
4. Power Supply Protection: Use a 24 VDC power supply with surge protection (≥1 kV) to safeguard YASKAWA JAMSC-B2507AV from voltage spikes in industrial electrical systems.
