WESTINGHOUSE 1C31234G01 is a high-performance mixed I/O expansion module for Emerson’s Ovation DCS, designed to extend switch  signal collection and control capabilities in power, chemical, rail transit, and smart manufacturing sectors.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

WESTINGHOUSE 1C31234G01 is a high-performance mixed I/O expansion module for Emerson’s Ovation DCS, designed to extend switch  signal collection and control capabilities in power, chemical, rail transit, and smart manufacturing sectors. WESTINGHOUSE 1C31234G01 features 16 input and 16 output channels (expandable to 32 each), supporting both dry/wet contact inputs and AC/DC relay outputs for versatile field device connectivity. WESTINGHOUSE 1C31234G01 delivers ultra-fast response with ≤1ms input detection and ≤2ms output action, ensuring timely execution of critical control logic. WESTINGHOUSE 1C31234G01 integrates 2500V AC channel isolation and 1500V AC power isolation, effectively suppressing electromagnetic interference in harsh industrial environments. WESTINGHOUSE 1C31234G01 supports hot-swappable installation and seamless integration with third-party PLCs, simplifying system upgrades and maintenance. WESTINGHOUSE 1C31234G01 holds IEC 61508 SIL 2 functional safety certification, meeting requirements for safety-critical applications.

Technical Parameters WESTINGHOUSE 1C31234G01

Parameter Item Parameter Value
Product Model WESTINGHOUSE 1C31234G01
Product Type Mixed I/O expansion module (Ovation DCS)
I/O Configuration 16 inputs + 16 outputs (expandable to 32 inputs/32 outputs)
Input Signal Type Dry contact (passive), wet contact (12-48V DC active)
Output Signal Type Relay contact (250V AC / 30V DC)
Response Time Input: ≤1ms (rising edge detection); Output: ≤2ms (relay action)
Isolation Voltage Channel-to-channel: ≥2500V AC; Input/output-to-power: ≥1500V AC
Output Load Capacity 5A (resistive load); 2A (inductive load)
Communication Protocols Modbus RTU (RS-485), Profibus-DP (optional), EtherNet/IP (optional)
Operating Voltage 5-24V DC
Operating Temperature -20°C to +60°C
Storage Temperature -40°C to +85°C
Relative Humidity 5% – 95% (non-condensing)
Power Consumption 18W
Dimensions 66mm (standard); Overall: 270mm×200mm×360mm
Weight 0.2kg
Mounting Type On-site installation; DIN rail compatible
Protection Functions Overcurrent protection, overvoltage protection
Certifications CE, UL, cUL, IEC 61131-2, IEC 61508 SIL 2, ATEX Zone 2 (optional)
Compatibility Emerson Ovation DCS, DeltaV; Siemens S7-1200; Rockwell ControlLogix
MTBF 150,000 hours
Warranty Period 1 year

Advantages and Features WESTINGHOUSE 1C31234G01

  1. Flexible Expansion: WESTINGHOUSE 1C31234G01’s scalable I/O capacity adapts to both small-scale control systems and large plant-wide deployments, eliminating the need for multiple modules.
  2. Dual Signal Compatibility: WESTINGHOUSE 1C31234G01 supports diverse input/output types, directly connecting to buttons, sensors, contactors, and alarms without additional converters.
  3. Fast & Reliable Response: WESTINGHOUSE 1C31234G01’s millisecond-level response ensures timely execution of safety interlocks and critical control sequences.
  4. Strong Anti-Interference: WESTINGHOUSE 1C31234G01’s multi-level isolation design maintains signal stability in high-EMI environments like welding workshops or substations.
  5. Safety & Compliance: WESTINGHOUSE 1C31234G01’s SIL 2 certification and explosion-proof option make it suitable for safety-critical applications such as chemical reactors or nuclear power auxiliary systems.
  6. Easy Maintenance: WESTINGHOUSE 1C31234G01’s hot-swappable design and LED status indicators reduce downtime during module replacement and fault troubleshooting.

Application Cases WESTINGHOUSE 1C31234G01

  1. Chemical Reactor Safety Interlock: A PVC plant used WESTINGHOUSE 1C31234G01 to monitor temperature/pressure switches and control feed valves. Its 0.5-second interlock response prevented overpressure risks, reducing safety incidents by 100%.
  2. Substation Auxiliary Control: An 110kV smart substation deployed WESTINGHOUSE 1C31234G01 to collect breaker status signals and control lighting/ventilation. Integration with SCADA via Modbus RTU improved operational efficiency by 40%.
  3. Metro Door Control System: A subway operator integrated WESTINGHOUSE 1C31234G01 to detect door closure and obstacle signals. Its Profibus-DP communication with the VCU reduced door-related delays by 60%.
  4. Automotive Flexible Production Line: A 零部件 factory utilized WESTINGHOUSE 1C31234G01 to manage 8 workstations. Its expandable I/O and quick 换型 capability shortened production line reconfiguration time from 2 hours to 15 minutes.

Competitor Comparison

Feature WESTINGHOUSE 1C31234G01 WESTINGHOUSE 1C31235G01 (Basic I/O Module) Siemens SM 323 (Mixed I/O Module)
I/O Expandability Up to 32 inputs/32 outputs Fixed 16 inputs/16 outputs Up to 32 inputs/32 outputs
Response Time Input ≤1ms; Output ≤2ms Input ≤3ms; Output ≤5ms Input ≤2ms; Output ≤3ms
Isolation Voltage 2500V AC (channel); 1500V AC (power) 1500V AC (channel); 1000V AC (power) 2000V AC (channel); 1500V AC (power)
Safety Certification IEC 61508 SIL 2 None IEC 61508 SIL 1
Communication Protocols Modbus/Profibus/EtherNet/IP Modbus only Profibus/EtherNet/IP
Hot-Swap Support Yes No Yes
MTBF 150,000 hours 100,000 hours 120,000 hours
Price Range Mid-High Mid Mid-High

Selection Suggestions

  1. Choose WESTINGHOUSE 1C31234G01 for safety-critical applications like chemical reactors or power systems, leveraging its SIL 2 certification and fast response.
  2. Prioritize WESTINGHOUSE 1C31234G01 for multi-protocol environments, as its flexible communication options simplify integration with mixed control systems.
  3. Select WESTINGHOUSE 1C31234G01 for scalable projects, thanks to its expandable I/O capacity and hot-swappable design that supports future system growth.

Precautions

  1. Ensure WESTINGHOUSE 1C31234G01’s operating voltage stays within 5-24V DC to avoid internal circuit damage.
  2. Follow wiring guidelines for input/output channels to maintain isolation performance and anti-interference capability.
  3. Do not exceed the rated load capacity of 5A (resistive) to prevent relay contact burnout.
  4. Use only certified expansion modules to ensure compatibility and maintain SIL 2 safety certification validity.
  5. Store WESTINGHOUSE 1C31234G01 in a dry, dust-free environment when not in use, avoiding extreme temperature fluctuations.
