产品名称
VMIC+ASSY 11993R2 & ASSY 11994R13 High-Speed Analog I/O Expansion Kit
产品说明
VMIC+ASSY 11993R2 is the front-end signal-conditioning and conversion board, while ASSY 11994R13 is the companion backplane adapter and terminal block assembly. Together, the VMIC+ASSY 11993R2 and ASSY 11994R13 form a complete high-speed analog input/output subsystem that plugs directly into any VME64x or PMC-compatible rack. Designed under the legacy VMIC brand (now part of Emerson’s PACSystems portfolio), VMIC+ASSY 11993R2 delivers 32 differential analog inputs and 8 analog outputs with 250 kS/s per-channel throughput, and ASSY 11994R13 provides hot-swappable spring-cage terminals, LED diagnostics, and 500 Vrms channel-to-ground isolation. Both ASSY 11993R2 and ASSY 11994R13 are engineered for real-time control loops that demand micro-second-level determinism and superior noise immunity.
产品参数
| Parameter | VMIC+ASSY 11993R2 | ASSY 11994R13 |
|---|---|---|
| Analog Inputs | 32 differential, ±10 V, ±20 mA, 16-bit, 250 kS/s | — |
| Analog Outputs | 8 single-ended, ±10 V or 4–20 mA, 16-bit, 100 kS/s | — |
| Digital I/O | 16 TTL/24 V configurable lines | 16 status LEDs, 32 spring-cage terminals |
| Isolation | 250 Vrms channel-to-channel; 500 Vrms channel-to-ground | Same |
| Bus Interface | 64-bit PMC, VME64x P0/P2 connector | Rear I/O via 68-pin SCSI-3 & D-sub |
| Calibration | Auto-zero & gain drift correction | — |
| Power Consumption | 6.5 W typical, 8 W max | <1 W |
| Operating Temp | –40 °C … +85 °C | –40 °C … +85 °C |
| Shock & Vibration | 5 g @ 10–500 Hz, 30 g shock | Same |
| Certifications | CE, UL Listed, ATEX Zone 2, RoHS | CE, UL Listed, RoHS |
优势和特点
• Simultaneous sampling across all 32 inputs with <50 ns skew, enabled by the dedicated sample-and-hold circuitry on VMIC+ASSY 11993R2.
• Hot-swappable terminal blocks on ASSY 11994R13 allow module replacement without powering down the VME rack, cutting maintenance downtime.
• 5 ppm/°C precision voltage reference and 24-bit calibration engine keep total accuracy within ±0.01 % FSR over the –40 °C to +85 °C range.
• Redundant power rails and over-voltage protection up to 60 V on analog inputs make VMIC+ASSY 11993R2 extremely robust in harsh environments.
• Firmware-upgradeable FPGA on ASSY 11993R2 supports custom filtering and real-time FFT processing directly on the board, offloading the PLC CPU.
• Hot-swappable terminal blocks on ASSY 11994R13 allow module replacement without powering down the VME rack, cutting maintenance downtime.
• 5 ppm/°C precision voltage reference and 24-bit calibration engine keep total accuracy within ±0.01 % FSR over the –40 °C to +85 °C range.
• Redundant power rails and over-voltage protection up to 60 V on analog inputs make VMIC+ASSY 11993R2 extremely robust in harsh environments.
• Firmware-upgradeable FPGA on ASSY 11993R2 supports custom filtering and real-time FFT processing directly on the board, offloading the PLC CPU.
应用领域应用案例
• Power-generation turbine control: A North American utility retrofitted legacy GE Mark V turbines with VMIC+ASSY 11993R2 and ASSY 11994R13 to add 32 channels of dynamic pressure monitoring at 250 kS/s, improving combustion diagnostics and reducing NOx emissions by 8 %.
• Semiconductor wafer fab: A 300 mm lithography tool uses the pair to control 8 piezo-actuated stages at 16-bit resolution, achieving <10 nm positional repeatability.
• Aerospace hardware-in-the-loop (HIL): An European test bench integrates VMIC+ASSY 11993R2 for real-time flight surface actuator simulation, leveraging the deterministic PMC bus latency of <3 µs.
• Semiconductor wafer fab: A 300 mm lithography tool uses the pair to control 8 piezo-actuated stages at 16-bit resolution, achieving <10 nm positional repeatability.
• Aerospace hardware-in-the-loop (HIL): An European test bench integrates VMIC+ASSY 11993R2 for real-time flight surface actuator simulation, leveraging the deterministic PMC bus latency of <3 µs.
竞品对比
| Feature | VMIC+ASSY 11993R2 / ASSY 11994R13 | NI PXIe-4339 / TB-4339 | Acromag 3515/3516-T |
|---|---|---|---|
| Max Sample Rate | 250 kS/s per channel | 102.4 kS/s aggregate | 100 kS/s aggregate |
| Isolation | 500 Vrms | 300 Vrms | 250 Vrms |
| Hot-Swap Terminals | Yes | No | No |
| Real-time FPGA | User-programmable | Fixed DSP | None |
| Operating Temp | –40 °C … +85 °C | 0 °C … +55 °C | –40 °C … +70 °C |
| Price Position | Mid-range | Premium | Budget |
选型建议
Choose VMIC+ASSY 11993R2 and ASSY 11994R13 when your application demands:
-
Simultaneous high-speed sampling (≥200 kS/s) with deterministic latency.
-
Wide temperature operation and ATEX Zone 2 certification.
-
On-board FPGA for custom signal processing without burdening the PLC.
If only slow-speed monitoring is required, Acromag 3515 may be cost-effective; if software-centric development tools outweigh ruggedization, NI PXIe-4339 is viable.
注意事项
• Ensure the VME rack provides 5 V/32 A and 3.3 V/8 A rails to meet the combined 7–9 W draw of VMIC+ASSY 11993R2 and ASSY 11994R13.
• Use shielded twisted-pair for analog inputs longer than 3 m to maintain 90 dB CMRR.
• Firmware revisions prior to Rev D require a jumper change on ASSY 11994R13 for 24 V digital compatibility—check the factory label.
• Periodic calibration is recommended every 24 months or 8,000 operating hours to retain 16-bit accuracy.
• Use shielded twisted-pair for analog inputs longer than 3 m to maintain 90 dB CMRR.
• Firmware revisions prior to Rev D require a jumper change on ASSY 11994R13 for 24 V digital compatibility—check the factory label.
• Periodic calibration is recommended every 24 months or 8,000 operating hours to retain 16-bit accuracy.
