REXROTH R161924051

Description

1. Product Overview

2. Product Parameters

2.1 Core Mechanical Specifications

• Rail Compatibility: Rexroth R1605 series linear guide rails (profile size 45 mm)
• Load Capacity: Dynamic radial load (C): 190 kN; Static radial load (C0): 290 kN
• Dynamic axial load (Ca): 54 kN; Static axial load (C0a): 85 kN
• Friction Coefficient: ≤0.0015 (lubricated)
• Maximum Speed: 5 m/s (continuous); 8 m/s (intermittent)
• Maximum Acceleration: 100 m/s²
• Operating Temperature Range: -20°C to +80°C (standard); -40°C to +120°C (high-temperature option)

2.2 Design & Material Specifications

• Bearing Type: Precision ball bearings (90° contact angle)
• Material: Carriage body (high-strength cast iron), balls (chrome steel), raceways (hardened steel, 60-64 HRC)
• Lubrication System: Integrated grease nipples with centralized lubrication channels
• Sealing: Double-lip scrapers (standard) + side seals (optional) for contamination protection
• Mounting: Flange-type mounting holes (M12 bolts) for secure attachment to machine frames

2.3 Dimensional Specifications

• Carriage Length: 210 mm
• Carriage Width: 150 mm
• Carriage Height: 65 mm
• Hole Spacing (lengthwise): 160 mm
• Hole Spacing (widthwise): 110 mm
• Compatible Rail Height: 45 mm

3. Advantages & Features

1. Superior Load Capacity: REXROTH R161924051’s 45 mm profile size and optimized ball contact design deliver exceptional radial and axial load handling, making it suitable for heavy-duty industrial applications (e.g., metalworking machinery, heavy material handlers).
2. High Precision & Low Friction: Precision-ground raceways and ball bearings in REXROTH R161924051 ensure repeatable positioning accuracy (≤0.01 mm) and minimal friction, reducing energy consumption and improving motion control responsiveness.
3. Long Service Life: Hardened steel components and corrosion-resistant coatings extend the service life of REXROTH R161924051 up to 50,000 operating hours (under normal conditions), minimizing maintenance downtime and replacement costs.
4. Contamination Resistance: Integrated scrapers and optional side seals protect REXROTH R161924051 from dust, coolant, and metal chips—critical for harsh manufacturing environments like machining and foundries.
5. Modular Compatibility: REXROTH R161924051 works seamlessly with Rexroth’s R1605 guide rails, lubrication systems, and accessories, enabling flexible customization of linear motion systems for diverse industrial needs.

4. Application Fields & Cases

4.1 Application Fields

• Machine Tools: CNC milling machines, lathes, grinding machines, laser cutting systems
• Automation: Robotic arms, linear actuators, automated assembly lines, pick-and-place systems
• Material Handling: Conveyor systems, palletizers, gantry cranes, automated storage and retrieval systems (AS/RS)
• Automotive Manufacturing: Welding robots, paint shop conveyors, component assembly stations
• Aerospace: Aircraft component machining centers, wing assembly jigs, engine part manufacturing equipment

4.2 Typical Cases

1. CNC Machining Center Precision: A leading aerospace component manufacturer integrated REXROTH R161924051 into its 5-axis CNC machining centers. The carriage’s high load capacity and low friction enabled high-speed cutting of titanium alloy parts with ±0.005 mm positioning accuracy, reducing production time by 25%.
2. Automotive Assembly Line Reliability: An automotive OEM deployed REXROTH R161924051 in its robotic welding lines. The carriage’s contamination resistance and long service life minimized unplanned downtime, increasing line productivity by 30% and cutting maintenance costs by $150,000 annually.
3. Material Handling System Efficiency: A logistics provider used REXROTH R161924051 in its automated palletizing gantry systems. The carriage’s high acceleration capability (80 m/s²) enabled faster pallet movement, increasing warehouse throughput by 40%.

5. Competitor Comparison

6. Selection Suggestions & Precautions

6.1 Selection Suggestions

1. Load & Speed Matching: REXROTH R161924051 is ideal for applications with radial loads up to 190 kN and speeds up to 5 m/s; for lighter loads (≤120 kN), select Rexroth R161921051 (35 mm profile) to reduce costs.
2. Environment Adaptation: Choose the high-temperature option (-40°C to +120°C) for foundry or furnace-side applications; opt for stainless steel components for food/beverage or cleanroom environments.
3. Accessory Compatibility: Pair REXROTH R161924051 with Rexroth’s centralized lubrication systems (e.g., R900912232) for extended maintenance intervals, and side seals for dusty or wet environments.

6.2 Precautions

1. Installation Guidelines: Align guide rails to within 0.02 mm/m straightness to avoid premature wear of REXROTH R161924051; torque mounting bolts to 80 N·m (M12) for secure fixation.
2. Lubrication Requirements: Lubricate REXROTH R161924051 with Rexroth-approved lithium-based grease (e.g., Mobil SHC 100) every 500 operating hours; avoid mixed lubricant types to prevent friction buildup.
3. Contamination Protection: Clean guide rails and carriage scrapers weekly in harsh environments (e.g., machining); replace scrapers every 12 months to maintain contamination resistance.
4. Maintenance Checks: Inspect ball bearings and raceways for wear or damage every 6 months; replace REXROTH R161924051 if radial play exceeds 0.05 mm to ensure positioning accuracy.
