Description

1. NI SCXI-1100

• Product Name: SCXI-1100
• Description: A high-performance analog-to-digital converter (ADC) module designed for the SCXI system.
• Specifications:
  • Maximum sample rate: Varies based on the selected configuration.
  • Resolution: 12-bit or higher, depending on the setup.
  • Input range: Configurable, suitable for various sensor outputs.
• Product Use: Used to convert analog signals from sensors into digital data for more accurate measurements and data processing in testing and measurement applications.

2. NI SCXI-1121

• Product Name: SCXI-1121
• Description: A modular, high-density signal conditioning, and data acquisition module designed for thermocouple measurement.
• Specifications:
  • Input channels: Typically 16 channels
  • Thermocouple types supported: J, K, T, E, N, R, S, B
  • Isolation between channels: 250 V
• Product Use: Ideal for applications requiring precise temperature measurements using thermocouples in environments such as industrial automation and laboratory settings.

3. NI SCXI-1140

• Product Name: SCXI-1140
• Description: A voltage input module for high-speed data acquisition with multiple channels.
• Specifications:
  • Input channels: 16 single-ended or 8 differential
  • Sampling rate: Up to 500 kS/s per channel
  • Input range: ±10 V
• Product Use: Designed for applications requiring fast voltage measurements from various sensors, particularly in dynamically changing environments.

4. NI SCXI-1160

• Product Name: SCXI-1160
• Description: A signal conditioning module designed for dynamic signal measurements (e.g., accelerometers and microphones).
• Specifications:
  • Input channels: 8 channels
  • Gain levels: Programmable gain options for different signal amplitudes
  • Bandwidth: Suitable for various frequency response requirements
• Product Use: Utilized in applications involving vibration analysis, noise monitoring, and other dynamic signal applications.

5. NI SCXI-1124

• Product Name: SCXI-1124
• Description: A multifunction signal conditioning module for bridge measurements (strain gauges, load cells).
• Specifications:
  • Input channels: 8 channels
  • Bridge completion: Integrated options for quarter, half, and full bridge configurations
  • Excitation voltage: Configurable for proper sensor operation
• Product Use: Commonly used in structural health monitoring, load testing, and material stress analysis applications.

General Use of SCXI Modules

NI SCXI modules are generally used in a wide range of industries for precision measurements and control. These modules excel in applications such as:

• Structural health monitoring
• Environmental testing
• Manufacturing and automation
• Research and development laboratories
