MOTOROLA MVME162-212

MOTOROLA MVME162-212 is a dual-height VME – bus embedded single – board controller (SBC) powered by the 25MHz MC68LC040/MC68040 32 – bit microprocessor, tailored for real – time control and data processing in industrial automation, aerospace testing, and energy management systems.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

MOTOROLA MVME162-212 is a dual-height VME – bus embedded single – board controller (SBC) powered by the 25MHz MC68LC040/MC68040 32 – bit microprocessor, tailored for real – time control and data processing in industrial automation, aerospace testing, and energy management systems. MOTOROLA MVME162-212 integrates a 32 – bit VMEbus interface supporting A16/A24/A32 addressing and D8/D16/D32 data widths, enabling seamless interoperability with VME – based I/O modules and peripherals. MOTOROLA MVME162-212 is equipped with 512KB battery – backed SRAM and a TOD clock, ensuring non – volatile data retention during power outages for critical system parameters. MOTOROLA MVME162-212 also features optional Ethernet and SCSI interfaces with 32 – bit DMA, facilitating high – speed data transfer for industrial communication and storage tasks. MOTOROLA MVME162-212’s IndustryPack mezzanine interface supports up to two single – wide IndustryPack modules, allowing flexible expansion for analog/digital I/O, motion control, and communication functions. With on – board diagnostic firmware and remote reset functions, MOTOROLA MVME162-212 simplifies system debugging and maintenance in harsh industrial environments.

Technical Parameters MOTOROLA MVME162-212

Parameter Item Parameter Value
Product Model MOTOROLA MVME162-212
Product Type Dual – height VME – bus embedded single – board controller
Processor 25MHz MC68LC040 (no FPU) / MC68040 (with FPU), 32 – bit, 8KB cache, MMU
Memory 4MB parity – protected DRAM (expandable to 8MB); 512KB battery – backed SRAM; 1MB flash; 8KB NVRAM
VMEbus Interface A16/A24/A32 addressing, D8/D16/D32/D64 data widths, VMEbus system controller
Communication Interfaces 2x EIA – 232 – D/EIA – 530 serial ports; optional 10BASE – T Ethernet; optional SCSI (with DMA)
Expansion IndustryPack mezzanine interface (supports 2 single – wide modules)
Timers 6x 32 – bit timers, programmable watchdog timer, TOD clock (M48T08)
Operating Temperature 0°C to +60°C
Power Supply +5V DC, ±12V DC, ±5V DC (VME standard)
Form Factor Dual – height VME module (100mm × 160mm)

Advantages and Features MOTOROLA MVME162-212

  1. Powerful Real – time Processing: The 25MHz MC68040 processor of MOTOROLA MVME162-212 delivers robust 32 – bit computing power, ideal for time – critical industrial control tasks.
  2. Flexible Expansion: MOTOROLA MVME162-212’s IndustryPack interface enables custom I/O and communication expansion without extra VME slots.
  3. Data Integrity: Battery – backed SRAM and NVRAM of MOTOROLA MVME162-212 ensure critical data retention during unexpected power failures.
  4. Easy Maintenance: On – board diagnostic firmware and remote reset functions of MOTOROLA MVME162-212 reduce on – site troubleshooting time.
  5. Broad Compatibility: MOTOROLA MVME162-212 supports VxWorks, pSOS, and NetBSD, adapting to diverse embedded system development needs.

Application Cases MOTOROLA MVME162-212

  1. Power Plant Turbine Control: A thermal power plant deployed MOTOROLA MVME162-212 as the core controller for its steam turbine governing system. The controller’s real – time processing capability enabled precise adjustment of turbine speed, improving energy conversion efficiency by 9% and reducing load – change response time by 12%.
  2. Aerospace Test Bench: An aerospace research lab integrated MOTOROLA MVME162-212 into its aircraft component test bench. With its IndustryPack motion control expansion, it achieved 0.1mm precision positioning of hydraulic actuators, ensuring accurate simulation of flight – load conditions and cutting test cycle time by 18%.
  3. Steel Mill Rolling Mill Automation: A large steel mill used MOTOROLA MVME162-212 to control its hot – rolling mill’s thickness – gauge system. The controller’s high – speed data acquisition via optional Ethernet and SCSI interfaces enabled real – time adjustment of rolling pressure, reducing product thickness deviation by 22%.

Competitor Comparison

Feature MOTOROLA MVME162-212 Siemens SIMATIC VME1430 GE Fanuc VME – 1630
Processor 25MHz MC68040 30MHz 80486DX 25MHz MC68040
Memory 4-8MB DRAM, 512KB SRAM 8-16MB DRAM, 256KB SRAM 4-8MB DRAM, 512KB SRAM
Expansion IndustryPack PC/104 IndustryPack
Communication Optional Ethernet/SCSI Built – in Ethernet Optional Ethernet
VMEbus Support D64, system controller D32, slave only D64, system controller
Price Range Mid – High Mid Mid – High

Selection Suggestions

  1. Choose MOTOROLA MVME162-212 for VMEbus – based industrial control systems that require 32 – bit real – time processing and IndustryPack expansion for I/O or motion control.
  2. Prioritize MOTOROLA MVME162-212 for applications needing non – volatile data retention, such as power plants and process control systems, leveraging its battery – backed SRAM and NVRAM.
  3. Select MOTOROLA MVME162-212 for projects with legacy VME infrastructure, as its D64 VMEbus support ensures compatibility with existing VME modules and controllers.

Precautions

  1. Use only VME – compliant power supplies (±5V, ±12V, +5V) with MOTOROLA MVME162-212 to prevent damage to the processor and on – board components.
  2. Ensure proper grounding of MOTOROLA MVME162-212 during installation to reduce electromagnetic interference and ensure stable VMEbus communication.
  3. Do not exceed the 0°C – +60°C operating temperature range of MOTOROLA MVME162-212 to avoid memory corruption and processor overheating.
  4. Replace the backup battery of MOTOROLA MVME162-212 every 2-3 years to maintain SRAM and NVRAM data retention during power outages.
  5. Use only compatible IndustryPack modules with MOTOROLA MVME162-212 to ensure electrical and mechanical compatibility and prevent bus conflicts.
