MOTOROLA MVME162-012

Description

Product Overview and Description

The MOTOROLA MVME162-012 is a high-performance, single-board computer (SBC) based on the VMEbus architecture, originally developed by Motorola’s Computer Group. This embedded controller is part of the popular MVME162 family, designed for a wide range of industrial control, telecommunications, and military/aerospace applications requiring robust performance and reliability. The MOTOROLA MVME162-012 integrates a powerful CPU, memory, and a comprehensive set of I/O functions onto a single standard VME card, providing a compact and powerful solution for embedded system designers.

The MVME162-012 is built around the MC68LC040 or MC68040 microprocessor, offering significant processing power for its generation. It is designed to operate in harsh environments with extended temperature ranges and resistance to shock and vibration. The use of the MOTOROLA MVME162-012 allows system integrators to create customized, high-reliability solutions for applications where standard PCs are not suitable, leveraging the deterministic performance and long-term availability of the VME platform.

Technical Parameters

Based on the analysis of the MVME162 family documentation, the MOTOROLA MVME162-012 possesses the following likely characteristics:

• Device Type: VMEbus Single-Board Computer (SBC) / Embedded Controller.
• Processor: MC68LC040 or MC68040 microprocessor running at 25MHz or 32MHz.
• Memory:
  • DRAM: Typically 4MB to 32MB of onboard shared DRAM.
  • SRAM: Battery-backed static RAM (up to 512KB) for non-volatile storage.
  • Flash Memory: Onboard Flash for BootROM and application storage (typically 1-4MB).
• VMEbus Interface: Full VMEbus master/slave interface supporting A32/D32 data transfers.
• Onboard I/O:
  • Four asynchronous serial ports (EIA-232) for console and device communication.
  • One parallel port (Centronics) for printer or digital I/O.
  • Ethernet interface (10BASE-T or AUI) for network connectivity.
  • SCSI interface (Fast SCSI-2) for connecting mass storage devices.
  • IndustryPack (IP) carrier sites for two IndustryPack mezzanine modules, allowing flexible I/O expansion.
• Timers: Four 32-bit timers and a watchdog timer.
• Real-Time Clock: Battery-backed real-time clock.
• Operating Systems: Supports various real-time operating systems (RTOS) including VxWorks, OS-9, LynxOS, and others.
• Form Factor: 6U VME (160mm x 233mm).
• Part Number: MOTOROLA MVME162-012 is the specific model identifier indicating the processor speed and configuration.

Advantages and Key Features

The MOTOROLA MVME162-012 offers several key advantages for embedded applications:

• Rugged and Reliable: Designed for industrial and military applications, the MVME162-012 is built with high-quality components and is tested for extended temperature ranges, shock, and vibration, ensuring reliable operation in demanding environments.
• Comprehensive I/O Integration: With onboard Ethernet, SCSI, serial, and parallel ports, plus IndustryPack expansion sites, the MOTOROLA MVME162-012 provides a complete system solution on a single board, reducing the need for additional modules.
• IndustryPack Expansion: The two IndustryPack sites on the MVME162-012 allow for tremendous flexibility. Users can add mezzanine cards for specialized I/O such as analog I/O, additional serial ports, CAN bus, or MIL-STD-1553 interfaces.
• Real-Time Performance: The 68040 processor and VMEbus architecture provide deterministic real-time performance essential for control systems, data acquisition, and signal processing applications.
• Long-Term Availability: Motorola (and later Emerson) maintained the MVME162 family for many years, making it a trusted choice for applications with long lifecycles, such as medical equipment, defense systems, and industrial machinery.

Application Cases in Key Industries

The MOTOROLA MVME162-012 has been deployed in thousands of applications across diverse industries:

• Industrial Automation: Used as a cell controller in manufacturing plants, the MVME162-012 can coordinate multiple robots, conveyors, and vision systems on a factory floor.
• Telecommunications: In telecom infrastructure, the MOTOROLA MVME162-012 served as a control processor in base station controllers and network switches.
• Medical Equipment: The reliability of the MVME162-012 made it suitable for use in medical imaging systems (CT scanners, MRI), patient monitoring systems, and laboratory analyzers.
• Defense and Aerospace: Deployed in radar systems, sonar processing, flight simulators, and onboard vehicle control systems, where the MOTOROLA MVME162-012 provides the necessary ruggedness and performance.
• Test and Measurement: As a controller in automated test equipment (ATE), the MVME162-012 manages instruments, acquires data, and executes test sequences.

Comparison with Competitors

In the VMEbus SBC market, the primary competitors to Motorola were Force Computers, PEP Modular Computers, and other embedded computing manufacturers.

• MOTOROLA MVME162-012 vs. Force Computers SPARC/68K Boards: Force offered competing 68K and SPARC-based boards. The MOTOROLA MVME162-012 benefited from Motorola’s own processor technology and a vast ecosystem of software and support, making it a preferred choice for many OEMs.
• MOTOROLA MVME162-012 vs. PEP Modular Computers: PEP offered compact VME solutions. The MVME162-012 provided a more full-featured, integrated solution with onboard SCSI and Ethernet, often reducing the need for additional modules.
• MOTOROLA MVME162-012 vs. Contemporary PC/104 Solutions: While PC/104 offers a different form factor, the MOTOROLA MVME162-012 excels in applications requiring the robustness of the VME backplane, superior cooling in sealed enclosures, and long-term supply guarantees that standard PC components may not offer.

Selection Recommendations and Precautions

1. Processor and Memory Verification: The MOTOROLA MVME162-012 may have different variations. Confirm the specific processor speed (e.g., 25MHz vs. 32MHz) and the amount of installed DRAM to ensure it meets your application’s processing and memory requirements.
2. Operating System and BSP: When using the MVME162-012, ensure you have the appropriate Board Support Package (BSP) for your chosen RTOS (e.g., VxWorks, OS-9). This is critical for hardware abstraction and driver support.
3. IndustryPack Modules: If your application requires specialized I/O, verify the availability and compatibility of IndustryPack modules for the MOTOROLA MVME162-012.
4. Environmental Specifications: Ensure the MVME162-012 variant you select meets the environmental requirements (temperature range, coating) of your target application, especially for military or outdoor installations.
5. Legacy System Support: If you are replacing or repairing an existing system, the MOTOROLA MVME162-012 is often used in legacy applications. Ensure the replacement module has the same firmware revision and configuration to guarantee plug-and-play compatibility with your existing software.
