MOOG D136-001-007

MOOG D136-001-007 is a high-performance MSC I series multi-axis motion controller integrating PLC functionality, tailored for precision position, velocity, and force control in electric and hydraulic motion systems across aerospace, precision manufacturing, metallurgy, and heavy machinery.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

MOOG D136-001-007 is a high-performance MSC I series multi-axis motion controller integrating PLC functionality, tailored for precision position, velocity, and force control in electric and hydraulic motion systems across aerospace, precision manufacturing, metallurgy, and heavy machinery. MOOG D136-001-007 delivers microsecond-level response with a 40 MHz CPU and 400 μs minimum task cycle time, ideal for high-dynamic-coordination applications. MOOG D136-001-007 supports IEC 61131-3 programming, enabling custom motion algorithms for complex multi-axis synchronization. MOOG D136-001-007 integrates 8 analog inputs, 2 analog outputs, and 8 digital I/Os, with configurable SSI/incremental encoder interfaces for precise feedback. MOOG D136-001-007 features CAN/CANopen, Ethernet, and optional Profibus-DP, ensuring seamless integration with servo drives, hydraulic valves, and upper-level control systems. MOOG D136-001-007’s modular E‑bus expansion and DIN‑rail mounting simplify system customization and maintenance.

Technical Parameters MOOG D136-001-007

Parameter Item Parameter Value
Product Model MOOG D136-001-007
Product Type MSC I Series Motion Controller with PLC Function
Core Function Multi-axis motion control, position/velocity/force control, PLC logic, I/O management
CPU 40 MHz 32‑bit RISC (PowerPC with FPU)
Memory 4 MB Flash EEPROM, 4 MB RAM
Minimum Task Cycle Time 400 μs
Analog I/O 8×16‑bit analog inputs, 2×16‑bit analog outputs (configurable range)
Digital I/O 8×digital I/O (configurable as input/output)
Position Transducer Interface 2×SSI (Master/Slave) or incremental encoder
Communication Interfaces 2×CAN/CANopen, 2×RS‑232, Ethernet, E‑bus; optional Profibus‑DP slave
Power Supply 24V DC (redundant input support)
Operating Temperature 0°C to +60°C
Storage Temperature -25°C to +70°C
Protection Level IP20
Mounting DIN‑rail
Programming Standard IEC 61131‑3 (LD, FBD, ST, IL)
MTBF ≥150,000 hours
Warranty Period 1 year

Advantages and Features MOOG D136-001-007

  1. Precision Motion Control: MOOG D136-001-007 achieves ±0.001 mm positioning accuracy via high‑resolution feedback and closed‑loop algorithms, critical for aerospace test benches and precision machine tools.
  2. Fast Response: 400 μs cycle time enables MOOG D136-001-007 to track dynamic motion profiles with microsecond‑level latency.
  3. Programming Flexibility: IEC 61131‑3 compliance allows custom logic for MOOG D136-001-007, adapting to unique multi‑axis coordination needs.
  4. Modular Expansion: E‑bus interface lets MOOG D136-001-007 add I/O/communication modules without reconfiguring the core system.
  5. Multi‑Protocol Compatibility: CAN/CANopen, Ethernet, and Profibus‑DP (optional) ensure MOOG D136-001-007 integrates with diverse servo drives and control networks.
  6. Seamless Feedback Integration: Dual configurable position transducer interfaces of MOOG D136-001-007 support encoders/resolvers for closed‑loop precision.

Application Cases MOOG D136-001-007

  1. Aerospace Component Test Bench: An aerospace lab used MOOG D136-001-007 for hydraulic servo valve testing, achieving ±0.001 mm 阀芯 displacement control and reducing test cycle time by 25%.
  2. Precision Grinding Machine: A tool manufacturer deployed MOOG D136-001-007 for 2‑axis spindle/table synchronization, improving surface finish by Ra 0.2 μm and yield by 18%.
  3. Metallurgical Continuous Casting: A steel mill integrated MOOG D136-001-007 to control mold oscillation, cutting slab defects by 30% via real‑time speed/position adjustment.
  4. Heavy Machinery Hydraulic Control: A construction equipment maker utilized MOOG D136-001-007 for crane boom positioning, enabling ±0.5° angle precision and enhancing safety margins by 22%.

Competitor Comparison

Feature MOOG D136-001-007 MOOG MSC II D136-002-002 Siemens S7‑1500 Motion Controller
Core Focus Motion control + PLC (2‑axis optimized) Multi‑axis (4‑axis) + advanced fieldbus PLC‑centric + basic motion
Task Cycle Time 400 μs 200 μs ≥500 μs
Position Transducer Interfaces 2 4 2 (Siemens‑centric)
Expansion Bus E‑bus (modular) E‑bus (enhanced) Profinet I/O
Programming IEC 61131‑3 IEC 61131‑3 + C++ IEC 61131‑3 (limited motion blocks)
Protection Level IP20 IP20 IP54
MTBF ≥150,000 hours ≥180,000 hours ≥160,000 hours
Price Range Mid‑Range Mid‑High High

Selection Suggestions

  1. Choose MOOG D136-001-007 for 2‑axis precision applications (e.g., test benches, small‑scale machine tools) to leverage its cost‑effective performance and PLC integration.
  2. Prioritize MOOG D136-001-007 for mixed electric/hydraulic systems, as its flexible feedback and drive interfaces minimize integration effort.
  3. Select MOOG D136-001-007 for DIN‑rail cabinet setups—its compact design and E‑bus expansion reduce footprint and upgrade costs.

Precautions

  1. Use a stable 24V DC redundant power supply for MOOG D136-001-007 to avoid voltage fluctuations affecting motion precision.
  2. Verify Profibus‑DP slave compatibility (if used) between MOOG D136-001-007 and the master before commissioning.
  3. Follow IEC 61131‑3 standards when programming MOOG D136-001-007 to prevent motion‑logic conflicts in closed loops.
  4. Ensure E‑bus expansion modules are MOOG‑compatible to maintain signal integrity and system stability for MOOG D136-001-007.
