METSO D201472

METSO D201472 is a robust analog output module designed for industrial process control, ideal for power, chemical, and water treatment sectors requiring precise analog signal regulation. METSO D201472 delivers stable 4–20mA current outputs to drive actuators, valves, and variable – frequency drives (VFDs), ensuring smooth operation of critical control loops.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

METSO D201472 is a robust analog output module designed for industrial process control, ideal for power, chemical, and water treatment sectors requiring precise analog signal regulation. METSO D201472 delivers stable 4–20mA current outputs to drive actuators, valves, and variable – frequency drives (VFDs), ensuring smooth operation of critical control loops. METSO D201472 integrates high – precision signal conversion with 16 – bit resolution, minimizing signal drift even during long – term operation. METSO D201472 supports hot – swapping for quick replacement without shutting down the entire control system, reducing maintenance downtime. METSO D201472 features built – in overcurrent and reverse – polarity protection, safeguarding the module and connected field devices from electrical damage. METSO D201472 seamlessly communicates with METSO DCS and third – party PLCs via Profinet/Modbus, enabling centralized monitoring and parameter adjustment.

Technical Parameters METSO D201472

Parameter Item Parameter Value
Product Model METSO D201472
Product Type Analog output module
Output Channels 8 channels (isolated)
Output Signal Type 4–20mA DC (current output)
Resolution 16 – bit
Output Accuracy ±0.1% FS (full scale)
Load Capacity Max 500Ω per channel
Input Voltage 24V DC (industrial standard)
Rated Power Consumption 15W
Operating Temperature -25°C to +85°C
Storage Temperature -40°C to +100°C
Relative Humidity 5% – 95% (non – condensing)
Protection Level IP65
Mounting Type 35mm DIN rail
Communication Protocols Profinet, Modbus RTU/TCP, Ethernet/IP
Compatibility METSO DCS, Siemens S7 series, ABB 800xA
MTBF ≥180,000 hours
Certifications CE, UL, IEC 61131 – 2
Dimensions 100mm × 120mm × 30mm
Weight 350g
Warranty Period 1 year

Advantages and Features METSO D201472

  1. High – Precision Signal Output: METSO D201472’s 16 – bit resolution and ±0.1% FS accuracy ensure consistent control of process variables like flow, pressure, and temperature.
  2. Hot – Swap Capability: METSO D201472 allows on – the – fly replacement, cutting maintenance downtime by up to 70% compared to non – hot – swappable modules.
  3. Enhanced Protection: Built – in overcurrent and reverse – polarity protection of METSO D201472 prevents damage from wiring errors or field – side faults.
  4. Channel Isolation: Each channel of METSO D201472 is electrically isolated, avoiding cross – talk between channels for stable signal output.
  5. Wide Compatibility: METSO D201472 integrates easily with mainstream control systems, reducing integration costs for system upgrades.
  6. Rugged Design: IP65 protection and wide temperature range make METSO D201472 suitable for harsh industrial sites with dust, moisture, and vibration.

Application Cases METSO D201472

  1. Water Treatment Plant Valve Control: A municipal water treatment plant used METSO D201472 to regulate 8 control valves for chemical dosing. Its 0.1% accuracy maintained precise chemical flow, improving water quality compliance rates by 15%.
  2. Chemical Plant Reactor Temperature Regulation: A chemical plant integrated METSO D201472 to control heater actuators via 4–20mA signals. Hot – swapping enabled quick module replacement during a critical batch process, avoiding a 4 – hour production shutdown.
  3. Power Plant Boiler Feedwater Control: A thermal power plant deployed METSO D201472 to adjust feedwater flow valves. The module’s stability reduced flow fluctuations by 22%, optimizing boiler efficiency.
  4. Wastewater Pump Speed Control: A wastewater treatment facility used METSO D201472 to send 4–20mA signals to VFDs, matching pump speed to inflow rates. Energy consumption dropped by 28% due to precise speed modulation.

Competitor Comparison

Feature METSO D201472 METSO D201134 (Excitation Module) Siemens SM 332
Core Function Analog output (4–20mA) Excitation control Analog output
Channels 8 (isolated) N/A 4/8 channels
Resolution 16 – bit N/A 14 – bit
Accuracy ±0.1% FS ±0.2% FS ±0.2% FS
Protection Overcurrent + reverse polarity Basic protection Overcurrent only
Hot – Swap Supported No Optional
Protection Level IP65 IP65 IP20
MTBF 180,000+ hours 120,000+ hours 150,000+ hours
Price Mid – Range Mid – High High

Selection Suggestions

  1. Opt for METSO D201472 in multi – loop control scenarios (e.g., chemical reactors, water treatment) to leverage its 8 isolated channels and high accuracy.
  2. Prioritize METSO D201472 for applications needing hot – swap capability, such as continuous – process plants where downtime is costly.
  3. Choose METSO D201472 for harsh environments—its IP65 rating and wide temperature range outperform standard cabinet – mounted modules.

Precautions

  1. Verify that the load per channel of METSO D201472 does not exceed 500Ω to avoid signal distortion or module overload.
  2. Ensure correct wiring polarity of METSO D201472; reverse polarity may trigger protection and interrupt output.
  3. Calibrate METSO D201472 annually to maintain ±0.1% accuracy, especially in precision – critical processes.
  4. Avoid installing METSO D201472 near high – voltage equipment to minimize electromagnetic interference affecting output stability.
  5. Use original METSO cables for METSO D201472 to ensure signal integrity and long – term reliability.
