ICS TRIPLEX T9481

Description

Product Description

ICS TRIPLEX T9481 is a Trusted Digital Output Module for the ICS Triplex Trusted TMR System. This module is a critical final element interface within a Triple Modular Redundant safety controller. Its primary function is to provide a robust, voted digital output signal to field devices, such as solenoid valves, motor starters, or alarm annunciators, based on the 2-out-of-3 decision of the main processor modules. The ICS TRIPLEX T9481 takes the voted command from the TMR logic solver and executes it through three independent output circuits. These circuits are wired in parallel to a single field device, ensuring that the command is carried out even if one of the three internal output channels fails. The reliability of the T9481 is essential, as it forms the final electronic link in the safety instrumented function (SIF) chain before the physical actuator.

Product Parameters / Technical Specifications

• Manufacturer: ICS Triplex (now part of Rockwell Automation)
• System: Trusted® TMR (Triple Modular Redundant) System
• Functional Designation: Digital Output Module
• Architecture: Triple-channel internal design. Contains three independent output circuits (one per TMR channel) that are wired together to drive a single field load.
• Output Type: Discrete (ON/OFF) output. Typically a dry contact relay or a solid-state output.
• Output Rating: Rated for a specific voltage and current (e.g., 24-120 VDC, 2A per channel; or 120/240 VAC). The exact rating is critical.
• Isolation: Provides high-grade isolation between the output circuits and the logic side, and between each of the three internal channels.
• Voting Implementation: The voting occurs in the logic solver. The T9481 module itself contains the three separate output paths that physically execute the voted command.
• Diagnostics: Includes comprehensive diagnostics for each internal channel, capable of detecting open circuit, short circuit, and load failures. A fault in one channel is reported but does not prevent the other two from operating the field device.
• Communication: Interfaces with the three main TMR processor modules via the trusted backplane.

Advantages and Key Features

• Fault-Tolerant Output Design: The core advantage of the ICS TRIPLEX T9481 is its ability to tolerate a failure within one of its three internal output circuits without losing the ability to drive the field load. This maintains the safety function’s availability.
• High Diagnostic Coverage: Advanced diagnostics provide early warning of impending output circuit failure, allowing for predictive maintenance and reducing the probability of failure on demand (PFD).
• Safety Integrity: Designed and certified for use in Safety Instrumented Systems (SIS) up to SIL 3 as per IEC 61508 and IEC 61511 standards.
• Hot-Replaceable: Can typically be replaced online without shutting down the TMR controller or the process, supporting very high system availability.
• Deterministic Performance: Provides a fast, guaranteed response time for executing safety trip commands.
• Robust Industrial Construction: Built to withstand harsh electrical and environmental conditions typical of industrial plant floors.

Application Cases in Industry

• Emergency Shutdown (ESD) Valve Control: The primary application for the ICS TRIPLEX T9481 is to de-energize (trip) or energize safety shutdown valves in oil & gas production, pipelines, and refining.
• Fire & Gas System Actuation: Activates deluge valves, fans, or HVAC shutdown dampers upon detection of fire or gas.
• Turbomachinery Protection: Triggers the trip mechanism on gas turbines or compressors in response to overspeed, high vibration, or other critical alarms.
• Critical Process Interlocks: Provides reliable output for any process interlock where failure could lead to a hazardous situation.

Comparison with Competing Products

Selection Suggestions and Precautions

1. Verify Exact Electrical Ratings: Critically important. Confirm the output type (relay or solid-state), voltage rating (AC/DC), and current rating of the ICS TRIPLEX T9481 module match the requirements of the field device (solenoid, contactor coil). Overloading will damage the module.
2. Understand the Wiring Configuration: The three output channels of the T9481 are wired in parallel to a single field device. You must follow the specific Trusted system wiring diagrams precisely. Incorrect wiring can defeat the redundancy.
3. External Protection for Inductive Loads: When driving inductive loads (solenoids, relay coils), you must use an external suppression device (a flyback diode for DC, an RC snubber for AC) across the load terminals to protect the module’s output circuits from voltage spikes.
4. Utilize Diagnostic Alarms: Configure the system to annunciate diagnostic faults from the T9481. A fault in one channel is an early warning that maintenance is required before the second channel fails.
5. Sourcing from Certified Safety System Specialists: This is a critical safety system component. Purchase the T9481 only from Rockwell Automation/ICS Triplex or their authorized, certified system integrators. They can guarantee authenticity, provide compatibility information, and ensure you receive a module with the correct firmware and configuration for your system.
