HONEYWELL TK-IOLI01

Description

HONEYWELL TK-IOLI01 is a local I/O link interface module, likely for the Honeywell Experion Process Knowledge System (PKS) or a related control platform. This module, the TK-IOLI01, serves as a communication bridge or concentrator between a primary controller (like a C300) and a bank of locally mounted I/O modules. Detailed technical specifications can be found on the product page: HONEYWELL TK-IOLI01. The HONEYWELL TK-IOLI01 enables the expansion of a controller’s I/O capacity by managing a dedicated local I/O network, facilitating high-speed and deterministic data exchange.

Product Description

The HONEYWELL TK-IOLI01 is a specialized interface card designed to be installed in an Experion C Series controller chassis or a dedicated I/O chassis. Its primary function is to provide a high-speed, proprietary communication link (the Local I/O Link) to one or more local I/O termination assemblies (like TAI01 or TCI01 units) that house the actual field wiring connections. The module acts as a master on this link, scanning the connected I/O modules, collecting input data from field devices, and distributing output commands from the controller. The TK-IOLI01 handles the protocol conversion and data management, ensuring that the I/O data is seamlessly integrated into the controller’s process image. This architecture allows for a distributed I/O layout while maintaining centralized control logic.

Product Parameters

• Brand and Manufacturer: HONEYWELL.
• Product Series: Experion PKS C Series (or possibly legacy TPS/TDC systems, given the “TK” prefix, but adapted for Experion).
• Product Type: Local I/O Link Interface Module.
• Compatible Controller: Designed for use with C200, C300, or other specified Honeywell controllers.
• Link Type: Proprietary high-speed serial link for communication with local I/O termination units.
• Number of Connected Units: Supports connection to a specific number of local I/O termination assemblies (e.g., up to 4 or 8 TAI01/TCI01 units) in a daisy-chain or star configuration.
• Data Transfer Rate: High-speed communication to support fast update times for all I/O points on the link.
• Function: Manages the cyclic data exchange (I/O scanning) between the controller and the remote I/O modules. Provides diagnostics for the link and connected I/O units.
• Physical Connection: Uses specialized coaxial or twisted-pair cables with Honeywell-specific connectors.
• LED Indicators: Status LEDs for power, link activity, fault, and communication status with the controller.
• Redundancy Support: May support redundant link configurations for high availability.

Advantages and Features

The key advantage of the HONEYWELL TK-IOLI01 is its ability to extend the physical reach and point density of a controller’s I/O system without compromising performance. It allows field I/O to be located closer to the process equipment, reducing long and costly field wiring runs back to a central cabinet. The dedicated link ensures deterministic and fast I/O update times, which is critical for regulatory control loops. The module provides comprehensive diagnostics for the entire local I/O network, simplifying troubleshooting. Its integration with the Experion engineering environment (Control Builder) allows for seamless configuration and monitoring. Using the HONEYWELL TK-IOLI01 facilitates a scalable and maintainable I/O architecture for large or geographically spread-out process units.

Application Cases in Various Fields

• Large Refinery Unit Control: A C300 controller uses a TK-IOLI01 module to connect to several local I/O cabinets distributed around a distillation column, collecting temperatures, pressures, and controlling valves.
• Pipeline Pump Station Control: Managing I/O from multiple skids (pumps, valves, filters) located hundreds of meters apart from a central control hut via a robust local I/O link.
• Water Treatment Plant: A single controller interfaces with local I/O panels at the intake, clarifier, filter, and chemical dosing stations across a large site.
• Batch Reactor Complex: Connecting I/O from multiple reactors and associated feed tanks to a centralized batch sequencing controller.
• Power Plant Auxiliary Systems: Distributing I/O for BOP (Balance of Plant) systems like coal handling, water treatment, and flue gas desulfurization from a central control room.

Comparison with Competing Products

As a proprietary interface for Honeywell’s Experion system, the TK-IOLI01 has no direct interchangeable competitors. Its function is analogous to remote I/O communication processors in other DCS platforms, such as Emerson’s DeltaV Remote I/O CHARM Communication Carriers, Siemens’ SIMATIC ET 200SP interface modules (IM), or Yokogawa’s FIO/RIO Node Communication Units. These all serve the purpose of extending I/O over a dedicated network. The choice is dictated by the selected DCS platform. The TK-IOLI01 is specifically engineered for Honeywell’s Local I/O Link protocol and Experion architecture, offering optimized performance and support within that ecosystem.

Selection Suggestions and Precautions

1. Verify System Compatibility: Confirm the TK-IOLI01 is compatible with your specific Experion controller model (C200, C300) and chassis type. It may also have compatibility requirements with the I/O termination units (TAI01/TCI01).
2. Plan the Local I/O Network: Design the network topology (daisy-chain length, number of nodes) strictly within the limits specified in the hardware manual. Consider cable type, termination, and maximum distance.
3. Address Configuration: Each local I/O termination unit on the link must be configured with a unique node address. This is typically set via hardware switches on the termination unit.
4. Redundancy Requirements: For critical applications, determine if a redundant TK-IOLI01 link configuration is required and plan the hardware and cabling accordingly.
5. Software Configuration: The module and all I/O points on the local link must be meticulously configured in the Experion Control Builder software, including mapping to the controller’s process database.
