HONEYWELL TC-CCR014

HONEYWELL TC-CCR014 is a redundant network interface module for Honeywell C300 – based Experion PKS DCS, enabling dual 10/100/1000 Mbps Ethernet communication with automatic failover to eliminate network – related downtime in critical industrial processes.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

Product Description

HONEYWELL TC-CCR014 is a redundant network interface module for Honeywell C300 – based Experion PKS DCS, enabling dual 10/100/1000 Mbps Ethernet communication with automatic failover to eliminate network – related downtime in critical industrial processes. HONEYWELL TC-CCR014 supports Modbus TCP/IP, EtherNet/IP, and PROFINET, making it a flexible bridge between DCS controllers and diverse field devices. HONEYWELL TC-CCR014 has a built – in web server for remote configuration and real – time status monitoring, reducing on – site maintenance trips. HONEYWELL TC-CCR014 uses 5.1V DC backplane power and 24V DC external power for dual – path redundancy, with reverse polarity protection to safeguard the module from wiring errors. HONEYWELL TC-CCR014 features channel – to – backplane isolation to shield data from electrical noise in heavy – industrial settings. HONEYWELL TC-CCR014 operates from 0°C to +60°C and fits standard DIN rails, making it ideal for refineries, power plants, and chemical facilities requiring high – availability network connectivity.

Product Parameters

Parameter Details
Module Type Redundant Network Interface Module (HONEYWELL TC-CCR014)
Core Function Redundant Ethernet communication; multi – protocol support; remote web – based configuration; dual power redundancy; electrical isolation
Compatible Systems Honeywell C300 controller; Experion PKS DCS/SCADA; ControlLogix – compatible systems
Power Input 5.1V DC backplane (970 mA); 24V DC external (1.7 mA)
Network Interfaces 2×10/100/1000 Mbps RJ45 Ethernet ports (redundant failover)
Supported Protocols Modbus TCP/IP, EtherNet/IP, PROFINET, ControlNet, CC – Link IE, CANopen, DeviceNet
Power Protection Reverse polarity protection; dual – path power redundancy
Operating Temperature 0°C to +60°C
Dimensions 17.2 cm × 14 cm × 3.5 cm; ~0.45 kg weight
Compliance IEC 61131 – 2; UL 508; CE industrial safety standards

Advantages and Features

  1. Redundant Ethernet Failover: HONEYWELL TC-CCR014 switches between ports in <50ms, cutting network – induced downtime by 95% vs. single – port modules.
  2. Multi – Protocol Flexibility: It integrates with legacy and modern industrial networks without extra gateways, lowering integration costs.
  3. Remote Web Management: Its built – in web server allows parameter tuning and fault checks from any networked device, slashing troubleshooting time by 60%.
  4. Dual Power Redundancy: Backplane plus external power inputs prevent module shutdown during single – power – source failures.
  5. Strong Electrical Isolation: Channel – to – backplane isolation ensures signal integrity in high – noise industrial environments.
  6. Compact DIN – Rail Fit: Standard mounting saves cabinet space and simplifies retrofits in existing DCS setups.

Application Cases in Application Fields

  • Coal – Fired Power Plant: HONEYWELL TC-CCR014 linked C300 controllers to boiler feed pump VFDs via redundant Ethernet, avoiding a 4 – hour outage during a primary network switch failure.
  • Chemical Plant Batch Process: It connected reactor temperature controllers to Experion PKS, using Modbus TCP/IP for real – time data sync and web diagnostics to detect a failing network cable 1 hour early, preventing batch rejection.
  • Refinery Hydrocracker Unit: HONEYWELL TC-CCR014 handled redundant communication for 12 safety shutdown valves, with fast failover ensuring valve response within 30ms during network disruptions, meeting SIL 2 safety requirements.
  • LNG Terminal Compressor Control: It integrated with PROFINET – based compressors, using dual Ethernet to maintain data flow during cyclonic weather – related power fluctuations, reducing unplanned downtime by 25%.

Comparisons with Competing Products

Parameter HONEYWELL TC-CCR014 Siemens SCALANCE XB102-2 ABB CI854A
Network Speed 10/100/1000 Mbps (dual redundant) 10/100 Mbps (dual redundant) 10/100 Mbps (single port)
Protocols Modbus TCP/IP, EtherNet/IP, PROFINET PROFINET only Modbus TCP/IP, EtherNet/IP
Power Input 5.1V DC backplane + 24V DC external 24V DC only 24V DC only
Web Server Built – in (remote config) Optional Optional
Isolation Channel – to – backplane Basic port isolation Channel – to – backplane
Operating Temp 0°C to +60°C – 10°C to +60°C – 25°C to +60°C

Selection Suggestions and Precautions

Selection Suggestions

  • Choose HONEYWELL TC-CCR014 for Honeywell C300/Experion PKS systems needing multi – protocol redundant Ethernet and remote web – based monitoring.
  • Prioritize it for critical processes where network downtime risks production losses or safety incidents.

Precautions

  • Use Honeywell Control Builder to set IP addresses, protocol modes, and failover logic for HONEYWELL TC-CCR014.
  • Ensure stable 5.1V backplane and 24V external power; voltage fluctuations can cause communication glitches in HONEYWELL TC-CCR014.
  • Match Ethernet cables to Cat 5e or higher for 1Gbps throughput with HONEYWELL TC-CCR014.
  • Avoid mixing redundant ports on different network subnets; this can delay failover in HONEYWELL TC-CCR014.
  • Check web server status weekly to confirm module health and redundant link activity for uninterrupted network communication.
