HONEYWELL SPS5785 51198651-100

Description

Product Description: Power Supply HONEYWELL SPS5785 51198651-100

The HONEYWELL SPS5785 51198651-100 is a high-reliability switching power supply unit designed for integration into Honeywell’s industrial automation and control system cabinets. This specific model, identified by the complete part number 51198651-100, is part of the SPS family, engineered to provide clean, regulated, and isolated DC power to sensitive electronic components such as controller processors, I/O modules, and communication cards within Distributed Control Systems (DCS) like Experion PKS. The reliable operation of the HONEYWELL SPS5785 51198651-100 is foundational to the stability of the entire control node it serves. For detailed electrical and mechanical specifications, refer to the official documentation: HONEYWELL SPS5785 51198651-100. Specifying the correct HONEYWELL SPS5785 51198651-100 is a critical step in ensuring system design integrity and operational uptime.

Key Parameters

• Function: AC/DC Switching Power Supply Module. It converts incoming AC mains voltage (typically with a wide input range like 85-264V AC, 47-63 Hz) to one or more precisely regulated and isolated DC voltage outputs required by the control system electronics.
• Output Specifications: Defined by the suffix -100, which indicates a specific power rating and output configuration. It likely supplies standard system voltages such as +24V DC for field I/O and relays, +5V DC for logic circuits, and possibly ±15V DC for analog circuits. The -100 often denotes a power rating (e.g., 100W, 120W).
• Protection and Safety: Incorporates comprehensive protection features including overvoltage protection (OVP), overcurrent protection (OCP), short-circuit protection (SCP), and thermal overload protection. These features safeguard both the power supply and the downstream load.
• Efficiency and Cooling: Designed for high efficiency (typically >85%) to minimize power loss and heat generation. It is usually convection-cooled (fanless) for silent, maintenance-free operation suitable for standard control cabinet environments.
• Mounting and Form Factor: Engineered for secure DIN-rail mounting or direct chassis mounting within a Honeywell system cabinet. Features robust screw terminal blocks for secure AC input and DC output connections.
• Certifications: Carries necessary international safety (e.g., UL, CE, ATEX for specific models) and electromagnetic compatibility (EMC) certifications for reliable use in industrial environments.

Advantages and Features
The primary advantage of the HONEYWELL SPS5785 51198651-100 is its engineered reliability and guaranteed compatibility within Honeywell’s automation ecosystem. It provides exceptionally clean DC power with low ripple and noise, which is crucial for the accurate operation of analog measurement circuits and the stable functioning of digital processors. Its robust design ensures long-term, continuous (24/7) operation with a high mean time between failures (MTBF). The integrated protection suite prevents faults from propagating and causing wider system damage. For system designers and maintainers, using the official HONEYWELL SPS5785 51198651-100 simplifies cabinet design, ensures compliance with system power specifications, and provides a single point of responsibility for power integrity, reducing overall project risk.

Application Case Studies in Various Fields

• Experion PKS Controller Node: Serving as the primary power source for a C300 Process Automation Controller chassis and its associated I/O modules in a refinery or chemical plant control room.
• Remote I/O Enclosure: Providing dedicated, conditioned power to a bank of C-series I/O modules located in a field-mounted junction box near a pipeline pump station.
• Safety System Cabinet: Powering the logic solvers and I/O modules of a Honeywell Safety Manager system where power quality and availability are critical for functional safety integrity.
• System Modernization and Retrofit: Replacing aging or undersized power supplies in legacy system cabinets during an upgrade project to improve reliability and support additional hardware.
• Critical Machine Control Panel: Acting as the central DC power supply for a Honeywell PLC or dedicated controller panel on a large compressor, turbine, or other critical rotating equipment package.

Comparison with Competing Products
The HONEYWELL SPS5785 51198651-100 competes with high-quality industrial DIN-rail power supplies from manufacturers such as Siemens (SITOP), Phoenix Contact (QUINT), ABB, and Weidmüller. Its key differentiators are its specific validation and recommendation for use within Honeywell systems and its potential optimization for the load profiles of Honeywell controllers and I/O modules. While third-party units may offer similar electrical specifications, the HONEYWELL SPS5785 51198651-100 offers the assurance of a single-vendor solution, simplified procurement for Honeywell-centric projects, and direct support from Honeywell should any power-related system integration issues arise.

Selection Suggestions and Important Precautions

1. Perform a Detailed Load Calculation: Meticulously calculate the total DC load current required by all devices to be powered. Include inrush currents for inductive loads (solenoids, contactors). Select the HONEYWELL SPS5785 51198651-100 only if its continuous output current/power rating exceeds the total calculated load by a safe margin (typically 25-30%).
2. Verify Input Voltage Compatibility: Ensure the available AC supply voltage at the installation site is within the specified input range of the power supply. The HONEYWELL SPS5785 51198651-100 model must match your plant’s electrical system (e.g., 120V AC, 230V AC).
3. Implement External Input Protection: Protect the power supply and downstream circuitry by installing appropriately rated fuses or a circuit breaker on the AC input line, following local electrical codes and Honeywell’s installation guidelines.
4. Ensure Proper Derating and Cooling: Adhere to any specified derating curves, especially if the ambient temperature in the cabinet is expected to be high (e.g., >40°C). Ensure adequate space around the unit for convection cooling.
5. Plan for Redundancy in Critical Applications: For applications where power supply failure would cause a process shutdown or safety risk, implement a parallel redundant configuration using two HONEYWELL SPS5785 51198651-100 units with a dedicated redundancy module to ensure uninterrupted power. Always procure from authorized Honeywell distributors. Before energizing, double-check all wiring connections for correctness and tightness. Use a multimeter to measure the output voltages upon first power-up to confirm they are within the specified tolerances.
