HONEYWELL SPS5713 51199930-100

Description

Product Description: Power Supply Module HONEYWELL SPS5713 51199930-100

The HONEYWELL SPS5713 51199930-100 is a robust and highly reliable switching power supply unit designed for integration into industrial automation systems, specifically within Honeywell’s Distributed Control System (DCS) cabinets and racks. This unit provides conditioned and regulated DC power to critical components such as controller processors, I/O modules, and communication cards. The part number 51199930-100 specifies the exact configuration and revision of the SPS5713 model. As the foundational power source for system electronics, the reliable operation of the HONEYWELL SPS5713 51199930-100 is paramount. For detailed electrical specifications and mounting instructions, consult the official resource: HONEYWELL SPS5713 51199930-100. Selecting the correct power supply, such as the HONEYWELL SPS5713 51199930-100, is a critical step in ensuring overall system stability and longevity.

Key Parameters

• Function: DC Switching Power Supply. Converts incoming AC line voltage (typically 100-240V AC, 50/60 Hz) to one or more isolated and tightly regulated low-voltage DC outputs, such as +5V, ±15V, and +24V, which are standard for logic, analog, and field circuit power.
• Output Power and Ratings: Defined by the specific model suffix (-100). This indicates the total output power capacity (e.g., 100W, 150W, 240W) and the current rating for each output voltage rail. These ratings must meet or exceed the total load of all connected devices in the chassis.
• Protection Features: Incorporates comprehensive protections including overvoltage protection (OVP), overcurrent protection (OCP), short-circuit protection (SCP), and thermal overload protection. These features safeguard both the power supply itself and the sensitive downstream electronics.
• Efficiency and Cooling: Designed with high efficiency (often >85%) to minimize heat generation. Typically uses convection cooling (fanless) for silent and maintenance-free operation, suitable for standard control cabinet environments.
• Mounting and Form Factor: Engineered for secure mounting on a DIN rail or direct chassis mounting within a Honeywell system cabinet. Features screw terminal blocks for secure AC input and DC output connections.
• Certifications: Carries necessary international safety (e.g., UL, cUL, CE) and electromagnetic compatibility (EMC) certifications for use in industrial environments.

Advantages and Features
The primary advantage of the HONEYWELL SPS5713 51199930-100 is its engineered reliability and guaranteed compatibility within Honeywell’s automation environment. It provides exceptionally clean and stable DC power with low ripple and noise, which is crucial for the accurate operation of analog measurement circuits and digital processors. Its robust design ensures long-term, continuous (24/7) operation with high mean time between failures (MTBF). The integrated protection suite prevents catastrophic failures from propagating. For system designers, using the official HONEYWELL SPS5713 51199930-100 simplifies cabinet design, ensures compliance with system specifications, and provides a single point of responsibility for power integrity.

Application Case Studies in Various Fields

• Experion PKS Controller Cabinet: Serving as the primary power source for a C300 Process Automation Controller chassis, supplying power to the controller module, I/O cards, and network interfaces in a refinery control room.
• Remote I/O Enclosure Power: Providing dedicated, clean power to a bank of C-series I/O modules located in a field-mounted junction box near a pipeline compressor station.
• Safety System Cabinet: Powering the logic solvers and I/O modules of a Honeywell Safety Manager system where power quality and availability are critical for functional safety.
• System Modernization and Retrofit: Replacing aging or undersized power supplies in legacy TDC 3000 or Experion cabinets to improve reliability and support additional hardware during an upgrade project.
• Critical Machine Control Panel: Acting as the central DC power supply for a Honeywell PLC-based control panel on a large compressor or pump package.

Comparison with Competing Products
The HONEYWELL SPS5713 51199930-100 competes with high-quality industrial DIN-rail power supplies from manufacturers like Siemens (SITOP), Phoenix Contact (QUINT), ABB, and Murr. Its key differentiators are its specific validation and recommendation for use within Honeywell systems and its potential optimization for the load characteristics of Honeywell controllers and I/O. While electrical specifications may be similar to third-party units, the HONEYWELL SPS5713 51199930-100 offers the assurance of a single-vendor solution, simplified procurement for Honeywell-centric projects, and direct support from Honeywell should any power-related system issues arise.

Selection Suggestions and Important Precautions

1. Accurate Load Calculation: Meticulously calculate the total DC load from all devices to be powered. Include inrush currents for inductive loads. Select the HONEYWELL SPS5713 51199930-100 model whose continuous output rating exceeds the total calculated load by a safety margin (typically 20-30%).
2. Verify Input Voltage Range: Ensure the available AC supply voltage (e.g., 120V AC, 230V AC) is within the specified input range of the power supply. The -100 suffix model must match your plant’s electrical system.
3. Implement Input Protection: Protect the power supply by installing appropriately rated fuses or a circuit breaker on the AC input line. Follow local electrical codes and Honeywell’s installation guidelines.
4. Ensure Adequate Cooling and Derating: Install the unit in a well-ventilated area of the cabinet. Observe any specified derating curves if the ambient temperature is expected to be high (e.g., >40°C).
5. Plan for Redundancy in Critical Applications: For applications where power supply failure is unacceptable, implement a parallel redundant configuration using two HONEYWELL SPS5713 51199930-100 units with a redundancy module. This ensures uninterrupted power. Always procure from authorized Honeywell distributors. Before energizing, double-check all wiring connections for correctness and tightness. Measure the output voltages to confirm they are within specification.
