HONEYWELL SC-UCMX01 51307198-175

Description

Product Description

Product Parameters

1. Module Type: Non-redundant industrial controller with 28-channel onboard mixed I/O module, dedicated to Honeywell Experion SCADA/PLC system
2. Working Voltage: DC 24V ±10% (18-30VDC), wide voltage adaptation to industrial power supply fluctuations
3. Core Processor: Dual-core 667MHz industrial control processor, supporting high-speed logic operation and data processing
4. I/O Channels: 28-channel mixed I/O, configurable for analog (4-20mA, 0-10V) and digital (DI/DO) signals
5. Communication Protocol: Native support for Modbus RTU/TCP, Ethernet/IP, DNP3, IEC 60870-5-101/104, compatible with Honeywell original communication protocol
6. Working Temperature: -40°C ~ +70°C, adapt to extreme high and low temperature industrial environments
7. Storage Temperature: -40°C ~ +85°C, suitable for long-term storage in various environments
8. Power Consumption: Minimum 1.7W (no expansion IOMs), maximum 3.4W (with expansion IOMs)
9. Protection Grade: IP20, suitable for cabinet-mounted installation, dustproof and anti-light mechanical contact
10. Installation Method: Standard DIN 35mm rail installation, compatible with Honeywell original control cabinet racks
11. Memory Capacity: 512MB onboard memory for data handling, logging and program storage
12. Isolation Performance: Channel-to-channel isolation, 1500V AC isolation voltage, excellent anti-interference performance

Advantages and Features

1. Cost-Effective Non-Redundant Solution: HONEYWELL SC-UCMX01 51307198-175 is designed for applications that do not require redundancy, providing a reliable and simple control solution while reducing the cost of system configuration, which is more economical than redundant controllers.
2. Flexible I/O Configuration: The 28-channel mixed I/O module can be flexibly configured for analog and digital signals, supporting multiple industrial signal types such as 4-20mA and 0-10V, which can meet the diverse monitoring and control needs of industrial sites without additional signal conversion modules.
3. Strong Communication Compatibility: It supports a variety of mainstream industrial communication protocols, such as Modbus, DNP3, and IEC 60870-5-101/104, and has dual Ethernet ports, which can realize seamless communication and data sharing with SCADA systems and third-party equipment, improving the integration and interoperability of the system.
4. Harsh Environment Adaptability: With a wide operating temperature range of -40°C to +70°C and excellent anti-electromagnetic interference performance, it can run stably for a long time in harsh industrial environments such as high temperature, low temperature, high humidity and strong vibration, ensuring the continuity and reliability of the production process.
5. Plug-and-Play & Easy Maintenance: The modular design and standard rail installation realize quick disassembly and assembly without professional tools, and the seamless integration with Honeywell’s original system reduces the time and difficulty of installation and commissioning, and greatly shortens the downtime of the production line during maintenance and replacement.
6. Original Quality Assurance: All components are selected from Honeywell’s designated original suppliers, manufactured in accordance with Honeywell’s strict industrial production standards, and have passed multiple reliability tests such as high and low temperature cycle, vibration and electromagnetic compatibility, with low failure rate and long service life.

Application Fields and Application Cases

Core Application Fields

Typical Application Cases

1. A European power distribution company: The substation monitoring system uses Honeywell SCADA for control. The original controller failed, resulting in inaccurate data acquisition and unstable control. After replacing HONEYWELL SC-UCMX01 51307198-175, the system’s data acquisition accuracy and real-time performance were restored, and the anti-interference ability was significantly improved. The system has been operating without fault for more than 9,000 hours, completely solving the problem of parameter drift caused by the use of general alternative controllers.
2. A North American chemical plant: In the upgrade of the reactor temperature and pressure control system, HONEYWELL SC-UCMX01 51307198-175 was adopted in batches as the core controller. It perfectly matches the original Honeywell PLC system, realizing multi-range signal acquisition and real-time control. The installation and commissioning cycle is shortened by 60% compared with using general spare parts, and the monitoring accuracy of temperature and pressure parameters is increased by 25%.
3. An Asian water treatment plant: The plant’s sewage treatment process monitoring system uses Honeywell automation equipment. After selecting HONEYWELL SC-UCMX01 51307198-175 to replace the old controller, the module’s excellent environmental adaptability and communication compatibility effectively solved the problems of signal interference and data loss in the harsh working environment of the sewage treatment plant. The data monitoring stability was greatly improved, and the sewage treatment efficiency was increased by 12%.

Comparison with Competing Products

Selection Suggestions and Precautions

Selection Suggestions

1. If the on-site automation control system is Honeywell’s original Experion SCADA or PLC system and does not require redundant configuration, HONEYWELL SC-UCMX01 51307198-175 is the first choice to avoid compatibility problems such as parameter drift and communication failure of general controllers, and ensure the stability of signal acquisition and control.
2. For industrial scenes with diverse signal types and flexible I/O configuration requirements (such as chemical reactor monitoring, water treatment process control), select HONEYWELL SC-UCMX01 51307198-175 for its 28-channel mixed I/O and multi-range configurable features, which can meet the complex monitoring and control needs of the process.
3. For harsh industrial working conditions such as extreme high and low temperature, strong electromagnetic interference and high humidity, priority is given to HONEYWELL SC-UCMX01 51307198-175 with excellent environmental adaptability to ensure long-term stable operation of the equipment.

Precautions

1. Before installation and commissioning, carefully read the original installation manual of HONEYWELL SC-UCMX01 51307198-175, and strictly follow the manual requirements for wiring and module installation. Cut off the on-site power supply before plugging and unplugging the module to avoid burning the module or damaging the control system due to live operation.
2. When configuring the module, set the corresponding I/O signal type and range on the Honeywell original configuration software according to the on-site actual signal requirements, and do not modify the original system parameters at will to avoid system misoperation.
3. In daily maintenance, regularly clean the dust and dirt on the surface and pin contact of HONEYWELL SC-UCMX01 51307198-175. Cut off the power supply and use dry and dust-free compressed air to purge during cleaning to avoid poor contact caused by dust accumulation.
4. When storing spare parts, place HONEYWELL SC-UCMX01 51307198-175 in a dry, normal temperature, electromagnetic interference-free environment. The storage temperature is controlled at 0°C ~ +35°C, and the relative humidity is ≤70% to avoid aging of electronic components and oxidation of pins.
5. After replacing the module, carry out system no-load commissioning and signal calibration in turn, confirm that the signal acquisition value is consistent with the actual field value and there is no drift, and then carry out on-load operation to ensure the normal operation of the control system.
6. It is strictly forbidden to use HONEYWELL SC-UCMX01 51307198-175 beyond the rated voltage, temperature and humidity parameter ranges, otherwise it will cause permanent damage to the module and reduce the service life of the module.
7. Do not disassemble the shell of HONEYWELL SC-UCMX01 51307198-175 without authorization, otherwise it will cause the failure of the original quality assurance and easily lead to internal circuit damage of the module.
