HONEYWELL CC-PAOX01

HONEYWELL CC-PAOX01 is a non-HART analog output module from Honeywell Series C, designed to convert digital signals from controllers like the C300 into precise 4–20mA current signals for driving industrial actuators. HONEYWELL CC-PAOX01 features 16 independent channels that can be individually configured, enabling simultaneous control of multiple devices such as control valves and frequency converters in complex process systems. HONEYWELL CC-PAOX01 delivers ±0.5% full-scale accuracy and 12-bit resolution, ensuring consistent performance for critical parameters like temperature and pressure.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

Product Description

HONEYWELL CC-PAOX01 is a non-HART analog output module from Honeywell Series C, designed to convert digital signals from controllers like the C300 into precise 4–20mA current signals for driving industrial actuators. HONEYWELL CC-PAOX01 features 16 independent channels that can be individually configured, enabling simultaneous control of multiple devices such as control valves and frequency converters in complex process systems. HONEYWELL CC-PAOX01 delivers ±0.5% full-scale accuracy and 12-bit resolution, ensuring consistent performance for critical parameters like temperature and pressure. HONEYWELL CC-PAOX01 incorporates 2500VDC isolation between channels and the system, effectively resisting electromagnetic interference in harsh industrial environments. HONEYWELL CC-PAOX01 operates from -40°C to 85°C, making it suitable for extreme settings from desert factories to cold-region facilities. HONEYWELL CC-PAOX01 seamlessly integrates with Honeywell Experion PKS systems, supporting remote configuration and diagnostics via Control Builder software.

Product Parameters

Parameter Details
Module Type Non-HART Analog Output Module (HONEYWELL CC-PAOX01)
Core Function Digital-to-analog conversion; 4–20mA output; multi-channel control; high isolation; Experion PKS integration
Compatible Systems Honeywell C300 controllers; Experion PKS systems; industrial process control setups
Channel Count 16 independent analog output channels
Output Signal 4–20mA DC current
Accuracy ±0.5% full-scale
Resolution 12-bit
Isolation Voltage 2500VDC (channel-to-channel, channel-to-system)
Power Supply 24V DC
Operating Temperature -40°C to 85°C
Dimensions 152mm × 152mm × 25.4mm
Weight Approximately 0.554kg
Compliance Industrial automation standards for process control modules

Advantages and Features

  1. 16 Independent Channels: HONEYWELL CC-PAOX01 controls multiple devices simultaneously, reducing rack space usage by 50% compared to single-channel modules.
  2. High Precision & Isolation: ±0.5% accuracy and 2500VDC isolation ensure signal stability and resist electromagnetic interference in harsh environments.
  3. Ultra-Wide Temperature Range: -40°C to 85°C operation eliminates the need for additional temperature control measures in extreme conditions.
  4. Seamless System Integration: Works natively with Experion PKS and C300 controllers for easy remote configuration and diagnostics.
  5. Compact & Reliable Design: Industrial-grade components and compact form factor suit tight installation spaces and ensure long-term durability.
  6. Flexible Configuration: Individual channel setup adapts to diverse actuator types and process requirements.

Application Cases in Application Fields

  • Petrochemical Distillation Control: HONEYWELL CC-PAOX01 controlled 12 调节阀 (control valves) in a distillation tower, maintaining ±0.5% pressure accuracy via 4–20mA signals and avoiding a 6-hour production outage worth ~$250k.
  • Pharmaceutical Reactor Regulation: It provided precise current signals for 8 reactor temperature control actuators, ensuring compliance with GMP standards and reducing product defect rates by 30%.
  • Power Plant Boiler Control: HONEYWELL CC-PAOX01 adjusted fuel flow and air intake via 16 channels, optimizing combustion efficiency and cutting energy consumption by 8%.
  • Wastewater Treatment: It controlled chemical dosing pumps and valve actuators, delivering accurate 4–20mA signals to maintain optimal treatment conditions and ensure effluent compliance.

Comparisons with Competing Products

Parameter HONEYWELL CC-PAOX01 Siemens SM 332 (6ES7332-5HF00-0AB0) ABB AI810
Module Type Non-HART analog output module Analog output module Analog input/output module
Channel Count 16 8 8
Output Signal 4–20mA DC 4–20mA DC 4–20mA DC
Accuracy ±0.5% full-scale ±0.3% full-scale ±0.1% full-scale
Isolation Voltage 2500VDC 500VAC 1000VAC
Operating Temperature -40°C to 85°C 0°C to 60°C -25°C to 60°C
Native Integration Honeywell Experion PKS/C300 Siemens TIA Portal ABB Control Builder Plus

Selection Suggestions and Precautions

Selection Suggestions

  • Choose HONEYWELL CC-PAOX01 for Experion PKS/C300 systems needing 16-channel 4–20mA output with high isolation and wide temperature tolerance.
  • Prioritize it for petrochemical, pharmaceutical, or power applications requiring precise multi-point process control.

Precautions

  • Use Control Builder software to configure channel parameters and verify compatibility with target actuators for HONEYWELL CC-PAOX01.
  • Ensure 24V DC power supply stability to maintain ±0.5% output accuracy for HONEYWELL CC-PAOX01.
  • Use shielded cables for field wiring to minimize interference with HONEYWELL CC-PAOX01 signal outputs.
  • Follow static protection procedures during installation to avoid damaging the module’s internal components.
  • Regularly check isolation integrity and output accuracy to ensure reliable operation of HONEYWELL CC-PAOX01.
