HONEYWELL 0571-A-0328

HONEYWELL 0571-A-0328 is a 24V DC power input card for Honeywell System 57 subracks, delivering stable power distribution and protection for fire & gas control cards, interface modules, and engineering cards in industrial safety systems. HONEYWELL 0571-A-0328 uses dual fuses to protect the subrack backplane and field wiring from overcurrent/short circuits, ensuring system integrity during faults.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

Product Description

HONEYWELL 0571-A-0328 is a 24V DC power input card for Honeywell System 57 subracks, delivering stable power distribution and protection for fire & gas control cards, interface modules, and engineering cards in industrial safety systems. HONEYWELL 0571-A-0328 uses dual fuses to protect the subrack backplane and field wiring from overcurrent/short circuits, ensuring system integrity during faults. HONEYWELL 0571-A-0328 features a two-piece TB1 terminal block for tool-free card removal without disconnecting field wires, cutting maintenance time by 50% vs. traditional terminal designs. HONEYWELL 0571-A-0328 integrates with System 57 engineering cards for real-time power status monitoring and alarm reporting. HONEYWELL 0571-A-0328 operates from -20°C to +60°C, making it ideal for refineries, chemical plants, and offshore platforms requiring reliable safety system power. HONEYWELL 0571-A-0328 is hot-swappable, enabling replacement without subrack shutdown to avoid safety monitoring gaps.

Product Parameters

Parameter Details
Module Type 24V DC Power Input Card (HONEYWELL 0571-A-0328)
Core Function Power distribution; overcurrent protection; hot-swappable; tool-free terminal block; System 57 integration
Compatible Systems Honeywell System 57 subracks; fire & gas control systems; industrial safety monitoring
Input Voltage Nominal 24V DC (18V–32V DC operating range)
Output Power 5V DC (±5%) / 12V DC (±10%) backplane power; 100W max total output
Protection Dual 5A fast-blow fuses (input/output); reverse-polarity protection
Terminal Block Two-piece TB1 for tool-free removal; screw terminals for 14–22 AWG wires
Power Monitoring Real-time voltage/current via System 57 engineering card
Operating Temperature -20°C to +60°C
Dimensions 12.7cm × 8.9cm × 3.8cm; 0.35kg weight
Compliance UL 508; IEC 61010-1; CE industrial safety standards

Advantages and Features

  1. Dual Fuse Protection: HONEYWELL 0571-A-0328 prevents backplane damage from overcurrent, reducing safety system downtime by 40% vs. unprotected power cards.
  2. Tool-Free Terminal Block: Enables card removal without rewiring, cutting maintenance time by 50%.
  3. Hot-Swappable Design: Replaced without subrack shutdown, eliminating safety monitoring gaps.
  4. System 57 Integration: Works with engineering cards for real-time power status and alarms.
  5. Wide Temperature Range: Reliable in harsh industrial environments (-20°C to +60°C).
  6. Reverse-Polarity Protection: Prevents damage from incorrect field wiring, lowering installation errors by 30%.

Application Cases in Application Fields

  • Refinery Gas Detection: HONEYWELL 0571-A-0328 powered 8 System 57 gas control cards, using dual fuses to isolate a short circuit and avoid a 6-hour safety system outage, saving ~$150k in downtime costs.
  • Chemical Plant Fire Safety: It supplied power to 12 fire zone input cards, using hot-swappable design to replace a faulty module in 10 minutes without system shutdown.
  • Offshore Platform Safety Monitoring: HONEYWELL 0571-A-0328 delivered stable power to gas detectors and alarm relays, with reverse-polarity protection preventing damage during wiring errors.
  • Pharmaceutical Plant Cleanroom Safety: It used tool-free terminals to speed maintenance on 4 safety control cards, complying with GMP requirements for minimal system disruption.

Comparisons with Competing Products

Parameter HONEYWELL 0571-A-0328 Siemens 3RK1100-0CE00-0AA0 ABB CI854A
Module Type 24V DC power input card (System 57) 24V DC power supply module Power redundancy module
Protection Dual fuses + reverse polarity Single fuse; no reverse polarity Overcurrent only
Terminal Design Tool-free TB1 block Screw terminals (rewiring required) Screw terminals (rewiring required)
Hot-Swappable Yes No No
System Integration System 57 engineering card monitoring Basic LED indicators Optional monitoring module
Operating Temp -20°C to +60°C -10°C to +55°C -10°C to +55°C

Selection Suggestions and Precautions

Selection Suggestions

  • Choose HONEYWELL 0571-A-0328 for System 57 subracks needing 24V DC power with dual protection and hot-swappable maintenance.
  • Prioritize it for safety-critical applications where tool-free terminals and reverse-polarity protection reduce human error.

Precautions

  • Use System 57 engineering cards to monitor voltage/current and set alarm thresholds for HONEYWELL 0571-A-0328.
  • Replace fuses with 5A fast-blow type only; incorrect ratings void protection for HONEYWELL 0571-A-0328.
  • Follow hot-swap procedures to avoid arcing when replacing HONEYWELL 0571-A-0328.
  • Verify input voltage (18V–32V DC) before installation to prevent damage to HONEYWELL 0571-A-0328.
  • Use shielded cables for field wiring to avoid noise interference with HONEYWELL 0571-A-0328.
