HITACHI LPU100A

Description

Product Description

Product Parameters

1. Product Type: Industrial grade PLC dedicated power supply module, multi-channel stable power supply spare part
2. Input Voltage: AC 100-240V (wide voltage input), 50/60Hz universal frequency
3. Output Voltage: DC 24V±1% (main output), DC 5V±1% (auxiliary output)
4. Output Current: 24V/4A, 5V/2A, total output power 100W
5. Conversion Efficiency: ≥92%, high-efficiency energy-saving design
6. Protection Functions: Overvoltage, overcurrent, short circuit, overheating, reverse connection protection (five-fold protection)
7. Operating Temperature Range: -20℃~+70℃, wide temperature industrial adaptation
8. Protection Grade: IP20 (cabinet installation grade), dustproof and anti-touch
9. Installation Method: 35mm standard DIN rail card installation, native support for hot swap
10. Ripple and Noise: ≤50mVp-p, low ripple stable power supply
11. Start-up Time: ≤100ms, fast power supply response
12. Electromagnetic Compatibility: Complies with IEC 61000-6-2/61000-6-4 industrial EMC standards
13. Power Factor: ≥0.95, high power factor energy saving
14. Design Service Life: Continuous operation ≥80,000 hours, industrial-grade long life
15. Working Humidity: 5%~95%RH (non-condensing), high humidity adaptability

Advantages and Features

1. Wide voltage input, strong grid adaptability: HITACHI LPU100A supports AC 100-240V wide voltage input and 50/60Hz universal frequency, which can adapt to unstable grid voltage in different industrial regions and countries, without additional voltage regulator configuration, and has strong on-site adaptability.
2. Five-fold protection, ultra-high power supply safety: Equipped with overvoltage, overcurrent, short circuit, overheating and reverse connection five-fold protection functions, HITACHI LPU100A can automatically cut off the power supply and protect the module and connected PLC equipment when an abnormality occurs, avoiding equipment damage caused by power supply faults and ensuring the safety of the entire industrial control system.
3. High efficiency and low ripple, stable power supply quality: With conversion efficiency ≥92% and ripple noise ≤50mVp-p, HITACHI LPU100A not only realizes industrial energy saving and reduces the overall power consumption of the control cabinet, but also provides low-ripple and high-stability DC power supply, avoiding signal interference of PLC modules caused by power supply ripple and ensuring the stable operation of the control system.
4. Hot swap design, efficient operation and maintenance: Native support for live hot swap operation, HITACHI LPU100A can complete module replacement and fault handling without cutting off the power supply of the control cabinet, avoiding production losses caused by system downtime, and is especially suitable for industrial scenarios with high requirements for continuous operation.
5. Dual output channel, multi-device power supply: With DC 24V/4A main output and DC 5V/2A auxiliary output, HITACHI LPU100A can provide stable power supply for PLC main control units, input/output modules, sensors and other peripheral devices at the same time, realizing one-module multi-purpose and simplifying the power supply structure of the control cabinet.
6. Seamless matching with Hitachi PLC, high integration efficiency: As a dedicated power supply module for Hitachi’s EH, H and L series PLC, HITACHI LPU100A is natively compatible with Hitachi’s full range of PLC controllers, with plug-and-play access and no complex parameter setting, greatly shortening the system integration and commissioning cycle.
7. Industrial-grade reliable design, strong environmental adaptability: Adopting industrial-grade high-quality components and anti-interference circuit design, HITACHI LPU100A can stably operate in the environment of -20℃~+70℃ and 5%~95%RH non-condensing humidity, with excellent anti-surge and anti-electromagnetic interference performance, and can adapt to various complex industrial on-site environments.

Application Fields and Application Cases

Core Application Fields

Typical Application Cases

1. Intelligent Manufacturing Industry: In the automated assembly line of a precision hardware manufacturing factory, HITACHI LPU100A was adopted as the core power supply module to provide stable power supply for Hitachi H series PLC, digital input/output modules and proximity sensors. Its low ripple power supply characteristic avoided signal interference of the PLC system, and the five-fold protection function prevented equipment damage caused by grid surge, ensuring the continuous and stable operation of the assembly line and improving the production efficiency by 12%.
2. Automotive Manufacturing Industry: In the auto parts stamping production line of a domestic automobile parts factory, HITACHI LPU100A was used to supply power for the PLC control system and stamping equipment detection sensors. Its wide voltage input design adapted to the unstable grid voltage of the factory workshop, and the hot swap design realized non-stop maintenance of the power supply module, reducing the production line downtime rate by 20% and improving the production capacity of the workshop.
3. Water Treatment Industry: In the automatic control system of a municipal sewage treatment plant, HITACHI LPU100A was adopted to provide power for the PLC main control unit, flow sensors and valve control modules in the control cabinet. Its wide temperature adaptability adapted to the temperature change of the sewage treatment plant’s outdoor control cabinet, and the high humidity adaptability realized stable operation in the high-humidity environment of the plant, ensuring the normal operation of the sewage treatment process and improving the automation level of the plant.
4. Packaging Machinery Industry: In the automatic packaging production line of a large food enterprise, HITACHI LPU100A was used to supply power for the PLC control system, photoelectric sensors and packaging machine execution components. Its dual output channel realized one-module power supply for multiple devices, simplifying the power supply wiring of the control cabinet, and the high conversion efficiency reduced the energy consumption of the production line, saving the enterprise’s electricity cost by about 8% every year.

Comparison with Competing Products

Selection Suggestions

1. Priority selection for Hitachi PLC system: If the on-site industrial control system is built with Hitachi EH, H and L series PLC controllers, HITACHI LPU100A is the first choice, with plug-and-play native compatibility, avoiding power supply adaptation problems and improving the integration efficiency of the control system.
2. Selection for unstable grid voltage scenarios: For industrial sites with unstable grid voltage such as factory workshops, construction sites and remote industrial areas, HITACHI LPU100A with AC 100-240V wide voltage input is selected to adapt to voltage fluctuations without additional voltage regulator configuration.
3. Priority selection for continuous operation industrial scenarios: For food and beverage, water treatment and other industrial fields that require 24/7 continuous production, HITACHI LPU100A with hot swap function is selected to realize non-stop maintenance of the power supply module and reduce production losses caused by system downtime.
4. Selection for multi-device power supply scenarios: If the PLC control cabinet needs to supply power for multiple devices such as PLC main control unit, I/O modules and sensors at the same time, HITACHI LPU100A with DC 24V/5V dual output channels is selected to realize one-module multi-purpose and simplify the power supply structure of the control cabinet.
5. Priority selection for high-stability power supply demand scenarios: For precision manufacturing, automotive parts processing and other industrial scenarios with high requirements for PLC system operation stability, HITACHI LPU100A with low ripple (≤50mVp-p) and high-precision output voltage (±1%) is recommended to avoid signal interference caused by power supply ripple.
6. Selection for energy-saving operation demand scenarios: For enterprises pursuing energy-saving and emission reduction of industrial production lines, HITACHI LPU100A with conversion efficiency ≥92% and power factor ≥0.95 is selected to reduce the overall power consumption of the control cabinet and save the enterprise’s electricity cost.
7. Priority selection for small and medium-sized control system: HITACHI LPU100A with 100W rated output power and compact DIN rail installation design is the optimal choice for the power supply construction of small and medium-sized industrial automation control systems and distributed control cabinets, which can effectively save the installation space of the control cabinet.

Precautions

1. Installation Norms: HITACHI LPU100A is installed with 35mm standard DIN rail card, ensure the module is clamped firmly during installation, and keep a distance of ≥5cm from the surrounding high-power heating equipment to ensure good heat dissipation; the module is IP20 protection grade, must be installed inside the closed industrial control cabinet to avoid dust and water vapor intrusion.
2. Wiring Operation: Strictly distinguish the AC input terminal, DC 24V output terminal and DC 5V output terminal during wiring, and mark the wiring clearly; the input and output lines use copper core wires with appropriate cross-sectional area (≥1.5mm²), and the wiring terminals are tightened to avoid poor contact caused by heating.
3. Hot Swap Operation: Although hot swap is supported, it is necessary to cut off the load of the corresponding output channel first before plugging and unplugging the module to avoid damage to the module and connected equipment caused by instantaneous current impact; hold the module buckle when plugging and unplugging, and it is strictly forbidden to pull the power line directly.
4. Load Matching: The connected load power of the module shall not exceed the rated output power (100W) of HITACHI LPU100A, and the single-channel output current shall not exceed the rated current (24V/4A, 5V/2A) to avoid overloading and damage to the module.
5. Grounding Requirement: The module must be reliably grounded (ground resistance ≤4Ω), and the grounding wire uses copper core wire with cross-sectional area ≥2.5mm²; reliable grounding can effectively improve the anti-electromagnetic interference performance of the module and avoid static electricity damage.
6. Environmental Protection: Avoid placing the control cabinet with HITACHI LPU100A in a high-temperature, high-humidity, strong-vibration or corrosive gas environment; keep the control cabinet well-ventilated, and regularly clean the dust inside the cabinet to avoid dust accumulation affecting the module’s heat dissipation.
7. Fault Handling: When the module’s fault indicator light is on, cut off the input power supply in time and check the load circuit for short circuit, overcurrent and other abnormalities; do not disassemble the module by yourself for repair, and contact professional after-sales personnel for maintenance.
8. Parallel Use: HITACHI LPU100A does not support parallel use of multiple modules to increase output power, and parallel connection will cause mutual interference between modules and damage the equipment; if higher power supply is needed, select Hitachi’s high-power PLC power supply module of the same series.
9. Daily Maintenance: Regularly check the module’s running indicator lights (power light/normal light), wiring terminals and shell temperature during daily maintenance; if the indicator light is off, the terminal is loose or the temperature exceeds 70℃, stop the machine for troubleshooting immediately.
10. Storage and Transportation: Unused HITACHI LPU100A should be stored in a dry and ventilated environment with a temperature of -10℃~+40℃ and a humidity of ≤70%RH, avoiding direct sunlight, rain and violent collision; use shockproof and moisture-proof packaging during transportation, and protect the wiring terminals with insulating caps to avoid short circuit.
