GE+IC693DNM200

Description

The GE IC693DNM200 is part of General Electric’s Series 90-30 PLC (Programmable Logic Controller) family, specifically related to networking and communications.

Product Name:

• GE IC693DNM200 – GE Series 90-30 Ethernet Communications Module

Product Description:

The IC693DNM200 is an Ethernet communications module designed to provide networking capabilities for GE Fanuc Series 90-30 PLCs. It allows the PLC to communicate over Ethernet networks, supporting a variety of communication protocols. This module enables the PLC to be part of an Ethernet-based control system, allowing for remote diagnostics, program updates, data acquisition, and integration with other industrial devices.

This module is typically used in applications that require high-speed, reliable communication between PLCs or between PLCs and other networked devices such as HMIs, SCADA systems, or remote I/O.

Key Features:

• Ethernet Communication: Provides connectivity over Ethernet networks.
• Supports TCP/IP Protocol: Allows for communication with systems using TCP/IP protocol, which is standard in many industrial and IT environments.
• Integration with GE PLCs: Specifically designed for the GE Series 90-30 PLCs, but can also be used for communication with other GE PLCs when integrated into the network.
• Supports Multiple Protocols: Including Modbus TCP, which is a widely used protocol for industrial communication.
• Web Server Capability: Can serve web pages for basic monitoring and control functions.

Product Specifications:

• Part Number: IC693DNM200
• Module Type: Ethernet Communications Module
• Interface: Ethernet (RJ45)
• Protocols Supported:
  • TCP/IP (Transmission Control Protocol/Internet Protocol)
  • Modbus TCP (for industrial communication)
• Operating Voltage Range: 5V DC (from the PLC backplane)
• Power Consumption: Approximately 1W
• Data Rate: 10/100 Mbps Ethernet
• Connection Type: Standard RJ45 Ethernet connector
• LED Indicators: For power, network activity, and communication status
• Size: 1 slot in the GE Series 90-30 rack (about 2.4 inches wide)
• Temperature Range: 0°C to 60°C (32°F to 140°F) operating
• Humidity Range: 5% to 95% non-condensing

Product Use:

• PLC Networking: Allows GE Series 90-30 PLCs to communicate over Ethernet networks, enabling integration into larger, networked control systems.
• Remote Monitoring and Control: Facilitates remote access to the PLCs for monitoring, diagnostics, and control through Ethernet-based systems.
• Industrial Automation: Useful in automation systems where real-time data exchange is crucial, such as in manufacturing, energy management, and process control.
• SCADA Integration: Easily integrates with SCADA (Supervisory Control and Data Acquisition) systems, enabling remote monitoring and control of industrial processes.
• Data Collection: Enables data collection from remote sensors and actuators that are part of the Ethernet network.

Typical Applications:

• Factory Automation Systems
• Building Automation
• Industrial Networks (IoT)
• Distributed Control Systems (DCS)
• SCADA and HMI Systems

The GE IC693DNM200 is a vital component for enhancing communication capabilities in industrial automation systems, allowing users to leverage the full potential of Ethernet networks for remote control, monitoring, and data exchange.
