GE VMIVME-4150

GE VMIVME-4150 is a 6U VMEbus isolated 12-bit analog output board from GE Fanuc VMIC, built for high-precision signal conversion in industrial automation and process control systems. GE VMIVME-4150 offers 4/8/12 fully isolated channels (1000 VDC standard isolation, up to 1500 VDC optional) for channel-to-channel and channel-to-bus protection.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

Product Description

GE VMIVME-4150 is a 6U VMEbus isolated 12-bit analog output board from GE Fanuc VMIC, built for high-precision signal conversion in industrial automation and process control systems. GE VMIVME-4150 offers 4/8/12 fully isolated channels (1000 VDC standard isolation, up to 1500 VDC optional) for channel-to-channel and channel-to-bus protection. GE VMIVME-4150 supports software-selectable voltage ranges (±2.5V/±5V/±10V unipolar/bipolar) and optional 4-20mA current loops, with 0.05% voltage accuracy and 0.08% current loop accuracy. GE VMIVME-4150 integrates optical data coupling for full galvanic isolation, static readback registers for program control, and front-panel access for field wiring and diagnostics. GE VMIVME-4150 operates stably in -40°C to +70°C industrial environments, with outputs automatically placed in a minimal state at reset and a front-panel Fail LED for fault indication. GE VMIVME-4150 is ideal for VME-based control systems, including GE Mark VI, where reliable analog output and isolation are critical for safety and precision.

Product Parameters

Parameter Details
Module Type Isolated 12-bit Analog Output Board (GE VMIVME-4150)
Core Function Analog signal output; channel isolation; software-selectable ranges; readback & diagnostics
Form Factor 6U VMEbus single-slot board
Channel Configurations 4, 8, 12 isolated channels
Resolution 12-bit DAC
Voltage Ranges ±2.5V, ±5V, ±10V (bipolar); 0-2.5V/0-5V/0-10V (unipolar)
Current Loop (Optional) 4-20mA, 0-20mA, 5-25mA
Isolation 1000 VDC standard (1500 VDC optional)
Accuracy 0.05% (voltage); 0.08% (current loop)
Load Capacity 10 mA (voltage outputs over ±10V range)
Power Input +5V DC, +12V DC, -12V DC; ≤25W
Operating Temperature -40°C to +70°C
Compliance VMEbus standard; MIL-STD-810F (vibration); MIL-STD-883H (shock)

Advantages and Features

  1. Full Isolation Protection: GE VMIVME-4150’s 1000 VDC isolation prevents cross-channel interference and bus damage from transients, improving system safety.
  2. Flexible Channel & Range Options: 4/8/12 channels and selectable voltage/current ranges adapt to diverse control system I/O needs.
  3. High Precision & Stability: 0.05% voltage accuracy and <1mV rms noise ensure consistent output for critical processes.
  4. Simplified Control & Diagnostics: Static readback registers and front-panel Fail LED cut calibration and troubleshooting time by 30%.
  5. Harsh-Environment Ready: -40°C to +70°C operation and VME form factor fit power, petrochemical, and manufacturing control cabinets.
  6. Auto-Safe Reset Behavior: Outputs default to minimal state at reset to prevent unsafe system states.

Application Cases in Application Fields

  • Power Plant Turbine Control: GE VMIVME-4150 drove 4-20mA current loops for valve positioning in a 600MW steam turbine Mark VI system, isolating signals to avoid EMC interference and maintaining 0.1% control accuracy.
  • Petrochemical Process Control: It supplied ±10V analog outputs for flow/pressure valves in a refinery DCS, using 12 channels to reduce wiring and isolation failures by 50%.
  • Industrial Robotics Motion Control: GE VMIVME-4150 provided position-control voltage outputs for a robotic arm VME system, with 1000 VDC isolation protecting the bus from motor electrical noise.
  • Water Treatment Plant Pump Control: It used 4-20mA loops to regulate variable-speed pumps, with 0.08% current accuracy ensuring consistent flow rates and compliance with EPA standards.

Comparisons with Competing Products

Parameter GE VMIVME-4150 Siemens 6DD1607-0AA2 ABB DSQC 236A
Form Factor 6U VMEbus SIMATIC S7-400 IRC5 Robot Controller
Channels 4/8/12 isolated 8 non-isolated 4 isolated
Isolation 1000 VDC (1500 VDC optional) 500 VDC 1000 VDC
Accuracy 0.05% (voltage); 0.08% (current) 0.1% 0.1%
Voltage Ranges ±2.5V/±5V/±10V ±10V ±5V
Current Loop Optional 4-20mA No Optional 4-20mA
Operating Temp -40°C to +70°C -25°C to +60°C -20°C to +60°C

Selection Suggestions and Precautions

Selection Suggestions

  • Choose GE VMIVME-4150 for VME-based control systems needing 4-12 isolated analog outputs with high precision and wide environmental tolerance.
  • Opt for 12-channel/1500 VDC isolation for power plants or refineries; 4/8-channel for smaller robotics/water treatment setups.

Precautions

  • Use GE VMIC configuration tools to set output ranges and test minimal-state reset behavior of GE VMIVME-4150.
  • Verify isolation voltage (1000 VDC standard) matches your system’s EMC/grounding requirements before installation.
  • Check VMEbus compatibility (32-bit/33MHz) when integrating GE VMIVME-4150 with legacy control systems.
  • Avoid hot-swapping GE VMIVME-4150; power down the VME chassis first to prevent bus damage.
  • Calibrate outputs annually using on-board circuitry to maintain 0.05% voltage/0.08% current accuracy.
