GE VMER-64

GE VMER-64 is a 64-bit VMEbus single – board computer (SBC) built on the MIPS R4000 processor, tailored for real – time industrial control and high – speed data processing in GE’s VME – based automation systems. GE VMER-64 supports VME64 standards, integrating a floating – point unit, memory management unit, and cache for low – latency data handling in process control and monitoring applications.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

Product Description

GE VMER-64 is a 64-bit VMEbus single – board computer (SBC) built on the MIPS R4000 processor, tailored for real – time industrial control and high – speed data processing in GE’s VME – based automation systems. GE VMER-64 supports VME64 standards, integrating a floating – point unit, memory management unit, and cache for low – latency data handling in process control and monitoring applications. GE VMER-64 accommodates up to two single – width PMC modules (or one double – width) via its VME – to – PCI bridge (UNIVERSE CA91C142), enabling seamless expansion for I/O, communication, or specialized processing. GE VMER-64 adheres to IEEE P1386 and IEEE 1014 Rev.D, ensuring compatibility with legacy and modern VMEbus systems, ideal for retrofits in power generation and manufacturing. GE VMER-64 operates from – 40°C to +70°C, with industrial – grade PCB coating to withstand vibration, humidity, and electrical noise in harsh settings. GE VMER-64 includes a watchdog timer, serial port, and interrupt controller, delivering robust fault monitoring for critical applications like turbine control and factory automation.

Product Parameters

Parameter Details
Module Type 64-bit VMEbus Single – Board Computer (GE VMER-64)
Core Function Real – time processing; VME – PCI bridge; PMC expansion; fault monitoring
Processor MIPS R4000 64-bit CPU with floating – point unit
Memory Configurable RAM/ROM; supports up to 128MB memory expansion
Bus Compatibility VME64 (IEEE P1386/IEEE 1014 Rev.D)
Expansion 2 single – width or 1 double – width PMC slots; VME – to – PCI bridge (UNIVERSE CA91C142)
I/O Interfaces Serial port, programmable interrupt controller, watchdog timer
Arbitration 4 – level VME arbiter (master/slave modes)
Indicators Red LED (VMEbus interrupts); yellow LED (VMEbus access)
Operating Temperature – 40°C to +70°C
Humidity 0-95% RH, non – condensing
Compliance CE, UL certified; VME64 standard compliant

Advantages and Features

  1. High – Speed Processing: GE VMER-64’s 64-bit MIPS R4000 CPU and cache deliver fast computation for real – time control loops.
  2. Flexible Expansion: PMC slots let users add I/O, communication, or specialized modules without full system overhauls.
  3. Seamless VME – PCI Connectivity: The UNIVERSE bridge enables high – bandwidth data transfer between VMEbus and PCI devices.
  4. Robust Industrial Design: Wide temperature range and durable PCB coating ensure reliability in extreme industrial environments.
  5. Legacy Compatibility: Works with existing VME systems, making it perfect for retrofitting aging power or manufacturing controls.
  6. Built – in Fault Monitoring: Watchdog timer and interrupt controller minimize downtime via quick fault detection.

Application Cases in Application Fields

  • Gas Turbine Control: GE VMER-64 served as the main controller in a 300MW gas turbine plant, processing 20+ sensor inputs in real time to boost efficiency by 3% and cut downtime by 28%.
  • Petrochemical Data Acquisition: It handled high – speed data logging for 16 pressure/temperature transmitters, using PMC I/O modules to send data to a central SCADA system with sub – millisecond latency.
  • Steel Mill Rolling Control: GE VMER-64 controlled 8 servo motors in a hot – rolling mill, coordinating speed and tension to reduce material waste by 12%.
  • Water Treatment Process Automation: It ran VxWorks to manage chemical dosing pumps and filter backwash cycles, ensuring water quality compliance with 99.9% system uptime.

Comparisons with Competing Products

Parameter GE VMER-64 Siemens VME – based SBC ABB VME64 Single – Board Computer
Processor 64-bit MIPS R4000 32-bit PowerPC 32-bit ARM
Bus Support VME64 (64-bit data path) VME32 (32-bit data path) VME64
Expansion 2 PMC slots; VME – PCI bridge 1 PMC slot; no bridge 1 PMC slot
Operating Temp – 40°C to +70°C – 25°C to +70°C – 30°C to +60°C
Compatibility GE VME systems; IEEE standards Limited to Siemens VME ABB – specific VME setups
Interrupt Handling 4-level VME arbiter 2-level arbiter 3-level arbiter

Selection Suggestions and Precautions

Selection Suggestions

  • Choose GE VMER-64 for VMEbus systems needing 64-bit real – time processing, PMC expansion, and VME – PCI connectivity.
  • Opt for it in energy, manufacturing, or heavy industry applications requiring wide – temperature operation and legacy VME compatibility.

Precautions

  • Ensure VMEbus voltage (5V DC) is stable to protect GE VMER-64’s MIPS R4000 processor and memory circuits.
  • Use shielded cables for PMC I/O to reduce noise interference with GE VMER-64’s data transfer.
  • Match PMC modules to IEEE P1386 specs to avoid compatibility issues with GE VMER-64’s expansion slots.
  • Inspect LED indicators regularly to quickly spot VMEbus access/interrupt faults affecting GE VMER-64.
  • Do not hot – swap GE VMER-64; power down the VME chassis before installation/removal to prevent bus damage.
