GE IS420UCSCH1A

GE IS420UCSCH1A is a quad – core UCSC controller module in GE’s Mark VIe system, powered by a 1.2GHz AMD G – Series CPU and QNX Neutrino OS, tailored for TMR/simplex/dual – redundant control in power generation and heavy – duty industrial automation.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

Product Description

GE IS420UCSCH1A is a quad – core UCSC controller module in GE’s Mark VIe system, powered by a 1.2GHz AMD G – Series CPU and QNX Neutrino OS, tailored for TMR/simplex/dual – redundant control in power generation and heavy – duty industrial automation. GE IS420UCSCH1A supports IONet for seamless I/O pack integration, with 2 Hall – effect pulse inputs, 2 analog inputs, and 4 DIOs to handle diverse field signals for turbine speed, temperature, and valve positioning. GE IS420UCSCH1A features dual redundant Ethernet ports (10/100Mbps, IONet/Modbus TCP/Ethernet/IP) and an Embedded Field Agent (EFA) for Predix cloud connectivity, enabling real – time remote monitoring and predictive maintenance. It has 4GB non – volatile flash and 2GB DDR3 RAM, with fanless operation and a wide – range 24VDC power supply (±10%) for high reliability in harsh industrial sites. GE IS420UCSCH1A offers SIL3 compliance for safety – critical loops and an MTBF of 414,248 hours at 30°C, minimizing unplanned downtime. GE IS420UCSCH1A fits Mark VIe compact chassis, with front – panel LEDs for power, status, and I/O health, simplifying on – site diagnostics and reducing troubleshooting time.

Product Parameters

Parameter Details
Module Type Mark VIe UCSC Compact Stand – Alone Controller (GE IS420UCSCH1A)
Core Function TMR/simplex/dual – redundant control; IONet I/O integration; cloud – connected data acquisition
Processor Quad – core 1.2GHz AMD G – Series
Operating System QNX Neutrino
Memory 2GB DDR3 RAM; 4GB non – volatile flash memory
I/O Interfaces 2 Hall – effect pulse inputs; 2 analog inputs (4–20mA); 4 DIOs (24VDC)
Communication Dual redundant 10/100Mbps Ethernet (IONet/Modbus TCP/Ethernet/IP); 1 USB 2.0; 1 RJ – 45 console
Redundancy TMR, Simplex, Dual modes supported
Certifications SIL3 compliant; IEC 61508 certified; CE, UL compliant
Power Supply 24VDC (±10%); max power ≤15W
MTBF (30°C) 414,248 Hours
Operating Temperature 0°C to 50°C
Storage Temperature – 40°C to 85°C
Weight 1.33 kg
Form Factor Mark VIe compact chassis – mount; 22cm×18cm×6cm
Diagnostics Front – panel LEDs (power, status, I/O, communication)
EFA Support Embedded Field Agent for Predix cloud connectivity

Advantages and Features

  1. Quad – Core + QNX OS: GE IS420UCSCH1A delivers fast, stable control for complex algorithms in turbine and process loops, with QNX ensuring real – time response and fault tolerance.
  2. Multi – Redundancy Modes: Native TMR/simplex/dual support meets safety – critical needs in power generation and oil/gas refining.
  3. IONet & Cloud Connectivity: Dual Ethernet enables IONet I/O linking; EFA on GE IS420UCSCH1A connects to Predix for predictive maintenance and remote monitoring.
  4. SIL3 Compliance & High MTBF: SIL3 certification and 414,248 – hour MTBF at 30°C maximize uptime in safety – critical systems.
  5. Integrated I/O & Fanless Design: Built – in I/O ports reduce extra hardware costs; fanless operation lowers maintenance and failure risks.
  6. Simplified Diagnostics: Front – panel LEDs on GE IS420UCSCH1A speed up power, status, and I/O fault identification.

Application Cases in Application Fields

  • Gas Turbine Control: GE IS420UCSCH1A used TMR mode to manage a 60MW gas turbine’s fuel flow and speed regulation, with IONet linking 12 I/O packs for 10ms – fast control response and 99.97% uptime.
  • Steam Turbine Auxiliary Systems: It handled 8 analog loops (pressure, temperature) and 16 DIOs for feedwater pumps, using dual Ethernet for redundant SCADA communication and Predix – based vibration monitoring, cutting maintenance costs by 25%.
  • Oil Refinery Compressor Control: GE IS420UCSCH1A ran dual – redundant control for a 10,000 – rpm centrifugal compressor, with EFA streaming vibration data to the cloud for anomaly detection and 30% fewer unplanned shutdowns.
  • Chemical Plant Batch Process: It coordinated 20+ I/O modules via IONet for recipe – driven mixing control, with SIL3 compliance ensuring safe operation during hazardous material handling and 99.8% batch consistency.

Comparisons with Competing Products

Parameter GE IS420UCSCH1A Siemens S7 – 400 CPU 417 – 4 PN/DP ABB AC800M CPU 800A
Core Redundancy Native TMR/simplex/dual (Mark VIe) Requires separate S7 – 400H hardware Requires separate ABB 800xA redundancy modules
Processor Quad – core 1.2GHz AMD G – Series Dual – core 1.4GHz Intel Core i7 Dual – core 800MHz ARM Cortex – A8
OS QNX Neutrino (real – time, fault – tolerant) Siemens proprietary RTOS ABB proprietary RTOS
IONet Compatibility Native Mark VIe IONet integration No IONet support No IONet support
Cloud Connectivity Built – in EFA for Predix Requires extra Siemens MindSphere gateway Requires extra ABB Ability gateway
SIL Certification SIL3 compliant (native) SIL3 with extra safety modules SIL3 with extra safety modules
MTBF (30°C) 414,248 Hours 350,000 Hours 380,000 Hours
Cost – Effectiveness High (native redundancy, built – in I/O, cloud – ready) Medium (needs extra H hardware for redundancy) Medium (proprietary ecosystem premium)

Selection Suggestions and Precautions

Selection Suggestions

  • Choose GE IS420UCSCH1A for Mark VIe systems needing TMR/simplex/dual – redundant control in power generation, oil/gas, or chemical applications requiring SIL3 compliance.
  • Prefer it for projects needing IONet I/O integration, Predix cloud connectivity, and embedded I/O to reduce hardware count.

Precautions

  • Pair GE IS420UCSCH1A with compatible Mark VIe power supplies and IONet I/O packs to avoid hardware mismatches.
  • Ensure GE IS420UCSCH1A operates within 0°C–50°C and uses shielded Ethernet cables to prevent signal interference.
  • Follow GE’s redundancy setup guidelines when configuring GE IS420UCSCH1A for TMR/dual mode to ensure fault – tolerant operation.
  • Update GE IS420UCSCH1A firmware via USB or Ethernet only with GE – approved files to avoid system corruption.
