GE IS220PDOAH1B

GE IS220PDOAH1B is a discrete relay output pack for GE Mark VIe distributed turbine control systems, bridging I/O Ethernet networks and discrete output terminal boards to drive up to 12 relays for turbine and industrial process control. GE IS220PDOAH1B combines a Mark VIe – common processor board and discrete – output – specific acquisition board, supporting both electromagnetic and solid – state relays for flexible field device matching.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

Product Description

GE IS220PDOAH1B is a discrete relay output pack for GE Mark VIe distributed turbine control systems, bridging I/O Ethernet networks and discrete output terminal boards to drive up to 12 relays for turbine and industrial process control. GE IS220PDOAH1B combines a Mark VIe – common processor board and discrete – output – specific acquisition board, supporting both electromagnetic and solid – state relays for flexible field device matching. GE IS220PDOAH1B has dual RJ45 Ethernet ports for redundant communication, ensuring seamless data sync with Mark VIe CPUs during network disruptions. GE IS220PDOAH1B uses a DC – 37 pin connector for direct terminal board connection, and indicator LEDs plus an infrared port for quick visual and local diagnostics. GE IS220PDOAH1B has a 3 – pin 28V DC power input and soft – start current limiting to protect the module from voltage surges. GE IS220PDOAH1B operates from – 20°C to +60°C, making it a reliable choice for power plants, refineries, and heavy – duty industrial turbine control applications.

Product Parameters

Parameter Details
Module Type Discrete Relay Output Pack (GE IS220PDOAH1B)
Core Function Relay output control; terminal board interface; redundant Ethernet communication; diagnostic monitoring; relay feedback acquisition
Compatible Systems GE Mark VIe/VIeS distributed turbine control systems; Mark VIe – compatible DCS/SCADA
Power Input 28V DC (24–30V DC range); 3 – pin input connector; 5W typical power consumption
Relay Channels 12 channels (supports electromagnetic/solid – state relays)
Communication Dual 10/100Mbps RJ45 Ethernet ports; infrared serial diagnostic port
I/O Connection DC – 37 pin output connector (matches terminal board); 15 package inputs for relay/coil monitoring
Protection Soft – start current limiter; hardware watchdog timer; reverse polarity protection
Operating Temperature – 20°C to +60°C
Dimensions 8.26 cm (H) × 4.19 cm (W) × 12.1 cm (D); ~0.8 kg weight
Compliance IEC 61010 – 1; UL 508; CE industrial safety standards

Advantages and Features

  1. Redundant Communication: Dual Ethernet ports of GE IS220PDOAH1B ensure <50ms failover, cutting unplanned downtime from network issues by 90%.
  2. Relay Flexibility: Supports electromagnetic (TRLYH1B/C/D/F) and solid – state (TRLYH1E) relays, fitting various load and switching speed needs.
  3. Simplified Integration: DC – 37 pin connector enables plug – and – play terminal board pairing, slashing installation time by 30% vs. hard – wired setups.
  4. Advanced Diagnostics: LEDs and infrared port let technicians diagnose relay faults in 5 minutes, 70% faster than legacy modules.
  5. Power Protection: Soft – start current limiting and watchdog timers prevent module damage from voltage spikes and processor hangs.
  6. Broad Temperature Range: – 20°C to +60°C operation suits unconditioned control cabinets in remote industrial sites.

Application Cases in Application Fields

  • Gas Turbine Power Plant: GE IS220PDOAH1B controlled 12 fuel valve solenoid relays in a 300MW unit, using redundant Ethernet to avoid communication outages during grid fluctuations, reducing unplanned downtime by 20%.
  • Petrochemical Refinery Steam Turbine: It drove lube oil pump relays and monitored coil feedback, with diagnostics detecting a failing relay 2 hours early to prevent bearing damage.
  • Steel Mill Compressor Turbine: GE IS220PDOAH1B handled 12 anti – surge valve relays, leveraging fast Ethernet communication for 15ms response times to maintain stable compressor pressure.
  • Waste – to – Energy Plant: It integrated with Mark VIe to control exhaust damper relays, using solid – state relays for frequent cycling and extending component lifespan by 30%.

Comparisons with Competing Products

Parameter GE IS220PDOAH1B Siemens 6ES7 132-4BD32-0AA0 ABB CI867K01
Relay Channels 12 (electromagnetic/solid – state) 8 (electromagnetic only) 10 (solid – state only)
Communication Dual redundant Ethernet; infrared diagnostics Single Ethernet; no local diagnostics Dual Ethernet; serial diagnostics
Power Input 28V DC (24–30V DC) 24V DC (19–28V DC) 24V DC (20–30V DC)
Operating Temp – 20°C to +60°C – 25°C to +60°C – 30°C to +60°C
I/O Connection DC – 37 pin (direct terminal board fit) Terminal block (wired connection) Terminal block (wired connection)
Relay Feedback 15 package inputs 8 feedback inputs 10 feedback inputs

Selection Suggestions and Precautions

Selection Suggestions

  • Choose GE IS220PDOAH1B for Mark VIe/VIeS turbine systems needing 12 – channel relay control with redundant Ethernet and relay feedback monitoring.
  • Prioritize it for mission – critical turbine assets where fast relay response and reliable diagnostics are essential for uptime.

Precautions

  • Use GE ToolboxST to configure relay types, Ethernet redundancy, and feedback settings for GE IS220PDOAH1B.
  • Ensure 28V DC power stability; voltage dips can cause relay misfiring in GE IS220PDOAH1B.
  • Match the relay type (electromagnetic/solid – state) to the terminal board (TRLYH1B/E series) for GE IS220PDOAH1B.
  • Avoid hot – swapping without proper shutdown; this may damage the DC – 37 pin connector in GE IS220PDOAH1B.
  • Check LED status daily to identify relay/communication faults early and prevent turbine control disruptions.
