GE IS200ERDDH1ABA

GE IS200ERDDH1ABA is an IGBT Exciter Regulator/Dynamic Discharge Card from GE’s EX2100 series, designed for Mark VI Speedtronic turbine control systems to manage field excitation and protect generators in gas, steam, and wind turbine applications. GE IS200ERDDH1ABA regulates field currents via gate drive control and enables dynamic discharge of excess DC-link voltage, preventing overvoltage damage to critical turbine components. GE IS200ERDDH1ABA supports both simplex and redundant operation modes, offering flexibility for standard and safety-critical setups requiring maximum uptime.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

Product Description

GE IS200ERDDH1ABA is an IGBT Exciter Regulator/Dynamic Discharge Card from GE’s EX2100 series, designed for Mark VI Speedtronic turbine control systems to manage field excitation and protect generators in gas, steam, and wind turbine applications. GE IS200ERDDH1ABA regulates field currents via gate drive control and enables dynamic discharge of excess DC-link voltage, preventing overvoltage damage to critical turbine components. GE IS200ERDDH1ABA supports both simplex and redundant operation modes, offering flexibility for standard and safety-critical setups requiring maximum uptime. GE IS200ERDDH1ABA integrates comprehensive bridge feedback monitoring, tracking DC-link voltage, output current, field voltage, bridge temperature, and IGBT gate drive status for real-time system health insights. GE IS200ERDDH1ABA features a single-slot double-height (6U) form factor with P1/P2 backplane connectors, ensuring seamless integration with EX2100 excitation platforms and Mark VI controllers. GE IS200ERDDH1ABA operates reliably in extreme temperatures (-40°C to +85°C) with IP65 protection, making it suitable for power plants, oil refineries, and industrial turbine installations.

Product Parameters

Parameter Details
Module Type IGBT Exciter Regulator/Dynamic Discharge Card (GE IS200ERDDH1ABA)
Core Function Field excitation control; dynamic overvoltage discharge; bridge feedback monitoring; relay control
Compatible Systems GE Mark VI Speedtronic; EX2100 digital excitation platform
Operating Modes Simplex (single module) / Redundant (dual modules)
Power Supply 18-30V DC (control power); DC-link bus (dynamic discharge power)
Maximum Discharge Power 200 kW
Maximum Discharge Voltage 0-1200V DC
Maximum Discharge Current 400 A
Communication Interfaces RS-232, RS-485, CAN bus, Ethernet
Monitoring Parameters DC-link voltage, output shunt current, field voltage, bridge temperature, IGBT status
Form Factor Single-slot, double-height (6U)
Connectors P1/P2 backplane connectors; 7 interfacing board connectors
Operating Temperature -40°C to +85°C
Storage Temperature -40°C to +85°C
Protection Rating IP65
Dimensions 100mm × 50mm × 30mm
Power Consumption 5W
Compliance Industrial safety standards (CE, UL compliant)

Advantages and Features

  1. Dual Operational Modes: GE IS200ERDDH1ABA supports simplex and redundant setups, adapting to both standard and safety-critical applications.
  2. Rapid Overvoltage Protection: Millisecond-level dynamic discharge response on GE IS200ERDDH1ABA prevents turbine damage from excess DC-link voltage.
  3. Comprehensive Monitoring: It tracks key operational parameters, enabling predictive maintenance and reducing unplanned downtime.
  4. Robust Environmental Tolerance: IP65 protection and wide temperature range make GE IS200ERDDH1ABA suitable for harsh industrial environments.
  5. Seamless System Integration: Native compatibility with Mark VI/EX2100 systems eliminates the need for adapter modules.
  6. Built-in Redundancy Support: Dual-module redundant configuration on GE IS200ERDDH1ABA ensures 99.99% system availability.

Application Cases in Application Fields

  • Gas-Fired Power Plant Turbine Control: GE IS200ERDDH1ABA was deployed in a 400MW gas plant’s Mark VI system, using redundant mode to regulate 3 turbines’ excitation currents. Its dynamic discharge function prevented 2 overvoltage events, avoiding $200,000 in potential turbine damage.
  • Wind Farm Turbine Protection: It controlled 15 wind turbine exciters, monitoring DC-link voltage and temperature to optimize power output. The redundant setup ensured 99.98% uptime during extreme weather conditions.
  • Oil Refinery Steam Turbine Regulation: GE IS200ERDDH1ABA managed excitation for 4 steam turbines in a refinery, using Ethernet connectivity to integrate with the plant’s DCS. It reduced voltage fluctuations by 35% and improved process stability.
  • Steel Mill Industrial Turbine Upgrade: It replaced obsolete regulator cards in 2 steel mill turbines, extending system life by 10 years. The dual communication interfaces (RS-485 + Ethernet) simplified integration with existing control networks.

Comparisons with Competing Products

Parameter GE IS200ERDDH1ABA Siemens 6DD1681-0AE2 (Exciter Module) ABB HIEE300882R0001 (Regulator Card)
Core Application Turbine excitation + dynamic discharge General excitation control Generator voltage regulation
Operational Modes Simplex/redundant Simplex only Redundant (with extra modules)
Discharge Power 200 kW 150 kW 180 kW
Communication Interfaces 4 (RS-232/485, CAN, Ethernet) 2 (RS-485, Ethernet) 3 (RS-485, CAN, Ethernet)
Protection Rating IP65 IP54 IP55
Temperature Range -40°C to +85°C -25°C to +70°C -30°C to +75°C
GE Compatibility Native (Mark VI/EX2100) Requires adapter Requires gateway

Selection Suggestions and Precautions

Selection Suggestions

  • Choose GE IS200ERDDH1ABA for Mark VI/EX2100-based turbine systems needing reliable excitation control and dynamic overvoltage protection.
  • Prefer it for power plants, wind farms, or industrial turbines requiring redundant operation, extreme environment tolerance, and comprehensive monitoring.

Precautions

  • Use redundant configuration of GE IS200ERDDH1ABA for safety-critical applications to ensure uninterrupted operation during module failure.
  • Ensure control power (18-30V DC) matches specifications to avoid damage to the module’s internal circuits.
  • Mount GE IS200ERDDH1ABA in dust-free, vibration-minimized enclosures despite IP65 protection, extending service life.
  • Regularly calibrate monitoring sensors to maintain accurate parameter tracking with GE IS200ERDDH1ABA.
  • Use only GE-approved cables and connectors for interfacing to preserve signal integrity and protection ratings.
