GE IC698CRE030

Description

Product Description

GE IC698CRE030 is a high-performance, rack-mounted Controller (CPU) module for the GE Fanuc Series 90-70 PLC system, which is part of the later RX7i product family. This module, the IC698CRE030, serves as the central processing unit and the primary logic solver for the automation system. It executes the user-programmed control logic, manages communications with local and remote I/O, and coordinates data exchange with other controllers and supervisory systems. The core function of the GE IC698CRE030 is to provide deterministic control for complex, high-speed, and high-I/O-count applications. It is designed for demanding tasks in industries like power generation, metals, and transportation. The processing power and memory capacity of the IC698CRE030 make it suitable for coordinating multiple processes and handling extensive program data. For system architects requiring robust control within the GE ecosystem, the GE IC698CRE030 represents a capable and scalable controller solution.

Product Parameters / Technical Specifications

• Manufacturer: GE Fanuc (now part of Emerson)
• Series: Series 90-70 / RX7i PLC System
• Functional Designation: Controller (CPU) Module
• Processor: Features a high-performance microprocessor for fast logic execution.
• Memory: Includes both user memory (for logic and variables) and system memory. Specific capacity is defined by the model suffix (030).
• Communication Ports:
  • Serial Port(s): For programming (RS-232/485), often used for initial configuration or connecting to HMIs.
  • Ethernet Port: Integrated Ethernet for programming (SRTP), peer-to-peer communication, and network connectivity.
• I/O Capacity: Supports a large number of local and remote I/O points, communicating via the VME-based backplane and Genius bus or Profibus.
• Scan Time: Capable of very fast deterministic scan times, suitable for high-speed control applications.
• Real-Time Clock: Includes a battery-backed clock for time-stamping events.
• Compatibility: Uses the VersaMax/90-70 form factor and mounts in an IC698 chassis.

Advantages and Key Features

• High Performance and Capacity: Designed for large-scale applications with complex logic, numerous I/O points, and demanding scan time requirements.
• Deterministic Operation: Provides predictable and repeatable scan cycles, which is critical for precise motion control, sequencing, and interlocking.
• Robust Communication: Supports multiple integrated and expandable communication options, including Genius LAN, Ethernet, and serial, enabling seamless integration into diverse networks.
• Extensive Memory: Ample user memory for large control programs, data tables, and recipe storage.
• Hot Standby Redundancy Support: The Series 90-70/RX7i platform, with controllers like the IC698CRE030, can be configured in a hot standby redundant pair to ensure maximum system availability for critical processes.
• Mature & Proven Platform: The 90-70 architecture is known for its ruggedness and reliability in harsh industrial environments.

Application Cases in Industry

• Power Generation (Balance of Plant): Controls complex auxiliary systems for coal, gas, or nuclear plants, such as ash handling, water treatment, and material conveying.
• Metals Production: Manages automation for rolling mills, blast furnace charging systems, and continuous casting lines where high-speed logic and coordination are essential.
• Automated Warehousing & Material Handling: Controls large-scale sortation systems, automated storage/retrieval systems (AS/RS), and airport baggage handling networks.
• Water/Wastewater Management: Serves as the main controller for large treatment plants, managing processes across multiple clarifiers, filter beds, and pumping stations.
• Discrete Manufacturing: Used for high-speed assembly, testing, and packaging lines with extensive I/O and communication needs.

Comparison with Competing Products

Selection Suggestions and Precautions

1. Legacy System Consideration: The Series 90-70/RX7i platform, including the GE IC698CRE030, is a discontinued product line. Selection should be primarily for spare part replacement in existing systems, not for new greenfield projects.
2. Firmware Version Compatibility: The CPU’s firmware version must be compatible with the programming software version (Proficy ME) and the firmware of all connected I/O and communication modules in the rack.
3. Chassis and Backplane Compatibility: The controller must be installed in a compatible IC698 chassis (e.g., IC698CHSxxx). Verify the chassis model and backplane configuration.
4. Memory Backup: Always have a verified, recent backup of the controller’s program and configuration before performing any maintenance or replacement. The program is stored in volatile RAM backed by a battery; loss of power without a backup results in complete program loss.
5. Battery Maintenance: The IC698CRE030 uses a lithium battery to retain the program and real-time clock during power outages. Check and replace this battery periodically according to manufacturer guidelines to prevent unexpected memory loss.
6. Sourcing from Specialists: Given its status as a critical legacy component, source the GE IC698CRE030 from suppliers who specialize in GE PLC systems and can provide testing assurance and compatibility guarantees.
