GE IC698CPE010-JU

GE IC698CPE010 – JU is a 300MHz Intel Celeron – powered CPU module for GE PACSystems RX7i, designed for mid – to large – scale industrial control with real – time processing and flexible communication. GE IC698CPE010 – JU uses a VME64 backplane for seamless integration with RX7i I/O and legacy 90 – 70 Series modules, supporting up to 512 program blocks (128KB max each) for complex control logic in power, manufacturing, and water/wastewater applications.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

Product Description

GE IC698CPE010 – JU is a 300MHz Intel Celeron – powered CPU module for GE PACSystems RX7i, designed for mid – to large – scale industrial control with real – time processing and flexible communication. GE IC698CPE010 – JU uses a VME64 backplane for seamless integration with RX7i I/O and legacy 90 – 70 Series modules, supporting up to 512 program blocks (128KB max each) for complex control logic in power, manufacturing, and water/wastewater applications. GE IC698CPE010 – JU has 10MB battery – backed RAM and 10MB non – volatile flash memory, with firmware updatable via Ethernet without disassembly. It has two 10/100Mbps Ethernet ports (SRTP/Modbus TCP) and three isolated serial ports (RS – 232/485) for HMI/SCADA connectivity and remote monitoring via its built – in web server/FTP. GE IC698CPE010 – JU supports IEC 61131 – 3 languages (LD, ST, FBD, C) and Test Edit mode for on – the – fly programming tweaks, while its Boolean execution speed of 0.33ms per 1000 contacts/coils ensures fast control response. GE IC698CPE010 – JU’s LED diagnostics (power, CPU status, communication) enable quick troubleshooting, and its compact rack – mount form factor simplifies installation in RX7i chassis for system expansions or upgrades.

Product Parameters

Parameter Details
Module Type RX7i PACSystems CPU module (GE IC698CPE010 – JU variant)
Core Function Real – time control, program execution, I/O coordination, VME64 backplane communication
Processor 300MHz Intel Celeron
Memory 10MB battery – backed RAM; 10MB non – volatile flash memory
I/O Capacity 32K discrete I/O points; 32K analog I/O words
Communication 2×10/100Mbps Ethernet (SRTP, Modbus TCP); 3 isolated serial ports (RS – 232/485, Modbus RTU/SNP)
Backplane VME64 (RX7i/90 – 70 compatible)
Programming IEC 61131 – 3 (LD, ST, FBD, C); Test Edit mode; web – based monitoring
Program Capacity 512 blocks max, 128KB per block
Execution Speed 0.33ms per 1000 Boolean contacts/coils
Power Supply 24VDC (3.2A typical)
Operating Temperature 0°C to 50°C
Certifications CE, UL compliant; IEC 61131 – 3 certified
Diagnostics LED indicators for power, CPU, Ethernet, serial port status
Form Factor RX7i rack – mount; ~0.6kg; 29.2cm×19.1cm×4.4cm

Advantages and Features

  1. VME64 Compatibility: GE IC698CPE010 – JU works with RX7i and legacy 90 – 70 I/O, cutting upgrade costs by reusing existing hardware.
  2. Dual Ethernet + Triple Serial: Dual Ethernet ports for redundant communication and three serial ports cover legacy/modern protocols for flexible HMI/SCADA integration.
  3. Non – Volatile Memory & Easy Firmware Updates: 10MB flash memory preserves data; GE IC698CPE010 – JU firmware updates over Ethernet avoid downtime from module disassembly.
  4. IEC 61131 – 3 Programming: Supports multiple languages and Test Edit mode for efficient code development and on – line adjustments.
  5. Fast Boolean Execution: 0.33ms per 1000 contacts/coils ensures quick response in time – critical control loops.
  6. Simplified Diagnostics: LED indicators on GE IC698CPE010 – JU reduce troubleshooting time for power, CPU, and communication issues.

Application Cases in Application Fields

  • Manufacturing Assembly Line Control: GE IC698CPE010 – JU coordinated 20+ I/O modules to manage a 50 – station automotive assembly line, with Ethernet linking to SCADA for real – time OEE tracking and 99.8% uptime.
  • Water Treatment Plant Process Control: It handled 15 analog loops (pH, flow, level) and 300 discrete I/O points, using Modbus TCP to integrate with chemical dosing systems and remote monitoring stations.
  • Power Plant Auxiliary Control: GE IC698CPE010 – JU integrated with legacy 90 – 70 I/O to control boiler feed pumps and cooling towers, supporting a 20% system capacity boost without full hardware replacement.
  • Food & Beverage Packaging Line: It ran 100+ program blocks for recipe management and quality checks, with serial ports connecting to barcode scanners and Ethernet linking to HMI for operator control.

Comparisons with Competing Products

Parameter GE IC698CPE010 – JU Siemens S7 – 400 CPU 414 – 3PN/DP ABB AC800M CPU 804F
Processor 300MHz Celeron 1.4GHz Core i7 800MHz ARM Cortex – A8
Memory 10MB RAM + 10MB flash 512MB RAM + 256MB flash 256MB RAM + 128MB flash
Backplane VME64 (RX7i/90 – 70 compatible) Siemens S7 – 400 backplane ABB AC800M backplane
Communication 2 Ethernet + 3 serial ports Profinet + 2 serial ports EtherNet/IP + 1 serial port
Legacy Integration Supports 90 – 70 I/O Limited S5 integration No legacy ABB 800xA support
Programming IEC 61131 – 3 + Test Edit mode IEC 61131 – 3 (no Test Edit) IEC 61131 – 3
Cost – Effectiveness High (legacy reuse, flexible I/O) Medium (premium for S7 – 400 ecosystem) Medium (proprietary hardware)

Selection Suggestions and Precautions

Selection Suggestions

  • Choose GE IC698CPE010 – JU for RX7i systems needing mid – to large – scale control with legacy 90 – 70 integration or multi – protocol communication.
  • Prefer it for applications requiring IEC 61131 – 3 programming and web – based remote monitoring.

Precautions

  • Pair GE IC698CPE010 – JU with compatible RX7i power supplies and VME64 backplanes to avoid hardware mismatches.
  • Replace the CMOS battery of GE IC698CPE010 – JU every 2–3 years to maintain RAM data retention during power outages.
  • Use shielded Cat5e/Cat6 cables for Ethernet connections on GE IC698CPE010 – JU to prevent signal interference.
  • Follow GE’s firmware update guidelines to avoid corruption when upgrading GE IC698CPE010 – JU remotely.
