GE IC698CHS009

Description

Product Description

The GE IC698CHS009 is a critical chassis or main rack assembly for the GE Fanuc PACSystems RX7i platform, which is the successor to the Series 90-70 control system. This chassis provides the physical and electrical backbone, housing the central processing unit (CPU), power supply, and all other I/O and communication modules. The GE IC698CHS009 features a high-speed VME-based backplane that ensures reliable data transfer between modules and supports the powerful processing capabilities of the RX7i family. For comprehensive technical specifications, installation instructions, and module compatibility lists, the primary resource is the official GE Vernova (formerly GE Intelligent Platforms) support portal for the GE IC698CHS009. As the foundational enclosure, the integrity and proper configuration of the IC698CHS009 chassis are essential for the stable operation of the entire controller. Its robust construction is designed for industrial environments, providing a secure and organized platform for complex automation applications.

Product Parameters

• Manufacturer / Brand: GE (GE Vernova).
• Series: PACSystems RX7i (IC698 series).
• Model: IC698CHS009 – Chassis Assembly.
• Form Factor: A multi-slot metal enclosure designed for panel or rack mounting.
• Number of Slots: Typically provides 9 slots (as indicated by the “009” suffix) for module installation.
• Backplane Type: High-performance VME64 (VITA 1.1) backplane for high-speed communication between modules.
• Slot Allocation: Slot 1 is typically reserved for the CPU module (e.g., IC698CRExxx), and the remaining slots are for I/O, communication, and special function modules.
• Power Distribution: Contains the bus for distributing power from the system power supply module (e.g., IC698PSDxxx) installed in the chassis to all other modules.
• Connectors: Includes connectors for system power supply input and external I/O network connections (e.g., Genius bus).
• Mounting: Designed for standard 19-inch rack mounting or panel mounting using provided brackets.
• Compatible Modules: Designed to work with the entire range of RX7i (IC698xxx) and many Series 90-70 (IC697xxx) modules.

Advantages and Features

• High-Performance Backplane: The VME architecture provides a fast, deterministic data pathway between the CPU and I/O modules, supporting the high-speed scanning capabilities of the RX7i system.
• Robust Industrial Design: Built with heavy-gauge metal, the GE IC698CHS009 offers excellent protection for sensitive electronic modules against dust, vibration, and electromagnetic interference (EMI).
• Scalable Platform: The 9-slot configuration offers ample room for a powerful CPU, multiple communication cards, and a significant number of I/O modules, supporting medium to large control applications.
• Easy Maintenance: The modular “slide-in” design of the chassis allows for easy installation, replacement, or reconfiguration of modules without complex wiring.
• Proven Compatibility: As part of the RX7i migration path for Series 90-70 users, it ensures compatibility with a vast library of existing I/O and programming, protecting investment.

Application Cases in Industry

• Automotive Body Shop Control: A GE IC698CHS009 chassis houses the CPU and communication modules that orchestrate multiple welding robots, conveyor systems, and safety gates in a large assembly line.
• Food and Beverage Processing: Serves as the central controller rack for a major processing line, integrating analog loops for temperature and flow control with high-speed digital I/O for packaging machinery.
• Water Treatment Plant SCADA: Acts as the main control rack for a treatment facility, managing pump control, chemical dosing, and filter backwash sequences across multiple processes.
• Pharmaceutical Batch Production: Provides a centralized, reliable platform for controlling complex batch reactors, mixers, and filling lines where recipe management and data integrity are critical.
• Material Handling Distribution Center: Controls a large network of conveyors, sorters, and automated storage/retrieval systems (AS/RS) from a single, powerful controller rack.

Comparison with Competing Products

Competing products are chassis from other mid-to-high-end PLC platforms, such as the Siemens SIMATIC S7-400 rack or the Rockwell Automation ControlLogix chassis (1756-Ax). The GE IC698CHS009 differentiates itself through its specific role in the RX7i migration story from the large installed base of Series 90-70 systems. Compared to a ControlLogix chassis, the IC698CHS009 uses a VME backplane versus a proprietary parallel backplane, each with its own performance characteristics. Its primary advantage is for users entrenched in the GE ecosystem, offering a straightforward upgrade path with hardware continuity, whereas switching to a competitor’s chassis would require a complete system overhaul.

Selection Suggestions and Precautions

• Selection Suggestions:
  1. Select the GE IC698CHS009 when designing a new RX7i system or upgrading an existing Series 90-70 system that requires the capacity of a 9-slot rack.
  2. Plan the slot layout carefully. Reserve Slot 1 for the CPU. Allocate slots for power supply, communication modules (Ethernet, Genius), and I/O modules based on density and future expansion needs.
  3. Ensure the selected system power supply module (IC698PSDxxx) is compatible and has sufficient wattage to power all modules planned for the chassis.
• Precautions:
  1. Proper Grounding: The chassis must be properly grounded to the plant earth ground to ensure electrical safety and protect against noise. Follow the installation manual’s grounding instructions precisely.
  2. Module Insertion Order: When power is applied, always insert the CPU module first, followed by the power supply, and then other modules. Follow the proper power-up sequence outlined in the hardware manual.
  3. Thermal Management: Ensure adequate ventilation around the chassis. Do not block air vents. In high-temperature environments, consider forced cooling to prevent module overheating.
  4. Handling and Static: Handle the chassis and all modules with care. Use proper anti-static precautions when installing modules to prevent damage from electrostatic discharge (ESD).
  5. Sourcing and Compatibility: Source the GE IC698CHS009 from authorized automation suppliers. Verify that all modules intended for use are listed in the official RX7i compatibility guide for this chassis model. Using non-listed or third-party modules can cause system instability or damage.
