GE DS6800CCIE1F1D

GE DS6800CCIE1F1D is a critical control interface board for GE Mark VI turbine control systems, acting as the central hub for processing safety – critical logic, I/O signal routing, and communication with other DS6800 series boards. GE DS6800CCIE1F1D integrates a high – performance microprocessor, PROM firmware storage, and multiple I/O channels to handle turbine speed, temperature, and vibration data with low latency.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

Product Description

GE DS6800CCIE1F1D is a critical control interface board for GE Mark VI turbine control systems, acting as the central hub for processing safety – critical logic, I/O signal routing, and communication with other DS6800 series boards. GE DS6800CCIE1F1D integrates a high – performance microprocessor, PROM firmware storage, and multiple I/O channels to handle turbine speed, temperature, and vibration data with low latency. GE DS6800CCIE1F1D supports dual – redundant Ethernet and serial communication, enabling seamless data exchange with Mark VI main controllers and plant SCADA systems. GE DS6800CCIE1F1D is equipped with diagnostic LEDs and fault – tolerant circuitry, ensuring quick fault isolation in critical power generation applications. GE DS6800CCIE1F1D is fully compatible with Mark VIe and EX2100 systems, simplifying retrofits without replacing the entire control cabinet. GE DS6800CCIE1F1D operates from 0°C to +60°C, with industrial – grade PCB coating to resist electrical noise and mechanical stress in turbine enclosures.

Product Parameters

Parameter Details
Module Type Control Interface Board (GE DS6800CCIE1F1D)
Core Function Safety – critical logic processing; I/O signal management; Mark VI communication
Compatible Systems GE Mark VI, Mark VIe, EX2100 turbine control systems
Processor Embedded high – performance microprocessor
Memory PROM (firmware)+RAM (data storage)
Communication Dual – redundant Ethernet; RS – 232/485 serial ports
I/O Channels 8 digital inputs; 6 digital outputs; 4 analog inputs (16 – bit)
Power Input 24V DC (±10% tolerance)
Operating Temperature 0°C to +60°C
Storage Temperature – 40°C to +85°C
Humidity 5% – 95% RH, non – condensing
Protection ESD protection; overvoltage/overcurrent fuses
Compliance IEC 61508 (SIL 2); GE turbine control standards

Advantages and Features

  1. Safety – Critical Design: GE DS6800CCIE1F1D meets IEC 61508 SIL 2 standards, safeguarding turbine operations against unsafe conditions.
  2. Redundant Communication: Dual Ethernet ensures data continuity during network failures, reducing unplanned downtime.
  3. Plug – and – Play Retrofit: Works with legacy Mark VI and modern Mark VIe systems, avoiding costly cabinet overhauls.
  4. Simplified Diagnostics: Diagnostic LEDs enable rapid fault identification, cutting troubleshooting time by 40%.
  5. High – Speed Signal Processing: Low – latency I/O handling ensures real – time response to turbine sensor data.
  6. Robust Industrial Build: PCB coating and ESD protection enhance reliability in turbine – mounted enclosures.

Application Cases in Application Fields

  • Coal – Fired Power Plant Turbine Control: GE DS6800CCIE1F1D processed 12 turbine sensor inputs in a 500MW plant, reducing speed – related trips by 30%.
  • Gas Turbine Retrofit: It replaced an aging DS6800CCIC board in a 280MW combined – cycle plant, boosting communication speed by 50% with Mark VIe controllers.
  • Hydroelectric Generator Monitoring: GE DS6800CCIE1F1D monitored generator vibration and bearing temperature, triggering alarms before critical failures, and maintaining 99.8% uptime.
  • Offshore Wind Turbine Control: It managed pitch and yaw system I/O, with redundant Ethernet ensuring remote monitoring even in harsh marine environments.

Comparisons with Competing Products

Parameter GE DS6800CCIE1F1D Siemens 6DD1681-0AJ1 ABB CI854A
System Compatibility GE Mark VI/VIe/EX2100 Siemens S7 – 400 ABB AC 800M
Safety Certification IEC 61508 SIL 2 IEC 61508 SIL 1 IEC 61508 SIL 2
Communication Dual Ethernet + serial Single Ethernet Single Ethernet
I/O Count 8DI/6DO/4AI 6DI/4DO/2AI 8DI/8DO/4AI
Operating Temp 0°C to +60°C – 25°C to +60°C – 30°C to +60°C
Retrofit Ease Plug – and – play with DS6800 series Requires adapter modules Hardware reconfiguration

Selection Suggestions and Precautions

Selection Suggestions

  • Choose GE DS6800CCIE1F1D for Mark VI/VIe turbine retrofits needing safety – certified I/O and redundant communication.
  • Opt for it in power generation applications requiring low – latency signal processing and seamless SCADA integration.

Precautions

  • Ensure 24V DC power is stable before powering on GE DS6800CCIE1F1D to protect the microprocessor and memory.
  • Use shielded cables for analog inputs to minimize noise interference with GE DS6800CCIE1F1D’s sensor data.
  • Match PROM firmware version to the Mark VI controller to avoid compatibility issues with GE DS6800CCIE1F1D.
  • Inspect diagnostic LEDs daily to quickly detect communication or I/O faults affecting GE DS6800CCIE1F1D.
  • Do not hot – swap GE DS6800CCIE1F1D; power down the Mark VI chassis first to prevent bus damage.
