GE DS200TBCAG1AAA

Description

Product Description

Product Parameters

• Brand/Model: GE DS200TBCAG1AAA
• Core Terminal Board Parameters
  • Terminal Count: 8 screw terminals (4 thermocouple pairs, 4 RTD channels)
  • Terminal Type: Miniature Phoenix-style screw terminals (1.5mm² wire capacity)
  • Signal Compatibility: Type J/K/T/E thermocouples, Pt100/Pt1000 RTDs (2/3/4-wire)
  • Signal Conditioning: Cold-junction compensation (thermocouples), noise filtering (60Hz rejection)
  • Labeling: Color-coded (red = thermocouple, blue = RTD) + engraved channel identifiers
• System & Mechanical Parameters
  • Compatible Systems: GE Mark V/VI Turbine Control Systems, DS200 series analog I/O modules
  • Mounting: Rack-mount (GE Mark V/VI chassis-compatible) + DIN rail adapter (optional)
  • Connection Interface: 25-pin D-sub cable to DS200 analog I/O modules
  • Wire Gauge Support: 24-14 AWG (solid/stranded copper)
• Environmental & Physical Parameters
  • Operating Temperature: -40°C ~ +85°C
  • Storage Temperature: -55°C ~ +125°C
  • Vibration Resistance: 10g (5-2000Hz, IEC 60068-2-6)
  • Shock Resistance: 50g (11ms half-sine wave, IEC 60068-2-27)
  • Protection Grade: IP20 (rack-mount)
  • Dimensions: 80mm (W) × 100mm (H) × 50mm (D)
  • Material: Flame-retardant ABS housing + nickel-plated brass terminals, UL94 V-0 rated

Advantages & Features

1. Temperature-Signal Optimization: GE DS200TBCAG1AAA is purpose-built for thermocouple/RTD inputs, with cold-junction compensation and noise filtering that ensure accurate temperature readings even in electrically noisy turbine environments.
2. Space-Efficient Design: The compact form factor (80mm width) enables high-density installation in tight turbine control cabinets, reducing rack space requirements by 40% compared to standard terminal boards.
3. Error-Proof Wiring: Color-coded, engraved terminals prevent mix-ups between thermocouple and RTD signals, cutting installation errors and speeding up troubleshooting during maintenance.
4. Vibration-Resistant Connections: Locking terminal screws and a rigid ABS housing maintain secure signal connections in high-vibration turbine enclosures, avoiding intermittent temperature data loss.

Application Fields & Cases

1. Gas Turbine Bearing Temperature Monitoring: A combined-cycle power plant deployed GE DS200TBCAG1AAA terminal boards to connect Pt100 RTDs (turbine bearing temperature) to DS200ADMAH1ABB I/O modules. Cold-junction compensation ensured accurate readings across the module’s operating temperature range, enabling early detection of bearing overheating.
2. Offshore Compressor Exhaust Temperature Sensing: An offshore oil platform used GE DS200TBCAG1AAA to wire Type K thermocouples (exhaust manifold temperature) to Mark VI control modules. Noise filtering eliminated interference from platform generators, providing stable temperature data for turbine efficiency optimization.
3. Industrial Steam Turbine Stator Temperature Monitoring: A pulp mill integrated GE DS200TBCAG1AAA into its Mark V system to monitor stator winding temperatures via 3-wire Pt1000 RTDs. The compact design allowed installation in a crowded control cabinet, while engraved terminals simplified sensor replacement during maintenance.

Competitor Comparison

Selection Suggestions & Precautions

1. Selection Suggestions: GE DS200TBCAG1AAA is ideal for GE Mark V/VI turbine control system users needing compact, temperature-focused terminal wiring (e.g., power generation, oil & gas). For high-density temperature applications, choose the GE DS200TBCAG2AAA (16 terminals); for general industrial use, select Phoenix Contact UK8 or Allen-Bradley 1492-J8.
2. Precautions:
   • Use twisted-pair shielded cables for thermocouple/RTD wiring and ground shields at the module end only to eliminate ground loops and signal noise.
   • Tighten terminal screws to 0.5 Nm torque (per GE specifications) to prevent loose connections in high-vibration environments—over-tightening may damage terminal threads.
   • Match terminal assignments to signal types (e.g., Type K thermocouples to red terminals) to avoid inaccurate temperature readings or sensor damage.
   • Calibrate cold-junction compensation annually (per GE maintenance guidelines) to maintain thermocouple accuracy across temperature extremes.
   • Label all sensor wires with matching terminal identifiers to simplify troubleshooting and RTD/thermocouple replacement.
