GE DS200PANAH1A

Description

Product Description

Product Parameters

• Brand/Model: GE DS200PANAH1A
• Core Interface Panel Parameters
  • Display: 5.7-inch color LCD (320×240 resolution, LED backlight)
  • Input Device: Tactile membrane keypad (24 keys, including function/navigation keys)
  • Communication Interface: GE Genius Bus (1 Mbps), RS-232 (local programming)
  • User Interface: Customizable HMI screens (turbine status, alarms, configuration)
  • Language Support: English, Spanish, French, German (configurable)
• System & Environmental Parameters
  • Compatible Systems: GE Mark V/VI Turbine Control Systems, DS200 series control modules
  • Mounting: Panel-mount (front IP65, rear IP20)
  • Protection Grade: IP65 (front panel, dust/water-resistant), IP20 (rear)
  • Operating Temperature: -20°C ~ +60°C
  • Storage Temperature: -40°C ~ +85°C
  • Vibration Resistance: 5g (10-2000Hz, IEC 60068-2-6)
  • Shock Resistance: 30g (11ms half-sine wave, IEC 60068-2-27)
• Power & Physical Parameters
  • Power Supply: 24V DC (18-30V range)
  • Power Consumption: < 15W
  • Dimensions: 180mm (W) × 140mm (H) × 50mm (D) (panel cutout: 172×132mm)
  • MTBF: > 200,000 hours (per Telcordia SR-332)

Advantages & Features

1. Intuitive Local Control: GE DS200PANAH1A provides a user-friendly interface for local turbine monitoring and adjustment, eliminating the need for remote HMI access during maintenance or emergency situations.
2. Rugged IP65 Protection: The front-panel IP65 rating protects against dust, water spray, and accidental spills—critical for use in industrial turbine enclosures and power plant control rooms.
3. Customizable HMI Screens: Operators can configure dedicated screens for turbine status, alarm logs, and parameter adjustment, tailoring the interface to specific operational needs and reducing training time for new users.
4. Seamless System Integration: Compatibility with the GE Genius Bus ensures real-time data synchronization with turbine control modules, providing accurate, up-to-date information for informed decision-making.

Application Fields & Cases

1. Gas Turbine Local Control Station: A combined-cycle power plant installed GE DS200PANAH1A panels at each 9FA gas turbine control cabinet, enabling operators to monitor turbine speed, exhaust temperature, and fuel flow locally. During a network outage, the panels allowed manual adjustment of turbine setpoints to maintain stable operation until remote HMIs were restored.
2. Offshore Compressor Turbine Operation: An offshore oil platform deployed GE DS200PANAH1A to provide local control of gas turbine-driven compressors. The IP65-rated front panel withstood saltwater spray and dust, while the intuitive interface simplified troubleshooting for maintenance teams working in harsh marine conditions.
3. Industrial Steam Turbine Maintenance: A pulp mill integrated GE DS200PANAH1A into its steam turbine control system to display real-time lubrication pressure, bearing temperature, and vibration data. Custom alarm screens alerted operators to potential issues (e.g., low oil pressure), enabling proactive maintenance and reducing unplanned downtime.

Competitor Comparison

Selection Suggestions & Precautions

1. Selection Suggestions: GE DS200PANAH1A is ideal for GE Mark V/VI turbine control system users needing local operator interfaces for monitoring and maintenance (e.g., power generation, offshore oil & gas). For smaller display needs, choose the GE DS200PANAH1B (4-inch monochrome); for non-GE systems, select Siemens KTP400 or Allen-Bradley PanelView 800.
2. Precautions:
   • Mount the panel in a location protected from direct sunlight and extreme temperatures to prevent LCD damage and ensure optimal visibility.
   • Use shielded cables for Genius Bus communication and route them separately from power cables to avoid electromagnetic interference (EMI) that could disrupt data transmission.
   • Calibrate the display and keypad annually (per GE maintenance guidelines) to ensure accurate touch/keypad response and clear visibility.
   • Back up HMI configuration files regularly (via RS-232) to prevent data loss in the event of panel failure.
   • Clean the front panel with a soft, damp cloth (avoid harsh chemicals) to maintain IP65 protection and prevent scratching the LCD.
