GE 369-HI-0-M-F-E-0

GE 369-HI-0-M-F-E-0 is a high – performance motor management relay from GE Multilin’s 369 series, tailored for comprehensive protection, monitoring, and control of 3 – phase medium – to – large AC motors in industrial environments. GE 369-HI-0-M-F-E-0 integrates core protection functions like overload, short circuit, ground fault, undervoltage, and phase loss, along with a metering package for voltage, power, and energy monitoring. G

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

Product Description

GE 369-HI-0-M-F-E-0 is a high – performance motor management relay from GE Multilin’s 369 series, tailored for comprehensive protection, monitoring, and control of 3 – phase medium – to – large AC motors in industrial environments. GE 369-HI-0-M-F-E-0 integrates core protection functions like overload, short circuit, ground fault, undervoltage, and phase loss, along with a metering package for voltage, power, and energy monitoring. GE 369-HI-0-M-F-E-0 supports Modbus TCP, RS485, and optional Profinet/EtherNet – IP, enabling seamless integration with SCADA/DCS platforms such as GE CIMPLICITY. GE 369-HI-0-M-F-E-0 features a 40 – character LCD, front – panel keypad, and status LEDs for quick on – site parameter setting and fault diagnosis. GE 369-HI-0-M-F-E-0 has a rugged flame – retardant enclosure, 40–265V AC/50–300V DC wide – range power input, and operates stably in – 25°C to +70°C industrial conditions. GE 369-HI-0-M-F-E-0 can “learn” motor parameters, allowing users to adjust inrush current, cooling rates, and acceleration time for optimized protection performance.

Product Parameters

Parameter Details
Module Type Motor Management Relay (GE 369-HI-0-M-F-E-0)
Core Function 3 – phase motor protection (overload, short circuit, ground fault, undervoltage, phase loss); metering; communication integration; parameter learning
Compatible Systems Industrial SCADA/DCS (GE CIMPLICITY, Siemens WinCC); 3 – phase AC motor systems (medium – large capacity)
Control Power 40–265V AC; 50–300V DC
Current Input Direct 1–100A AC (HI version, no external CT needed); built – in Rogowski coil
Voltage Input VT inputs (for metering package); supports 100V/220V/400V AC
Communication Front RS232; rear RS485; Modbus TCP Ethernet; optional Profinet/EtherNet – IP
Display 40 – character LCD; 10 front – panel status LEDs
Outputs 8 relay outputs (AC250V/8A, DC24V/12A); 4 user – definable analog outputs
Operating Temperature – 25°C to +70°C
Storage Temperature – 40°C to +85°C
Humidity 5% – 95% RH, non – condensing
Compliance IEEE C37.90.1; UL/CE certified; Pollution Degree II

Advantages and Features

  1. Integrated Protection & Metering: GE 369-HI-0-M-F-E-0 combines 25+ motor protection functions with a metering package, reducing panel space and wiring costs by 35% vs. discrete devices.
  2. Parameter Learning: Adapts to motor – specific parameters to optimize protection and reduce false trips by 40%.
  3. Dual – Mode Communication: RS485 + Ethernet ensures reliable data exchange for remote monitoring and diagnostics.
  4. On – Site Diagnostics: LCD and LEDs cut troubleshooting time by 50% without additional software/tools.
  5. Wide Power & Environmental Range: 40–265V AC/50–300V DC input and – 25°C to +70°C operation suit harsh industrial sites.
  6. Event Recording: 512+ event records with 1ms resolution for post – trip analysis and compliance.

Application Cases in Application Fields

  • Petrochemical Refinery: GE 369-HI-0-M-F-E-0 protected 500kW reactor agitator motors, detecting bearing wear via integrated electrical – vibration diagnostics and triggering pre – trip alarms 20+ days early, reducing unplanned shutdowns by 45%.
  • Power Plant Auxiliary Motors: It monitored 300kW boiler feed pump motors, using overload/ground fault protection to prevent damage during grid voltage fluctuations, ensuring 99.9% uptime.
  • Steel Mill Rolling Mills: GE 369-HI-0-M-F-E-0 controlled 800kW rolling mill motors, adjusting acceleration time to avoid mechanical jams and cutting maintenance costs by 30%.
  • Water Treatment Pumps: It protected 200kW submersible pumps, using undervoltage and phase – loss protection to prevent dry – run damage and extend pump life by 25%.

Comparisons with Competing Products

Parameter GE 369-HI-0-M-F-E-0 Siemens 7SJ61 ABB PMA 132
Protection Functions Overload, short circuit, ground fault, undervoltage, phase loss + metering Overload, short circuit, ground fault Overload, short circuit, ground fault, temperature
Power Input 40–265V AC/50–300V DC 85–264V AC/110–300V DC 24–240V AC/DC
Communication RS485 + Ethernet + optional Profinet Single Ethernet + RS485 Dual Ethernet + Modbus RTU
Display 40 – character LCD + 10 LEDs 2 – line LCD + 6 LEDs 4 – line LCD + 8 LEDs
Parameter Learning Yes (adjust inrush/cooling/acceleration) No Limited
Event Records 512+ (1ms) 256+ (5ms) 300+ (2ms)
Operating Temp – 25°C to +70°C – 20°C to +60°C – 30°C to +60°C

Selection Suggestions and Precautions

Selection Suggestions

  • Choose GE 369-HI-0-M-F-E-0 for medium – large 3 – phase AC motors needing integrated protection, metering, and parameter learning.
  • Opt for it in petrochemical, power, steel, and water treatment applications requiring wide power input and harsh – environment operation.

Precautions

  • Use GE EnerVista 369 software for configuring protection settings and event analysis of GE 369-HI-0-M-F-E-0.
  • Verify direct current input (1–100A AC) compatibility with your motor’s rated current before installation.
  • Check communication connectivity (RS485/Ethernet) when integrating GE 369-HI-0-M-F-E-0 with SCADA/DCS.
  • Avoid hot – swapping GE 369-HI-0-M-F-E-0; power down the control panel first to prevent relay damage.
  • Regularly update firmware for GE 369-HI-0-M-F-E-0 to ensure compliance with the latest protection standards and bug fixes.
