EMERSON VE4003S2B3

Emerson VE4003S2B3 is an 8-channel 4-20 mA analog input (AI) card for the Emerson DeltaV DCS, paired with the KJ4001X1-CC1 4-wire termination block, optimized for precise signal acquisition from industrial field instruments like pressure transmitters, flow meters, and temperature sensorsEmerson.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

Emerson VE4003S2B3 is an 8-channel 4-20 mA analog input (AI) card for the Emerson DeltaV DCS, paired with the KJ4001X1-CC1 4-wire termination block, optimized for precise signal acquisition from industrial field instruments like pressure transmitters, flow meters, and temperature sensorsEmerson. As a core Traditional I/O module, Emerson VE4003S2B3 supports native HART communication, enabling bidirectional data exchange with smart devices for remote configuration and diagnostics. Emerson VE4003S2B3 features channel-to-channel isolation (1500V DC) to eliminate cross-talk and noise in harsh industrial settings, ensuring signal integrity and measurement accuracy of 0.15% of span. Emerson VE4003S2B3 offers 16-bit resolution and a 24V DC loop power supply (max 30 mA per channel), simplifying integration with 2-wire and 4-wire field devices. With seamless DeltaV software integration, Emerson VE4003S2B3 allows centralized monitoring and calibration, reducing on-site maintenance time and improving system uptime. The robust design of Emerson VE4003S2B3 operates reliably from -40°C to +70°C, making it ideal for critical process control in oil and gas, chemical, and power generation applications.

Technical Parameters Emerson VE4003S2B3

Parameter Item Parameter Value
Product Type 8-Channel 4-20 mA Analog Input Card (Emerson VE4003S2B3)
Core Function Signal acquisition, HART communication, remote diagnostics, DeltaV integration
Number of Channels 8 (independent, 4-wire)
Input Signal 4-20 mA DC (2-wire/4-wire compatible)
Accuracy 0.15% of span
Resolution 16-bit
Isolation Channel-to-channel: 1500V DC
Loop Power 24V DC, max 30 mA per channel
Communication Native HART (compatible with AMS Device Manager)
Termination Block KJ4001X1-CC1 (4-wire)
Operating Temperature -40°C to +70°C
Storage Temperature -55°C to +85°C
Mounting DIN rail (TS35/7.5 or TS35/15)
Power Consumption 12W (typical)
Dimensions 86.8 mm×55.1 mm×32.4 mm
Weight 0.5 kg (approx.)

Advantages and Features Emerson VE4003S2B3

  1. High Accuracy & Resolution: Emerson VE4003S2B3 delivers 0.15% of span accuracy and 16-bit resolution for precise process variable measurement.
  2. HART & DeltaV Integration: Native HART support and seamless DeltaV DCS compatibility enable smart device integration and centralized system management.
  3. Robust Isolation: 1500V DC channel isolation of Emerson VE4003S2B3 ensures signal integrity in noisy industrial environments.
  4. Flexible Powering: 24V DC loop power supply supports both 2-wire and 4-wire field devices, reducing wiring complexity.
  5. Reliable Industrial Design: Wide temperature range and DIN-rail mounting make Emerson VE4003S2B3 suitable for harsh field conditions and space-constrained cabinets.

Application Cases Emerson VE4003S2B3

  1. Oil Refinery Pressure Monitoring: A refinery used Emerson VE4003S2B3 to monitor 48 pressure transmitters across distillation units. HART diagnostics reduced unplanned downtime by 28%, and 0.15% accuracy improved process stability by 20%.
  2. Chemical Plant Flow Control: A chemical manufacturer integrated Emerson VE4003S2B3 to acquire flow meter signals for reactor feed control. Channel isolation eliminated noise interference, cutting measurement errors by 32% and enhancing product quality consistency.
  3. Power Plant Temperature Sensing: A 600 MW thermal power plant deployed Emerson VE4003S2B3 to monitor boiler tube temperatures. The card’s wide temperature range and HART integration ensured reliable data transmission, reducing maintenance costs by 25%.

Competitor Comparison

Feature Emerson VE4003S2B3 Siemens S7-1500 AI 8×4-20mA Rockwell ControlLogix 1756-IF8H
Channel Count 8 (4-wire, HART native) 8 (2-wire, HART optional) 8 (2-wire, HART native)
Accuracy 0.15% of span 0.2% of span 0.1% of span
Resolution 16-bit 14-bit 16-bit
Isolation 1500V DC 1000V DC 1500V DC
Loop Power 24V DC, 30 mA max Optional Built-in
DeltaV Compatibility Yes (seamless) No No
Price Range Mid Mid High

Selection Suggestions

  1. Choose Emerson VE4003S2B3 for DeltaV Traditional I/O projects requiring 8-channel AI with native HART and 4-wire termination.
  2. Prioritize Emerson VE4003S2B3 for applications needing 0.15% accuracy and 1500V isolation to ensure reliable measurements in noisy industrial environments.
  3. Select Emerson VE4003S2B3 when upgrading legacy AI cards to leverage HART smart device integration and DeltaV centralized management.

Precautions

  1. Use only KJ4001X1-CC1 termination blocks for Emerson VE4003S2B3 to maintain isolation and HART communication reliability.
  2. Do not exceed 30 mA per channel loop power for Emerson VE4003S2B3 to prevent damage to the module’s power circuits.
  3. Ensure proper grounding and shielding during installation of Emerson VE4003S2B3 to maximize signal integrity and noise immunity.
  4. Calibrate Emerson VE4003S2B3 annually using a certified HART communicator to retain 0.15% of span accuracy.
  5. Operate Emerson VE4003S2B3 within -40°C to +70°C and avoid exposure to moisture, dust, or corrosive gases to ensure long-term reliability.
