EMERSON VE3006

Technical Specifications

Category Details
Rated Power Range 0.75kW – 75kW (230V single-phase / 380V–480V three-phase)
Control Modes Sensorless vector control (default); V/F control (configurable)
Speed Accuracy ±0.1% of rated speed (sensorless vector); ±0.5% (V/F)
Torque Accuracy ±0.5% of rated torque (sensorless vector)
Input Voltage 230V ±10% (single-phase); 380V–480V ±10% (three-phase); 50/60Hz
Output Frequency 0.1Hz – 400Hz
Communication Modbus RTU (RS485); BACnet MS/TP; optional Ethernet/IP
Operating Environment Temperature: -10°C to +50°C (no derating); Humidity: 5%–95% RH (non-condensing); IP20 (chassis-mounted)
Protection Features Overcurrent, overvoltage, undervoltage, overtemperature, phase loss, motor overload
Certifications CE, UL 508C, CSA C22.2 No. 14, IEC 61800-5-1
Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

EMERSON VE3006 is a high-performance variable frequency drive (VFD) designed for industrial motor control, part of Emerson’s PowerDrive product lineup. Its core function is to adjust the frequency and voltage supplied to AC induction motors, enabling precise speed and torque regulation while reducing energy consumption. It is widely used in HVAC systems, water/wastewater treatment, manufacturing, and oil and gas industries—specifically for controlling pumps, fans, compressors, and conveyors.

Core Functions and Key Advantages

The standout strengths of EMERSON VE3006 lie in its energy efficiency, precise control capabilities, and robust reliability. It uses sensorless vector control technology, which delivers ±0.1% speed accuracy and ±0.5% torque accuracy even at low speeds (down to 0.5Hz)—critical for applications like wastewater pumps that require stable flow rates or conveyor belts that need consistent product alignment. Unlike basic V/F (Voltage/Frequency) drives, this control mode ensures the motor maintains torque at low speeds, preventing stalling under variable loads.
A key benefit of EMERSON VE3006 is its energy-saving performance. When motors operate at partial load (e.g., a fan running at 70% speed), the VFD automatically optimizes voltage and frequency to match the load demand, cutting energy use by up to 30% compared to direct-on-line (DOL) starting. This makes it ideal for energy-intensive applications where operational costs are a priority, such as large HVAC systems in commercial buildings.
EMERSON VE3006 also includes comprehensive motor protection features to minimize downtime. It guards against overcurrent (short circuits/overloads), overvoltage/undervoltage (power grid fluctuations), overtemperature (VFD or motor overheating), and phase loss (wiring errors). These protections eliminate the need for external relays or fuses, simplifying system design. Additionally, the VFD supports “soft starting,” which reduces inrush current during motor startup—extending motor lifespan by avoiding mechanical stress from sudden voltage spikes.
For integration flexibility, EMERSON VE3006 works with common industrial protocols: Modbus RTU (for RS485 connections), BACnet MS/TP (for building automation), and optional Ethernet/IP. This allows seamless communication with PLCs (e.g., Emerson PACSystems), DCS systems, or HVAC controllers, enabling remote monitoring, speed adjustments, and fault diagnostics from a central dashboard.

Technical Specifications

Category Details
Rated Power Range 0.75kW – 75kW (230V single-phase / 380V–480V three-phase)
Control Modes Sensorless vector control (default); V/F control (configurable)
Speed Accuracy ±0.1% of rated speed (sensorless vector); ±0.5% (V/F)
Torque Accuracy ±0.5% of rated torque (sensorless vector)
Input Voltage 230V ±10% (single-phase); 380V–480V ±10% (three-phase); 50/60Hz
Output Frequency 0.1Hz – 400Hz
Communication Modbus RTU (RS485); BACnet MS/TP; optional Ethernet/IP
Operating Environment Temperature: -10°C to +50°C (no derating); Humidity: 5%–95% RH (non-condensing); IP20 (chassis-mounted)
Protection Features Overcurrent, overvoltage, undervoltage, overtemperature, phase loss, motor overload
Certifications CE, UL 508C, CSA C22.2 No. 14, IEC 61800-5-1

Typical Application Scenarios

  1. Water/Wastewater: Sludge Pump Control

    In municipal wastewater plants, EMERSON VE3006 regulates the speed of centrifugal sludge pumps. The VFD receives level signals from tank float sensors: when sludge levels rise, it increases pump speed to 100% for maximum flow; when levels drop, it reduces speed to 30% to save energy. Its overcurrent protection triggers an alarm if the pump clogs, while remote monitoring via Modbus allows operators to adjust settings without onsite visits—minimizing maintenance time.

  2. HVAC: Commercial Building Fan Systems

    For large office buildings or shopping malls, EMERSON VE3006 controls rooftop air handling unit (AHU) fans. It adjusts fan speed based on CO₂ or temperature sensors: during peak hours, it runs at 100% speed for full airflow; during off-hours, it drops to 50% speed. This reduces HVAC energy use by 25–30% compared to fixed-speed fans, while soft starting prevents voltage dips that could disrupt other building systems.

  3. Manufacturing: Conveyor Belt Speed Matching

    In automotive assembly lines, EMERSON VE3006 synchronizes the speed of multiple conveyor belts to ensure smooth product transfer. Using sensorless vector control, it maintains ±0.1% speed accuracy across belts, preventing jams or misalignment of car parts. The VFD’s phase loss protection also shuts down the conveyor immediately if a wiring fault occurs, avoiding damage to expensive assembly equipment.

Comparison with Competitors

Feature EMERSON VE3006 Competitor (e.g., Siemens SINAMICS V20)
Control Precision ±0.1% speed accuracy (sensorless vector) ±0.5% speed accuracy (V/F only)
Energy Savings Up to 30% vs. DOL starting Up to 20% vs. DOL starting
Protocol Support Modbus RTU + BACnet (standard); Ethernet/IP (optional) Modbus RTU (standard); Ethernet/IP (requires upgrade)
Torque at Low Speeds Maintains full torque at 0.5Hz Torque drop-off below 5Hz

Selection Recommendations and Precautions

Selection Recommendations

  1. Match to Motor Size: Choose EMERSON VE3006 based on the motor’s rated power (0.75kW–75kW) and voltage (230V single-phase / 380V–480V three-phase) to ensure compatibility.
  2. Prioritize Precision: Opt for EMERSON VE3006 if your application needs low-speed torque (e.g., pumps, conveyors) or tight speed control—its sensorless vector mode outperforms basic V/F drives.
  3. Building Automation: Select this VFD for HVAC systems using BACnet, as it includes native BACnet MS/TP support (no additional modules needed).

Precautions

  1. Wiring: Use shielded power cables to reduce electromagnetic interference (EMI) with nearby sensors or controllers. Ground the shield at both the VFD and motor ends.
  2. Cooling: Ensure the installation area has adequate ventilation—EMERSON VE3006 derates performance above +50°C, so avoid mounting near heat sources (e.g., motors, heaters).
  3. Parameter Setup: Configure acceleration/deceleration times (1–300 seconds) based on the load: longer times for pumps (to prevent water hammer) and shorter times for fans.
