Emerson SE4035S2B5

Emerson SE4035S2B5 is a high-performance 8-channel analog output (AO) card for the Emerson DeltaV distributed control system (DCS), engineered to deliver precise 4-20 mA signal output for industrial process control applications such as valve actuation, pump speed regulation, and flow control loops.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

Emerson SE4035S2B5 is a high-performance 8-channel analog output (AO) card for the Emerson DeltaV distributed control system (DCS), engineered to deliver precise 4-20 mA signal output for industrial process control applications such as valve actuation, pump speed regulation, and flow control loops. As a core I/O component, Emerson SE4035S2B5 features channel-to-channel optical isolation (1500V DC) and HART communication support, enabling seamless integration with smart field devices while ensuring signal integrity in noisy industrial environments. Emerson SE4035S2B5 offers 0.25% of span accuracy and 12-bit resolution, ensuring consistent and reliable control signal transmission even in extreme temperature conditions. With a maximum field circuit power of 300 mA @ 24V DC, Emerson SE4035S2B5 can drive multiple loads per card, reducing hardware footprint and installation costs. It is fully compatible with DeltaV’s asset management software (AMS) for remote configuration, diagnostics, and calibration, minimizing on-site maintenance time and improving system uptimeEmerson. Emerson SE4035S2B5 is designed for harsh industrial settings, supporting a wide operating temperature range and compliance with global safety standards, making it a trusted choice for critical process control in oil and gas, chemical, and power generation industries.

Technical Parameters Emerson SE4035S2B5

Parameter Item Parameter Value
Product Type 8-Channel Analog Output Card (Emerson SE4035S2B5)
Core Function 4-20 mA control signal output, HART communication, remote diagnosticsEmerson
Number of Channels 8 (independently configurable)
Isolation Channel-to-channel optical isolation, 1500V DC factory-tested
Signal Range Nominal: 4-20 mA; Full: 1-23 mA
Accuracy 0.25% of span (over temperature range)
Resolution 12-bit
Field Circuit Power 300 mA max @ 24V DC (+/-10%)
Output Compliance 20 mA at 21.6V DC into 700 ohms load
LocalBus Current Typical: 100 mA; Max: 150 mA (12V DC nominal)
Operating Temperature -40°C to +70°C
Storage Temperature -40°C to +85°C
Communication Protocol HART (compatible with AMS software)Emerson
Mounting DIN rail (TS35/7.5 or TS35/15)艾默生

Advantages and Features Emerson SE4035S2B5

  1. High Accuracy & Resolution: Emerson SE4035S2B5’s 0.25% of span accuracy and 12-bit resolution ensure precise control signal output for critical process variables.
  2. Enhanced Signal Integrity: Channel-to-channel optical isolation (1500V DC) of Emerson SE4035S2B5 eliminates cross-talk and noise interference, improving system reliability.
  3. Seamless Smart Integration: HART support and AMS compatibility allow Emerson SE4035S2B5 to communicate with smart devices and enable remote diagnostics, reducing maintenance costsEmerson.
  4. Cost-Efficient Design: High load-driving capacity and multi-channel configuration minimize hardware count and installation complexity, lowering total cost of ownership.
  5. Robust Industrial Performance: Wide temperature range and global safety compliance make Emerson SE4035S2B5 suitable for harsh environments and critical process control applications.

Application Cases Emerson SE4035S2B5

  1. Oil Refinery Valve Control: A major oil refinery deployed Emerson SE4035S2B5 to control 64 control valves across its distillation units. The card’s HART compatibility enabled remote valve diagnostics, reducing unplanned downtime by 30% and cutting maintenance costs by 25%Emerson.
  2. Chemical Plant Flow Regulation: A chemical manufacturer used Emerson SE4035S2B5 to drive variable frequency drives (VFDs) for pump speed control. Its 0.25% accuracy ensured precise flow regulation, improving product quality consistency by 18%.
  3. Power Plant Boiler Control: A 500 MW thermal power plant integrated Emerson SE4035S2B5 into its boiler feedwater control system. The card’s optical isolation and noise immunity maintained stable control signals, reducing steam pressure fluctuations by 22% and enhancing energy efficiency.

Competitor Comparison

Feature Emerson SE4035S2B5 Siemens S7-1500 AO 8×4-20mA Rockwell ControlLogix 1756-OF8H
Channel Count 8 (optical isolation) 8 (galvanic isolation) 8 (galvanic isolation)
HART Support Yes (native)Emerson Optional Yes (native)
Accuracy 0.25% of span 0.3% of span 0.2% of span
Resolution 12-bit 14-bit 16-bit
Load Driving Capacity 700 ohms @ 20 mA 600 ohms @ 20 mA 500 ohms @ 20 mA
AMS Compatibility YesEmerson No No
Price Range Mid Mid High

Selection Suggestions

  1. Choose Emerson SE4035S2B5 for DeltaV DCS installations requiring 8-channel AO cards with HART support and remote diagnostics capabilitiesEmerson.
  2. Prioritize Emerson SE4035S2B5 for applications needing high accuracy (0.25% of span) and signal isolation (1500V DC) to ensure reliable control in noisy environments.
  3. Select Emerson SE4035S2B5 when upgrading legacy AO cards to maintain system compatibility and leverage smart device integration for predictive maintenanceEmerson.

Precautions

  1. Ensure proper grounding and shielding during installation of Emerson SE4035S2B5 to maximize signal integrity and avoid noise interference.
  2. Use only Emerson-approved termination blocks and cables to maintain Emerson SE4035S2B5’s isolation rating and HART communication reliability.
  3. Calibrate Emerson SE4035S2B5 annually using a certified HART communicator to retain 0.25% of span accuracyEmerson.
  4. Avoid exceeding the maximum field circuit power (300 mA @ 24V DC) to prevent damage to the card’s output circuits.
  5. Operate Emerson SE4035S2B5 within its specified temperature range (-40°C to +70°C) to ensure long-term performance and reliability.
