Description

The Bently Nevada 3500 series is a widely used monitoring system for rotating machinery, designed for reliability and accuracy in industrial applications.

Bently Nevada 3500/53 – Accelerometer Module

Product Name: 3500/53

Product Description: The 3500/53 module is designed for monitoring vibration and dynamic measurements on rotating equipment. It collects and processes information from accelerometers to provide comprehensive analysis and alarming for machinery health.

Product Parameters:

• Input Voltage: 24 VDC
• Maximum Number of Channels: 4
• Measurement Range: Typically ±50g (subject to sensor used)
• Frequency Response: Broad, facilitating a range of applications

Specifications:

• Size: 3U rack mountable
• Communication: Supports various protocols for data retrieval
• Alarming Levels: Configurable limits for maintenance alerts
• Compatible Sensors: Various accelerometers, including velocity and displacement sensors

Product Use:

• Used in industries such as oil and gas, power generation, pulp and paper, and more for condition monitoring.

Bently Nevada 3500/50 – Proximity Probe Module

Product Name: 3500/50

Product Description: The 3500/50 module processes data from proximity probes used for measuring shaft position and axial displacement in rotating machinery.

Product Parameters:

• Input Voltage: 24 VDC
• Measurement Range: Varies based on specific probe used
• Number of Channels: Up to 4 channels

Specifications:

• Size: 3U rack mountable
• Output: Analog and digital signals for machine condition monitoring
• Fault Tolerance: High reliability with built-in redundancy for critical systems

Product Use:

• Critical for monitoring turbine generator shafts, compressors, and motors to prevent mechanical failures.

Bently Nevada 3500/54 – Torsional Vibration Module

Product Name: 3500/54

Product Description: The 3500/54 module is designed specifically for monitoring torsional vibrations in rotating shafts, providing early detection of potential torsional vibration issues.

Product Parameters:

• Input Voltage: 24 VDC
• Channels: Supports 2 channels typically
• Measurement Type: Torsional vibrations

Specifications:

• Size: 3U rack mounted
• Display: Outputs data for analysis in various formats
• Alarming: Configurable to alert operators of potential issues

Product Use:

• Often used in engines, gearboxes, and other machinery where torsional vibrations can lead to significant failures.
