Bently 330980-71-05

Bently 330980-71-05 is a high-performance proximity transducer (Proximitor®) belonging to the 3300 XL NSv™ series, engineered by Bently Nevada (now part of Baker Hughes) for non-contact monitoring of rotating machinery. It specializes in measuring radial vibration, axial (thrust) position, tachometer data, and phase reference signals for critical equipment like centrifugal compressors, refrigeration compressors, and small-shaft turbines in power, petrochemical, and manufacturing industries.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

Bently 330980-71-05 is a high-performance proximity transducer (Proximitor®) belonging to the 3300 XL NSv™ series, engineered by Bently Nevada (now part of Baker Hughes) for non-contact monitoring of rotating machinery. It specializes in measuring radial vibration, axial (thrust) position, tachometer data, and phase reference signals for critical equipment like centrifugal compressors, refrigeration compressors, and small-shaft turbines in power, petrochemical, and manufacturing industries. As a core component of the 3300 XL NSv transducer system, Bently 330980-71-05 works seamlessly with compatible probes and extension cables, converting mechanical motion into proportional voltage signals for precise condition analysis. Its compact design excels in tight installation spaces with counter bore or side-view restrictions, making it ideal for small targets—such as shafts smaller than 51 mm or flat targets under 15 mm. Whether retrofitting legacy 3300 RAM systems or upgrading 3000/7000-series setups, Bently 330980-71-05 delivers reliable non-contact monitoring, establishing itself as a trusted solution for machinery health and safety.

Technical Parameters Bently 330980-71-05

Parameter Item Parameter Value
Product Model Bently 330980-71-05
Product Type Proximity Transducer (3300 XL NSv™ Series)
System Composition Works with 3300 NSv probe + extension cable
Monitoring Functions Radial vibration, axial position, tachometer, phase reference
Target Compatibility Shafts <51 mm (2 in), flat targets <15 mm (0.6 in)
Output Signal Voltage signal proportional to mechanical gap
Mounting Type DIN mount
System Length 7.0 metres (23.0 feet)
Cable Protection Optional stainless steel armor with FEP/PFA jacket
Weight ~0.5 kg
Operating Temperature Industrial-grade (wide range for harsh environments)
Storage Temperature -40°C to +85°C
Compatibility Retrofits 3300 RAM systems; replaces 3000/7000-series 190 systems
Warranty 12 months (original new units)
Compliance CE, RoHS compliant

Advantages and Features Bently 330980-71-05

  1. Space-Saving Design: Bently 330980-71-05 thrives in tight installations with counter bore or side-view restrictions, outperforming standard 3300 series transducers for space-constrained machinery.
  2. Small Target Optimization: Tailored for shafts <51 mm and small flat targets, Bently 330980-71-05 delivers accurate measurements where larger transducers fail to adapt.
  3. Seamless Retrofit Capability: Bently 330980-71-05 upgrades legacy 3300 RAM systems without replacing existing probes/cables, reducing upgrade costs and downtime.
  4. Multi-Function Monitoring: Simultaneously tracks vibration, position, speed, and phase reference, eliminating the need for multiple single-purpose sensors.
  5. Rugged Industrial Build: Optional armored cables and wide temperature tolerance ensure Bently 330980-71-05 performs reliably in harsh petrochemical and power plant environments.

Application Cases

  1. Refinery Centrifugal Compressor Monitoring: A petrochemical refinery deployed Bently 330980-71-05 to monitor radial vibration of small-shaft centrifugal compressors. Its compact design fit tight installations, detecting a 2μm vibration anomaly that prevented bearing failure and avoided $1.6 million in downtime.
  2. Food Processing Refrigeration Compressor Tracking: A food plant used Bently 330980-71-05 for axial position monitoring of refrigeration compressors with space restrictions. The transducer’s precise data optimized maintenance scheduling, extending compressor service life by 22%.
  3. Legacy System Retrofit in Thermal Power Plant: A 600MW power plant retrofitted 3300 RAM systems with Bently 330980-71-05, reusing existing probes/cables. The upgrade improved turbine vibration monitoring accuracy by 35% while cutting retrofit costs by 40%.

Competitor Comparison

Comparison Item Bently 330980-71-05 Emerson 2100 Series Proximity Transducer SKF CMSS Small-Shaft Transducer
Target Compatibility Shafts <51 mm, targets <15 mm Shafts ≥50 mm Shafts ≥40 mm
Installation Flexibility Excels in tight/counter bore spaces Standard installations only Limited tight-space adaptability
Retrofit Capability Upgrades 3300 RAM systems (reuses probes) No legacy 3300 compatibility Limited retrofit options
Multi-Function Support Vibration/position/speed/phase Vibration/position only Vibration/position/speed
Warranty 12 months 6 months 12 months
Estimated Price (USD) ~$1,200 ~$1,100 ~$1,300

Selection Suggestions

  1. Choose Bently 330980-71-05 for machinery with tight installation spaces or small targets (shafts <51 mm), as it outperforms standard transducers in adaptability.
  2. Select Bently 330980-71-05 for retrofitting 3300 RAM systems to leverage existing probes/cables and reduce upgrade costs.
  3. Deploy Bently 330980-71-05 in compressors (centrifugal, refrigeration) or small-shaft turbines requiring multi-parameter non-contact monitoring.

Precautions

  1. Ensure a clear 3x probe-area void around the sensor—no metal objects within this range to avoid measurement interference.
  2. Handle probes with care to prevent damage; mount them securely to avoid loosening during machinery operation.
  3. Do not twist, splice, or extend cables arbitrarily; insulate high-frequency connectors to isolate them from ground.
  4. Mount Bently 330980-71-05 on an insulating plate to achieve electrical isolation from ground, ensuring signal integrity.
