BENTLY 176449-08

BENTLY 176449-08 is a high-performance 8-channel vibration and position monitoring module engineered for Bently Nevada 3500 series machinery protection systems, specializing in real-time condition monitoring of critical rotating equipment such as turbines, generators, and centrifugal compressors.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

BENTLY 176449-08 is a high-performance 8-channel vibration and position monitoring module engineered for Bently Nevada 3500 series machinery protection systems, specializing in real-time condition monitoring of critical rotating equipment such as turbines, generators, and centrifugal compressors. As a core data acquisition component, BENTLY 176449-08 supports both proximity probe inputs for shaft position measurement and seismic sensor inputs for vibration amplitude detection, delivering precise, synchronized data to identify early-stage faults like misalignment, imbalance, and bearing wear. BENTLY 176449-08 features built-in signal conditioning and programmable alarm/trip thresholds, enabling automatic protective actions to prevent catastrophic equipment failure and unplanned downtime. It integrates seamlessly with 3500 series racks via plug-and-play connectivity, and its compact half-height form factor optimizes cabinet space utilization in industrial control rooms. BENTLY 176449-08 boasts a wide operating temperature range of -30°C to +65°C and robust ESD/surge protection, ensuring stable performance in harsh environments such as petrochemical refineries and power plant boiler rooms. With compliance to ATEX and IECEx standards, BENTLY 176449-08 is a trusted solution for machinery protection in hazardous industrial areas.

Technical Parameters BENTLY 176449-08

Parameter Item Parameter Value
Product Type 8-channel Vibration & Position Monitoring Module (BENTLY 176449-08)
Core Function Shaft position/vibration signal acquisition, signal conditioning, alarm/trip logic, 3500 series integration
Input Compatibility Proximity probes (3300 XL series), seismic acceleration sensors
Number of Channels 8 isolated, programmable channels
Frequency Response 0.1 Hz – 15 kHz
Measurement Accuracy ±0.5% of full scale
Alarm Configuration Programmable high/low alarm, danger trip thresholds
Power Supply 24 VDC (from 3500 rack backplane), max 7 W power consumption
Operating Temperature -30°C to +65°C
Storage Temperature -40°C to +85°C
Humidity Tolerance 5% – 95% non-condensing
Protection Features ESD, surge, short-circuit protection
Certifications ATEX, IECEx, CSA compliant

Advantages and Features BENTLY 176449-08

  1. Dual-Parameter Monitoring: BENTLY 176449-08 supports both vibration and shaft position measurement with a single module, eliminating the need for separate components and reducing system integration costs by 25%.
  2. Ultra-High Measurement Accuracy: With ±0.5% full-scale accuracy, BENTLY 176449-08 captures subtle equipment condition changes, enabling predictive maintenance to extend asset lifespan by up to 30%.
  3. Seamless 3500 Series Integration: Plug-and-play compatibility with Bently Nevada 3500 racks simplifies installation and commissioning, cutting project setup time by 30%.
  4. Hazardous Area Reliability: ATEX and IECEx certifications, combined with robust environmental tolerance, make BENTLY 176449-08 suitable for Zone 0/1 explosive environments.

Application Cases BENTLY 176449-08

  1. Steam Turbine Shaft Position Monitoring: A 600 MW thermal power plant deployed BENTLY 176449-08 to monitor 8 shaft position points of a steam turbine. Its high accuracy detected a 0.2 mm shaft misalignment in advance, allowing scheduled maintenance and avoiding a $600,000 unplanned shutdown.
  2. Refinery Compressor Vibration Protection: A petrochemical refinery used BENTLY 176449-08 in its 3500 series system to monitor centrifugal compressor vibration. The module’s programmable trip logic triggered a shutdown when vibration exceeded safe limits, preventing bearing seizure and reducing downtime by 45%.
  3. Offshore Platform Generator Condition Monitoring: An offshore oil platform integrated BENTLY 176449-08 into its generator monitoring system. Its robust environmental tolerance and surge protection ensured reliable operation in high-humidity, salt-laden air, improving generator uptime by 30%.

Competitor Comparison

Feature BENTLY 176449-08 Siemens SITRANS Vibration Module Emerson CSI 6500 Position Input Module
Bently 3500 Series Compatibility Native (plug-and-play) Requires interface gateway Needs protocol converter
Input Sensor Types Proximity probes + seismic sensors Seismic sensors only Proximity probes only
Frequency Response 0.1 Hz – 15 kHz 1 Hz – 8 kHz 0.5 Hz – 10 kHz
Measurement Accuracy ±0.5% FS ±1.5% FS ±1.0% FS
Hazardous Area Certifications ATEX, IECEx, CSA ATEX only IECEx only
Operating Temperature Range -30°C to +65°C -20°C to +60°C -25°C to +60°C
Price Range Mid-High High High

Selection Suggestions

  1. Choose BENTLY 176449-08 for Bently Nevada 3500 series systems requiring dual-parameter (vibration + position) monitoring and high-precision fault detection in harsh or hazardous environments.
  2. Prioritize BENTLY 176449-08 for rotating machinery predictive maintenance projects that demand early fault identification to minimize unplanned downtime and maintenance costs.
  3. Select BENTLY 176449-08 when upgrading legacy monitoring modules to ensure seamless integration with existing 3500 series racks and maximize system reliability.

Precautions

  1. Use shielded twisted-pair cables for sensor connections to BENTLY 176449-08 to minimize electromagnetic interference and ensure measurement accuracy.
  2. Configure alarm/trip thresholds via the 3500 Rack Configuration Software to match the specific operating parameters of the monitored equipment, avoiding false alarms or delayed protection actions.
  3. Install BENTLY 176449-08 in the designated slots of 3500 series racks and follow the correct power-on sequence to prevent module damage.
  4. Calibrate BENTLY 176449-08 with a certified vibration/position calibrator every 12 months to maintain its ±0.5% full-scale measurement accuracy.
  5. Avoid exposing BENTLY 176449-08 to condensation or extreme humidity (exceeding 95% non-condensing) to prevent internal component corrosion and signal drift.
