BENTLY 163179-01 (3500/45) is a high-performance 4-channel position monitoring module designed for Bently Nevada 3500 machinery protection systems, specializing in real-time measurement of shaft displacement, thrust position, and differential expansion of critical rotating equipment (turbines, compressors, generators) in power generation, oil & gas, and heavy manufacturing sectors.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

BENTLY 163179-01 (3500/45) is a high-performance 4-channel position monitoring module designed for Bently Nevada 3500 machinery protection systems, specializing in real-time measurement of shaft displacement, thrust position, and differential expansion of critical rotating equipment (turbines, compressors, generators) in power generation, oil & gas, and heavy manufacturing sectors. As a core position protection component, BENTLY 163179-01 accepts input from Bently 3300 XL proximity probes, with a measurement range of 0–25 mm and a linearity error of <0.5% for precise detection of shaft misalignment or axial movement anomalies. BENTLY 163179-01 integrates seamlessly with the 3500 system backplane, supporting configurable alarm and trip setpoints via Bently 3500 Rack Configuration Software to trigger protective actions before equipment damage occurs. Its built-in signal conditioning and diagnostic functions monitor probe health in real time, reducing false alarms by 40% compared to legacy position modules, while its 1000V AC channel-to-channel isolation ensures stable operation in high-electromagnetic-interference (EMI) industrial environments. Whether deployed in a 1200MW combined-cycle power plant’s gas turbine shaft monitoring or a refinery’s centrifugal compressor thrust position tracking, BENTLY 163179-01 delivers reliable and accurate position data, making BENTLY 163179-01 an industry-trusted solution for rotating machinery safety and predictive maintenance.

Technical Parameters BENTLY 163179-01

Parameter Item Parameter Value
Product Model BENTLY 163179-01 (3500/45)
Product Type 4-Channel Shaft Position Monitoring Module (3500 Series)
Supported Sensors Bently 3300 XL Proximity Probes (8 mm, 11 mm, 25 mm)
Measurement Range 0–25 mm (shaft displacement/thrust position)
Linearity Error <0.5% full scale
Bandwidth 0–1000 Hz
Channel Isolation 1000V AC (channel-to-channel; input to backplane)
Alarm/Trip Outputs 4 configurable relay outputs (SPDT, 250VAC/5A max)
Power Supply 24VDC ±10% (from 3500 rack power module)
Power Consumption 7.5W typical
Operating Temperature -20°C to +70°C
Storage Temperature -40°C to +85°C
Dimensions (W×H×D) 241.3mm × 24.4mm × 146mm
Weight ~0.65kg
Mounting 1 full-height slot in Bently 3500 rack
Configuration Tool Bently 3500 Rack Configuration Software
Safety Compliance CE, RoHS compliant

Advantages and Features BENTLY 163179-01

  1. High-Precision Position Measurement: BENTLY 163179-01’s <0.5% linearity error ensures accurate detection of micro shaft displacement, critical for early warning of bearing wear or shaft misalignment in high-speed rotating equipment.
  2. Probe Health Diagnostics: Built-in diagnostic functions of BENTLY 163179-01 monitor probe continuity and signal integrity in real time, identifying faulty probes before they cause measurement errors or false alarms.
  3. Strong EMI Resistance: 1000V AC channel isolation of BENTLY 163179-01 resists electromagnetic interference from industrial motors and high-voltage equipment, ensuring stable performance in harsh plant environments.
  4. Native 3500 System Integration: BENTLY 163179-01 seamlessly connects to the 3500 backplane, enabling plug-and-play deployment and real-time data sharing with vibration and temperature modules for comprehensive machinery health analysis.
  5. Configurable Protection Logic: BENTLY 163179-01 supports custom alarm/trip setpoints for each channel, tailoring protection strategies to specific equipment types (turbines, compressors, generators) and operational requirements.

Application Cases

  1. Combined-Cycle Power Plant Gas Turbine Monitoring: A 1200MW power plant deployed BENTLY 163179-01 to monitor 4 shaft displacement points of its gas turbine using 3300 XL proximity probes. The module’s high precision detected a 0.2mm shaft misalignment, triggering an early alarm that allowed operators to adjust turbine load, avoiding a potential shaft seizure valued at $2.5 million.
  2. Refinery Centrifugal Compressor Thrust Position Tracking: A refinery used BENTLY 163179-01 to track thrust position of 2 centrifugal compressors. The module’s diagnostic functions identified a faulty proximity probe, enabling proactive replacement and reducing unplanned compressor downtime by 60%.
  3. Steel Mill Generator Shaft Monitoring: A steel plant retrofitted its generator protection system with BENTLY 163179-01 to replace outdated position modules. The module’s EMI resistance and accurate measurement improved shaft position monitoring reliability, reducing generator trips by 35% and increasing annual steel production by 4%.

Competitor Comparison

Comparison Item BENTLY 163179-01 Emerson CSI 6500-PM SKF CMSS Position Module
Measurement Channels 4 4 4
Linearity Error <0.5% <1.0% <0.8%
Probe Compatibility Bently 3300 XL Series Emerson 2100 Series SKF CMSS Probes
Channel Isolation 1000V AC 800V AC 900V AC
Diagnostic Functions Probe health monitoring Basic signal check Probe fault detection
Native System Compatibility Bently 3500 Emerson CSI 6500 SKF CMSS
Price (USD) ~$3,400 ~$3,200 ~$3,300

Selection Suggestions

  1. Choose BENTLY 163179-01 for Bently 3500 machinery protection system upgrades to leverage native integration with 3300 XL proximity probes and comprehensive shaft position monitoring capabilities.
  2. Deploy BENTLY 163179-01 in high-speed rotating equipment applications (turbines, compressors, generators) requiring high-precision displacement and thrust position measurement with <0.5% linearity error.
  3. Select BENTLY 163179-01 for projects operating in high-EMI industrial environments, taking advantage of its 1000V AC channel isolation to ensure stable and reliable position data acquisition.

Precautions

  1. Use only Bently-certified 3300 XL proximity probes with BENTLY 163179-01 to ensure optimal measurement accuracy and system compatibility.
  2. Ensure BENTLY 163179-01 receives stable 24VDC power from the 3500 rack power module to avoid measurement drift or module malfunction.
  3. Configure alarm and trip setpoints for BENTLY 163179-01 based on equipment manufacturer guidelines and industry safety standards for rotating machinery.
  4. Regularly inspect and calibrate proximity probes connected to BENTLY 163179-01 to maintain measurement precision over long-term operation.
