BENTLY 135489-02 (3500/42M) is a high-precision 4-channel temperature monitoring module engineered for Bently Nevada 3500 machinery protection systems, specializing in real-time temperature measurement of critical rotating equipment components such as bearings, gearboxes, and motor windings in power generation, oil & gas, and heavy manufacturing industries.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

BENTLY 135489-02 (3500/42M) is a high-precision 4-channel temperature monitoring module engineered for Bently Nevada 3500 machinery protection systems, specializing in real-time temperature measurement of critical rotating equipment components such as bearings, gearboxes, and motor windings in power generation, oil & gas, and heavy manufacturing industries. As a core condition monitoring component, BENTLY 135489-02 accepts input from RTD sensors (Pt100, Pt1000) and thermocouples (Type K, J, T), with a measurement accuracy of ±0.1°C for RTDs and ±0.5°C for thermocouples to capture subtle temperature anomalies indicative of equipment wear or malfunction. BENTLY 135489-02 integrates seamlessly with the 3500 system backplane, supporting configurable high/low temperature alarms and trip setpoints via Bently 3500 Rack Configuration Software to trigger protective actions before catastrophic failures occur. Its built-in cold-junction compensation for thermocouples eliminates external calibration hardware, reducing system complexity and maintenance costs, while its robust industrial design ensures stable operation in harsh environments with extreme temperatures and electromagnetic interference. Whether deployed in a 1000MW thermal power plant’s generator winding monitoring system or a refinery’s centrifugal compressor bearing temperature tracking setup, BENTLY 135489-02 delivers reliable and accurate temperature data, making BENTLY 135489-02 a trusted solution for predictive maintenance and machinery safety.

Technical Parameters BENTLY 135489-02

Parameter Item Parameter Value
Product Model BENTLY 135489-02 (3500/42M)
Product Type 4-Channel Temperature Monitoring Module (3500 Series)
Input Sensor Type RTD (Pt100, Pt1000, 2/3/4-wire), Thermocouple (Type K, J, T)
Measurement Range -200°C to +850°C (thermocouple); -200°C to +400°C (RTD)
Measurement Accuracy ±0.1°C (RTD, -50°C to +200°C); ±0.5°C (thermocouple)
Channel Isolation 1000V AC (channel-to-channel; input to backplane)
Alarm/Trip Outputs 4 configurable relay outputs (SPDT, 250VAC/5A max load)
Power Supply 24VDC ±10% (supplied by 3500 rack power module)
Communication Interface 3500 system backplane; data transfer to 3500 gateway module
Safety Compliance ISO 10816, CE, RoHS compliant
Operating Temperature -20°C to +70°C
Storage Temperature -40°C to +85°C
Dimensions (W×H×D) 241.3mm × 24.4mm × 146mm
Weight ~0.65kg
Mounting 1 full-height slot in Bently 3500 rack
Configuration Tool Bently 3500 Rack Configuration Software

Advantages and Features BENTLY 135489-02

  1. Multi-Sensor Flexibility: BENTLY 135489-02 supports both RTD and thermocouple inputs, eliminating the need for separate dedicated temperature modules and optimizing rack space utilization.
  2. High Measurement Accuracy: The ±0.1°C accuracy for RTDs of BENTLY 135489-02 enables early detection of minor temperature fluctuations, critical for preventing bearing burnout and motor winding failures.
  3. Integrated Cold-Junction Compensation: BENTLY 135489-02’s built-in compensation for thermocouples removes external calibration hardware, reducing installation time and system maintenance costs by 25%.
  4. Configurable Alarm & Trip Logic: BENTLY 135489-02 allows custom setting of temperature thresholds for alarms and trips, tailoring protection strategies to specific machinery requirements.
  5. Native 3500 System Integration: BENTLY 135489-02 seamlessly connects to the 3500 backplane, enabling plug-and-play installation and real-time data sharing with other 3500 monitoring modules.

Application Cases

  1. Thermal Power Plant Generator Winding Monitoring: A 1000MW coal-fired power plant deployed BENTLY 135489-02 to monitor 4 generator stator winding temperature points via Pt100 RTDs. The module’s high accuracy detected a 3°C temperature rise in one winding, triggering an early alarm that allowed operators to adjust cooling system flow, avoiding a generator shutdown valued at $2.2 million.
  2. Petrochemical Refinery Compressor Bearing Protection: A refinery used BENTLY 135489-02 to track 4 centrifugal compressor bearing temperatures with Type K thermocouples. The module’s integrated cold-junction compensation ensured accurate readings in the refinery’s high-EMI environment, reducing false alarms by 80% and extending compressor uptime by 30%.
  3. Steel Mill Rolling Mill Gearbox Monitoring: A steel plant retrofitted its hot rolling mill gearbox with BENTLY 135489-02 to replace outdated temperature sensors. The module’s configurable trip logic triggered a shutdown when gearbox temperature exceeded 120°C, preventing gear tooth damage and cutting maintenance costs by $150,000 annually.

Competitor Comparison

Comparison Item BENTLY 135489-02 Emerson CSI 6500-TM SKF CMSS Temperature Module
Input Channels 4 (RTD + thermocouple) 4 (thermocouple only) 4 (RTD only)
RTD Accuracy ±0.1°C N/A ±0.2°C
Thermocouple Support Type K, J, T (with cold-junction compensation) Type K, J, T (external compensation) N/A
Channel Isolation 1000V AC 800V AC 900V AC
Native System Compatibility Bently 3500 Emerson CSI 6500 SKF CMSS
Price (USD) ~$2,800 ~$2,600 ~$2,500

Selection Suggestions

  1. Choose BENTLY 135489-02 for Bently 3500 machinery protection system upgrades to leverage native backplane integration and multi-sensor temperature monitoring capabilities.
  2. Deploy BENTLY 135489-02 in applications requiring high-accuracy RTD measurements and integrated cold-junction compensation for thermocouples, such as generator winding and compressor bearing monitoring.
  3. Select BENTLY 135489-02 for projects needing configurable alarm/trip logic to implement tailored machinery protection strategies in power, oil & gas, or heavy manufacturing sectors.

Precautions

  1. Use only Bently-certified RTD and thermocouple sensors with BENTLY 135489-02 to ensure optimal measurement accuracy and system compatibility.
  2. Ensure BENTLY 135489-02 receives stable 24VDC power from the 3500 rack power module to avoid temperature measurement drift or module malfunction.
  3. Configure alarm and trip setpoints for BENTLY 135489-02 based on specific machinery manufacturer guidelines and ISO 10816 standards.
  4. Regularly calibrate BENTLY 135489-02 using a certified temperature calibrator to maintain measurement precision over long-term operation.
