BENTLY 135489-01

BENTLY 135489-01 is a 4 – channel Prox/Accel I/O module with internal barriers and internal terminations, specially designed for Bently Nevada 3500 series machinery protection systems, enabling safe and reliable sensor – to – rack signal interface in hazardous industrial areas.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

BENTLY 135489-01 is a 4 – channel Prox/Accel I/O module with internal barriers and internal terminations, specially designed for Bently Nevada 3500 series machinery protection systems, enabling safe and reliable sensor – to – rack signal interface in hazardous industrial areas. As a key I/O interface component, BENTLY 135489-01 integrates intrinsic safety barriers internally, eliminating the need for external safety barriers and simplifying system design while ensuring compliance with ATEX and IECEx standards for Zone 0/1 hazardous locations. BENTLY 135489-01 supports 4 isolated proximity or acceleration sensor channels, providing precise signal conditioning for vibration and shaft position monitoring in turbines, compressors, and generators. It seamlessly fits into 3500 series racks, and its internal termination design reduces wiring complexity and installation time by up to 30% compared with external termination modules. BENTLY 135489-01 maintains amplitude accuracy of 3% @ 10 kHz and phase accuracy of -11° @ 10 kHz, ensuring reliable data transmission for critical machinery condition monitoring. With reverse polarity, over – voltage, and short – circuit protection, BENTLY 135489-01 is a robust choice for harsh industrial environments demanding both safety and performance.

Technical Parameters BENTLY 135489-01

Parameter Item Parameter Value
Product Type 4 – channel Prox/Accel I/O Module with Internal Barriers (BENTLY 135489-01)
Core Function Intrinsically safe sensor signal interface, signal conditioning, 3500 series rack integration, fault protection
Number of Channels 4 isolated proximity/acceleration sensor channels
Termination Type Internal terminations with internal intrinsic safety barriers
Bandwidth 30 kHz
Amplitude Accuracy 3% @ 10 kHz, -15/+10% @ 30 kHz
Phase Accuracy -11° @ 10 kHz
Power Consumption 7 watts (24 VDC)
Form Factor Half – height module, compatible with 3500 series standard racks
Operating Temperature -30°C to +65°C
Storage Temperature -40°C to +85°C
Safety Certifications ATEX, IECEx compliant

Advantages and Features BENTLY 135489-01

  1. Integrated Intrinsic Safety Barriers: BENTLY 135489-01 has internal safety barriers, which avoids the cost and space of external barriers and ensures compliance with hazardous area safety standards.
  2. 4 Isolated Channels: The 4 isolated channels of BENTLY 135489-01 prevent cross – talk between sensor signals, ensuring measurement accuracy for multi – point machinery monitoring.
  3. Simplified Wiring: Internal termination design of BENTLY 135489-01 reduces on – site wiring work, shortens installation time and lowers the risk of wiring errors.
  4. Robust Protection: It is equipped with reverse polarity, over – voltage, and short – circuit protection, which can effectively prevent module damage and ensure continuous operation of the monitoring system.

Application Cases BENTLY 135489-01

  1. Offshore Platform Compressor Monitoring: An offshore oil platform used BENTLY 135489-01 in its 3500 series monitoring system for gas compressors. The integrated internal barriers of the module met Zone 1 hazardous area requirements, reducing system footprint by 25% and cutting installation costs by $12,000.
  2. Refinery Turbine Vibration Monitoring: A petrochemical refinery deployed BENTLY 135489-01 to interface proximity sensors for turbine shaft vibration monitoring. Its 4 – channel design covered all critical measurement points, and the internal terminations reduced wiring time by 30% during system commissioning.
  3. Power Plant Generator Condition Monitoring: A coal – fired power plant integrated BENTLY 135489-01 into its 3500 series generator monitoring system. The module’s high accuracy and fault protection features prevented false alarms and ensured reliable monitoring of generator bearing vibration.

Competitor Comparison

Feature BENTLY 135489-01 Siemens SITRANS I/O Module (Intrinsically Safe) Emerson CSI 6500 I/O Module
Bently 3500 Series Compatibility Native (plug – and – play) Requires interface adapter Needs protocol converter
Number of Channels 4 (Prox/Accel) 4 (optional 2 – channel expansion) 4
Intrinsic Safety Barriers Internal (built – in) External (separate unit) Internal (built – in)
Bandwidth 30 kHz 20 kHz 25 kHz
Operating Temperature Range -30°C to +65°C -20°C to +60°C -25°C to +60°C
Safety Certifications ATEX, IECEx ATEX, IECEx ATEX
Installation Complexity Low (internal terminations) High (external barriers + wiring) Medium

Selection Suggestions

  1. Choose BENTLY 135489-01 for 3500 series systems in Zone 0/1 hazardous areas that need 4 Prox/Accel channels and intrinsic safety compliance.
  2. Prioritize BENTLY 135489-01 for projects aiming to simplify design and reduce installation time, as its internal barriers and terminations eliminate external components.
  3. Select BENTLY 135489-01 when monitoring critical rotating machinery that requires high – accuracy signal transmission (3% amplitude accuracy @ 10 kHz) and robust fault protection.

Precautions

  1. Confirm that the sensors connected to BENTLY 135489-01 are compatible with its internal barriers and follow intrinsic safety wiring guidelines to avoid safety risks.
  2. Use the 3500 Rack Configuration Software to correctly set channel parameters of BENTLY 135489-01 to ensure accurate signal conditioning and data transmission.
  3. Install BENTLY 135489-01 in the designated slots of 3500 series racks and follow the correct power – on sequence to prevent module damage.
  4. Regularly check the wiring connections of BENTLY 135489-01 to avoid loose connections that may cause signal loss or measurement errors.
  5. Do not exceed the module’s input voltage and current limits to prevent damage to the internal barriers and signal conditioning circuits of BENTLY 135489-01.
