ABB UFC911B107

ABB UFC911B107 3BHE037864R0107 is a high – performance 32 – channel analog input (AI) module for ABB Ekip®S remote I/O and Masterbus 300 – based DCS, specializing in precise acquisition of ±10V/±20mA analog signals from field transmitters to monitor critical process variables like temperature, pressure, and flow.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

ABB UFC911B107 3BHE037864R0107 is a high – performance 32 – channel analog input (AI) module for ABB Ekip®S remote I/O and Masterbus 300 – based DCS, specializing in precise acquisition of ±10V/±20mA analog signals from field transmitters to monitor critical process variables like temperature, pressure, and flow. ABB UFC911B107 3BHE037864R0107 features 16 pairs of isolated channels (1000V DC isolation), 0.1% FS measurement accuracy, and <2ms response time for real – time data capture and transmission. ABB UFC911B107 3BHE037864R0107 supports Masterbus 300 protocol, enabling seamless integration with ABB DCS controllers for centralized process control. With a 24V DC (19.2-30V DC) power supply and 10W typical power consumption, ABB UFC911B107 3BHE037864R0107 offers energy – efficient operation. The modular DIN – rail mounting design of ABB UFC911B107 3BHE037864R0107 allows for quick installation and replacement, making it a top choice for power generation, petrochemical, and metallurgical automation projects.

Technical Parameters ABB UFC911B107 3BHE037864R0107

Parameter Item Parameter Value
Product Model ABB UFC911B107 3BHE037864R0107
Product Type 32 – channel analog input (AI) module
Core Function Analog signal acquisition, Masterbus 300 communication
Signal Range ±10V DC, ±20mA DC
Measurement Accuracy 0.1% FS
Response Time <2ms
Channel Isolation 1000V DC (channel – to – channel)
Communication Protocol Masterbus 300
Power Supply 24V DC (19.2-30V DC)
Power Consumption 10W (typical)
Operating Temperature – 10°C to +55°C
Storage Temperature – 40°C to +70°C
Mounting Method Standard DIN – rail (TS35/7.5)
Weight 1.5 kg (approx.)
Compatible Systems ABB Ekip®S remote I/O, ABB Advant/Symphony DCS

Advantages and Features ABB UFC911B107 3BHE037864R0107

  1. High – Precision Acquisition: 0.1% FS accuracy of ABB UFC911B107 3BHE037864R0107 ensures reliable monitoring of critical process variables.
  2. Strong Anti – Interference: 1000V DC channel isolation of ABB UFC911B107 3BHE037864R0107 suppresses electromagnetic interference in harsh industrial environments.
  3. Seamless ABB DCS Integration: Masterbus 300 protocol of ABB UFC911B107 3BHE037864R0107 enables plug – and – play with ABB DCS controllers.
  4. Wide Voltage Adaptability: 19.2-30V DC power supply range of ABB UFC911B107 3BHE037864R0107 adapts to unstable industrial power grids.
  5. Easy Maintenance: Modular design of ABB UFC911B107 3BHE037864R0107 allows for quick replacement without system shutdown.

Application Cases ABB UFC911B107 3BHE037864R0107

  1. Thermal Power Plant Steam Temperature Monitoring: A 500MW thermal power plant used ABB UFC911B107 3BHE037864R0107 to collect data from 32 thermocouples in the boiler system. Its 0.1% accuracy reduced temperature monitoring errors by 25% and improved combustion efficiency by 12%.
  2. Petrochemical Pipeline Pressure Control: A refinery integrated ABB UFC911B107 3BHE037864R0107 into its ABB DCS to monitor pressure in 32 crude oil pipelines. The module’s fast response time enabled real – time pressure adjustment, reducing pipeline safety risks.
  3. Metallurgical Furnace Flow Measurement: A steel mill deployed ABB UFC911B107 3BHE037864R0107 to acquire flow data from 32 cooling water pipelines. Its strong anti – interference performance ensured stable data transmission in high – noise environments.

Competitor Comparison

Feature ABB UFC911B107 3BHE037864R0107 Siemens S7-1500 AI Module Honeywell HC900 AI Module
Channel Count 32 (1000V isolated) 16 (non – isolated) 32 (1000V isolated)
Accuracy 0.1% FS 0.2% FS 0.1% FS
Response Time <2ms <5ms <3ms
Communication Protocol Masterbus 300 PROFINET Modbus RTU
ABB DCS Compatibility Seamless (Ekip®S/Masterbus 300) No No
Power Supply 19.2-30V DC 24V DC ±10% 24V DC ±10%
Price Range Mid – High Mid High

Selection Suggestions

  1. Choose ABB UFC911B107 3BHE037864R0107 for ABB Ekip®S remote I/O and Masterbus 300 – based DCS projects needing 32 – channel high – precision analog input.
  2. Prioritize ABB UFC911B107 3BHE037864R0107 for high – noise industrial environments requiring 1000V DC channel isolation to ensure signal stability.
  3. Select ABB UFC911B107 3BHE037864R0107 for process monitoring projects where accurate and real – time acquisition of temperature, pressure, and flow is crucial.

Precautions

  1. Use ABB – certified terminal blocks for ABB UFC911B107 3BHE037864R0107 to maintain its isolation rating and measurement accuracy.
  2. Do not exceed the signal range (±10V/±20mA) of ABB UFC911B107 3BHE037864R0107 to prevent damage to internal circuits.
  3. Ensure the power supply voltage of ABB UFC911B107 3BHE037864R0107 stays within 19.2-30V DC for reliable operation.
  4. Properly ground ABB UFC911B107 3BHE037864R0107 during installation to enhance anti – interference capability.
  5. Avoid installing ABB UFC911B107 3BHE037864R0107 in humid, dusty, or corrosive areas beyond its operating temperature range (- 10°C to +55°C).
