ABB UFC911B104 3BHE037864R0104 (also known as CVMI2B) is a high – precision analog I/O module tailored for ABB Ekip®S remote I/O systems, acting as a bridge between field devices and DCS controllers to convert ±10V/±20mA analog signals for accurate process monitoring and control.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

ABB UFC911B104 3BHE037864R0104 (also known as CVMI2B) is a high – precision analog I/O module tailored for ABB Ekip®S remote I/O systems, acting as a bridge between field devices and DCS controllers to convert ±10V/±20mA analog signals for accurate process monitoring and control. ABB UFC911B104 3BHE037864R0104 comes with 32 isolated channels (16 AI + 16 AO), 0.1% measurement accuracy, and <2ms response time, enabling real – time data capture for critical industrial variables like temperature, pressure, and flow. ABB UFC911B104 3BHE037864R0104 supports Masterbus 300 protocol for seamless integration with ABB DCS, and its 1000V DC channel – to – channel isolation effectively suppresses electromagnetic interference in harsh industrial settings. With a 24V DC (19.2-30V DC) power supply and typical 12W power consumption, ABB UFC911B104 3BHE037864R0104 balances energy efficiency and high performance. The modular DIN – rail mounting design of ABB UFC911B104 3BHE037864R0104 allows for quick installation and replacement, making it an ideal choice for power, petrochemical, and metallurgical automation projects.

Technical Parameters ABB UFC911B104 3BHE037864R0104

Parameter Item Parameter Value
Product Model ABB UFC911B104 3BHE037864R0104
Product Type 32 – channel analog I/O module (16 AI + 16 AO)
Core Function Analog signal acquisition/transmission, Masterbus 300 communication
Signal Range AI/AO: ±10V DC, ±20mA DC
Measurement Accuracy 0.1% FS
Response Time <2ms
Channel Isolation 1000V DC (channel – to – channel)
Communication Protocol Masterbus 300
Power Supply 24V DC (19.2-30V DC)
Power Consumption 12W (typical)
Operating Temperature – 10°C to +55°C
Storage Temperature – 40°C to +70°C
Mounting Standard DIN – rail (TS35/7.5)
Weight 2.5 kg (approx.)
Protection Rating IP20

Advantages and Features ABB UFC911B104 3BHE037864R0104

  1. High Precision & Fast Response: 0.1% accuracy and <2ms response time of ABB UFC911B104 3BHE037864R0104 ensure precise and real – time signal processing for critical control loops.
  2. High – Density Isolated Channels: 32 isolated channels (16 AI + 16 AO) of ABB UFC911B104 3BHE037864R0104 meet multi – parameter monitoring needs while avoiding signal cross – talk.
  3. Strong Anti – Interference: 1000V DC isolation of ABB UFC911B104 3BHE037864R0104 eliminates electrical noise in heavy – industry environments.
  4. Seamless ABB DCS Integration: Masterbus 300 protocol of ABB UFC911B104 3BHE037864R0104 enables plug – and – play with ABB Ekip®S remote I/O and DCS controllers.
  5. Easy Maintenance: Modular design of ABB UFC911B104 3BHE037864R0104 allows for quick replacement without system shutdown, minimizing downtime.

Application Cases ABB UFC911B104 3BHE037864R0104

  1. Thermal Power Plant Steam Pressure Control: A 600MW power plant used ABB UFC911B104 3BHE037864R0104 to monitor 16 steam pressure transmitters and control 16 control valves. Its 0.1% accuracy reduced pressure fluctuations by 20% and improved power generation efficiency by 15%.
  2. Petrochemical Refinery Flow Regulation: A refinery integrated ABB UFC911B104 3BHE037864R0104 into its ABB DCS to collect flow data from 16 pipelines and adjust 16 control valves. The module’s fast response time ensured stable flow control during process load changes.
  3. Metallurgical Furnace Temperature Control: A steel mill deployed ABB UFC911B104 3BHE037864R0104 to monitor 16 thermocouples and control 16 heating elements. Its strong anti – interference performance maintained temperature control accuracy within ±1°C in high – noise environments.

Competitor Comparison

Feature ABB UFC911B104 3BHE037864R0104 Siemens S7-1500 AI/AO Module Honeywell HC900 Analog I/O Module
Channel Configuration 16 AI + 16 AO (1000V isolated) 8 AI + 8 AO (non – isolated) 16 AI + 16 AO (1000V isolated)
Accuracy 0.1% FS 0.2% FS 0.1% FS
Response Time <2ms <5ms <3ms
Communication Protocol Masterbus 300 PROFINET Modbus RTU
ABB DCS Compatibility Seamless (Ekip®S/Masterbus 300) No No
Power Supply 19.2-30V DC 24V DC ±10% 24V DC ±10%
Price Range Mid – High Mid High

Selection Suggestions

  1. Select ABB UFC911B104 3BHE037864R0104 for ABB Ekip®S remote I/O and Masterbus 300 – based DCS projects requiring 32 – channel (16 AI + 16 AO) analog I/O with high accuracy and fast response.
  2. Prioritize ABB UFC911B104 3BHE037864R0104 for applications in high – noise industrial environments needing 1000V DC channel isolation to ensure signal stability.
  3. Choose ABB UFC911B104 3BHE037864R0104 for process control projects where precise monitoring and real – time adjustment of temperature, pressure, and flow are essential.

Precautions

  1. Use ABB – certified terminal blocks for ABB UFC911B104 3BHE037864R0104 to maintain its isolation rating and measurement accuracy.
  2. Do not exceed the signal range (±10V/±20mA) of ABB UFC911B104 3BHE037864R0104 to prevent damage to the module’s internal circuits.
  3. Ensure the power supply voltage of ABB UFC911B104 3BHE037864R0104 stays within 19.2-30V DC for reliable operation.
  4. Properly ground ABB UFC911B104 3BHE037864R0104 during installation to enhance its anti – interference capability.
  5. Avoid installing ABB UFC911B104 3BHE037864R0104 in humid, dusty, or corrosive areas beyond its operating temperature range (- 10°C to +55°C).
