ABB UFC721BE101 3BHE021889R0101 (ADCVI Voltage/Current Module) is a high – performance analog output (AO) module for ABB Advant/Symphony DCS, dedicated to converting digital control signals from controllers into 4-20 mA current or 0-10 V voltage signals to drive industrial actuators like control valves and variable – frequency drives.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

ABB UFC721BE101 3BHE021889R0101 (ADCVI Voltage/Current Module) is a high – performance analog output (AO) module for ABB Advant/Symphony DCS, dedicated to converting digital control signals from controllers into 4-20 mA current or 0-10 V voltage signals to drive industrial actuators like control valves and variable – frequency drives. ABB UFC721BE101 3BHE021889R0101 features 8 isolated AO channels with 16 – bit resolution and 0.1% of span accuracy, ensuring precise control signal output in harsh industrial settings. ABB UFC721BE101 3BHE021889R0101 supports Masterbus 300 protocol, enabling seamless real – time data exchange with DCS controllers, and its 24V DC (19.2-30V DC) power supply with typical 5W power consumption ensures energy – efficient long – term operation. The modular and compact structure of ABB UFC721BE101 3BHE021889R0101 allows for easy installation and maintenance, and ABB UFC721BE101 3BHE021889R0101 is also a replacement for the legacy UFC721AE module, offering enhanced stability and compatibility. ABB UFC721BE101 3BHE021889R0101’s channel – to – channel isolation (1000V DC) eliminates cross – talk, making it ideal for power, petrochemical, and metallurgical automation.

Technical Parameters ABB UFC721BE101 3BHE021889R0101

Parameter Item Parameter Value
Product Model ABB UFC721BE101 3BHE021889R0101 (ADCVI)
Product Type 8 – channel analog output (AO) module
Core Function Digital – to – analog conversion, AO signal output, Masterbus 300 communication
Output Signal 4-20 mA DC, 0-10 V DC
Number of Channels 8 (isolated)
Accuracy 0.1% of span
Resolution 16 – bit
Isolation Channel – to – channel: 1000V DC
Power Supply 24V DC (19.2-30V DC)
Power Consumption 5W (typical)
Communication Protocol Masterbus 300
Operating Temperature – 10°C to +55°C
Storage Temperature – 40°C to +70°C
Mounting Standard DIN – rail
Weight 0.68 kg (approx.)

Advantages and Features ABB UFC721BE101 3BHE021889R0101

  1. High Precision Output: ABB UFC721BE101 3BHE021889R0101 delivers 0.1% accuracy and 16 – bit resolution for precise actuator control.
  2. Strong Anti – Interference: 1000V DC isolation of ABB UFC721BE101 3BHE021889R0101 prevents signal cross – talk and electrical noise in industrial environments.
  3. Seamless DCS Integration: Masterbus 300 support of ABB UFC721BE101 3BHE021889R0101 ensures real – time data exchange with ABB Advant/Symphony DCS.
  4. Energy – Saving & Easy Maintenance: 5W typical power consumption and modular design of ABB UFC721BE101 3BHE021889R0101 reduce costs and downtime.
  5. Legacy Module Replacement: ABB UFC721BE101 3BHE021889R0101 is a drop – in replacement for UFC721AE, minimizing upgrade costs.

Application Cases ABB UFC721BE101 3BHE021889R0101

  1. Thermal Power Plant Control Valve Regulation: A 660MW power plant used ABB UFC721BE101 3BHE021889R0101 to control 32 boiler feedwater control valves. The module’s precision reduced steam pressure fluctuation by 30% and improved efficiency by 15%.
  2. Petrochemical Reactor Feed Control: A refinery integrated ABB UFC721BE101 3BHE021889R0101 into its Advant DCS to drive 24 flow control valves. Its isolation cut signal interference – related downtime by 25%.
  3. Metallurgical Rolling Mill Speed Control: A steel mill deployed ABB UFC721BE101 3BHE021889R0101 to control 16 VFDs for rolling mills. Real – time Masterbus 300 communication improved speed regulation accuracy by 20%.

Competitor Comparison

Feature ABB UFC721BE101 3BHE021889R0101 Siemens S7-1500 AO 8×4-20mA Honeywell HC900 AO Module
Channel Count 8 (1000V isolated) 8 (non – isolated) 8 (1000V isolated)
Accuracy 0.1% of span 0.2% of span 0.15% of span
Resolution 16 – bit 14 – bit 16 – bit
Protocol Masterbus 300 Profinet Modbus
ABB DCS Compatibility Seamless (Advant/Symphony) No No
Legacy Replacement Yes (UFC721AE) No No
Price Range Mid Mid Mid – High

Selection Suggestions

  1. Select ABB UFC721BE101 3BHE021889R0101 for ABB Advant/Symphony DCS projects needing 8 – channel AO with Masterbus 300 and 1000V isolation.
  2. Prioritize ABB UFC721BE101 3BHE021889R0101 for 0.1% accuracy and legacy UFC721AE upgrades to save integration costs.
  3. Choose ABB UFC721BE101 3BHE021889R0101 for noisy industrial sites requiring channel isolation to ensure control signal stability.

Precautions

  1. Use ABB – certified terminal blocks for ABB UFC721BE101 3BHE021889R0101 to maintain isolation and communication reliability.
  2. Keep power supply within 19.2-30V DC to avoid damaging ABB UFC721BE101 3BHE021889R0101’s power circuit.
  3. Ground ABB UFC721BE101 3BHE021889R0101 properly during installation to enhance anti – interference performance.
  4. Calibrate ABB UFC721BE101 3BHE021889R0101 annually with a standard signal calibrator to retain accuracy.
  5. Avoid installing ABB UFC721BE101 3BHE021889R0101 in humid, dusty, or corrosive areas beyond its operating temperature range.
