ABB+PP865 3BSE042236R1

Description

Product Name:

• ABB+PP865 3BSE042236R1 Touch Screen

Product Description:

The ABB+PP865 3BSE042236R1 is a touchscreen terminal designed for user interface operations in industrial control systems. This device offers a robust, reliable, and intuitive interface for operators to interact with ABB’s automation and control systems, facilitating real-time monitoring, control, and system diagnostics. It is built to withstand harsh industrial environments and can be integrated into a variety of ABB automation solutions, including DCS (Distributed Control Systems), PLCs (Programmable Logic Controllers), and other process control applications.

Product Features:

• Touchscreen Interface: A high-resolution touchscreen display for easy interaction.
• Industrial Durability: Designed to perform reliably in tough environments, including factories and production lines.
• Integration with ABB Systems: Fully compatible with ABB’s automation systems such as DCS and PLC-based systems.
• Advanced Display Capabilities: Clear, high-definition graphics and text for better clarity and ease of use.
• User-Friendly Interface: Intuitive navigation and interface designed to improve operator productivity and reduce training time.
• Real-time Monitoring and Control: Allows operators to monitor system parameters and make adjustments in real-time.

Product Parameters and Specifications:

• Model: PP865 (Part Number 3BSE042236R1)
• Display Type: Touchscreen (likely TFT LCD or similar technology)
• Resolution: High resolution for clear and detailed visuals (specific resolution varies based on the exact model)
• Screen Size: Typically ranges from 5.7 to 15 depending on specific configurations.
• Operating Voltage: Usually operates at low voltage (24V DC is common for industrial screens).
• Operating Temperature Range: Typically -10°C to 60°C (14°F to 140°F) for industrial environments.
• Input/Output: Standard I/O options for interfacing with control systems (Ethernet, serial, etc.)
• Communication Protocols: Support for common industrial communication protocols (Modbus, Profibus, Ethernet/IP, etc.)
• Power Consumption: Generally low power consumption, depending on the screen size and specific configuration.
• Mounting: Panel-mounted design, making it suitable for integration into control panels or operator stations.
• Environment Protection: IP65 or equivalent protection against dust and water ingress for use in demanding industrial conditions.

Product Use:

The ABB+PP865 3BSE042236R1 touchscreen is primarily used in:

• Industrial Automation: As a HMI (Human-Machine Interface) for managing automated processes in manufacturing plants, power plants, and other facilities.
• Control Rooms: For displaying and controlling various industrial processes in real time.
• Monitoring Systems: To monitor parameters such as temperature, pressure, flow rates, and other variables in industrial systems.
• Operator Interface: As the primary point of interaction between the operator and the control system, enabling the setting of process parameters, data visualization, and troubleshooting.
• Process Control: Typically integrated into ABB’s distributed control systems (DCS) or programmable logic controllers (PLCs) for monitoring and adjusting various system functions.

Applications:

• Power Generation Plants
• Manufacturing Plants
• Oil & Gas Refineries
• Chemical and Petrochemical Industries
• Water Treatment Facilities
• Industrial Automation and Control Systems
