ABB 3BSE069055R1 DO828

Description

Product Description

Product Parameters

Advantages and Features

1. Fast & Reliable Switching Performance: ABB 3BSE069055R1 DO828 features a ≤10μs response time and solid-state MOSFET outputs, ensuring rapid and consistent control of field devices, which is critical for high-speed production lines and time-sensitive industrial processes.
2. Flexible Output Configuration: The module’s channels are configurable for sourcing or sinking operation, allowing ABB 3BSE069055R1 DO828 to adapt to diverse actuator and relay types without additional adapters, reducing system complexity and deployment costs.
3. Robust Overload Protection: Equipped with built-in overcurrent and overtemperature protection, ABB 3BSE069055R1 DO828 automatically limits current or shuts down in abnormal conditions, preventing damage to the module and connected field equipment.
4. Seamless ABB Ecosystem Integration: Natively optimized for ABB’s core PLC series, the module enables plug-and-play setup via ABB’s Control Builder M software, simplifying configuration and ensuring synchronized operation with the central control system.
5. Space-Saving & Durable Design: The compact DIN rail-mounted form factor maximizes control cabinet space utilization, while industrial-grade components ensure ABB 3BSE069055R1 DO828 withstands electromagnetic interference, extreme temperatures, and harsh industrial environments.

Application Cases in Application Fields

1. Automotive Component Manufacturing: A European automotive parts plant integrated ABB 3BSE069055R1 DO828 into its stamping and molding control systems to operate hydraulic actuators and robotic clamps. The module’s fast response time improved production line cycle efficiency by 10%, while its overload protection reduced equipment downtime.
2. Water & Wastewater Treatment: A municipal wastewater treatment facility in North America adopted ABB 3BSE069055R1 DO828 to control pump motors, valve actuators, and chemical dosing systems. Its configurable outputs adapted to different pump types, and its wide temperature tolerance ensured reliable operation in damp, variable-temperature environments.
3. Packaging Industry: A global food packaging plant deployed ABB 3BSE069055R1 DO828 to oversee sealing machines, labeling devices, and conveyor belt motors. The module’s solid-state outputs delivered long-term reliability with minimal wear, reducing maintenance frequency and extending service life compared to mechanical relay modules.
4. Industrial Robotics: A leading robotics manufacturer used ABB 3BSE069055R1 DO828 to control the end-effector actuators of industrial robots. The module’s precise switching and compact design fit seamlessly into the robot’s control unit, ensuring smooth and accurate motion control for assembly tasks.

Comparisons with Competing Products

Selection Suggestions

1. High-Speed Control Applications: Prioritize ABB 3BSE069055R1 DO828 for projects requiring fast response times (e.g., automotive production, robotics) due to its ≤10μs switching speed and solid-state outputs.
2. Mixed-Device Environments: Choose this module if your system uses diverse actuators or relays (sourcing/sinking types), as its configurable outputs eliminate the need for multiple specialized modules.
3. ABB PLC Ecosystems: Opt for ABB 3BSE069055R1 DO828 if your facility operates ABB AC 800M/AC 500 PLCs to leverage seamless integration and simplified configuration via ABB’s official software.
4. Reliability-Critical Systems: Select this model for industrial processes (e.g., water treatment, power generation) that demand long-term stability, thanks to its high MTBF and comprehensive protection functions.

Precautions

1. Wiring Guidelines: Follow ABB’s wiring specifications for ABB 3BSE069055R1 DO828, ensuring that connected devices do not exceed the module’s voltage and current limits to prevent output channel damage.
2. Power Supply Stability: Use a regulated 24V DC power supply with surge protection to safeguard the module from voltage fluctuations, which can affect switching performance and component longevity.
3. Configuration Best Practices: Confirm the sourcing/sinking configuration of each channel before deployment to avoid mismatches with field devices, which may cause signal failure or equipment damage.
4. Environmental Installation: Mount ABB 3BSE069055R1 DO828 in a well-ventilated, dust-free control cabinet, avoiding direct exposure to moisture, high temperatures, or high-voltage equipment.
5. Authorized Maintenance: Only ABB-certified technicians should perform calibration, firmware updates, or module replacement to ensure the product retains its performance standards and warranty validity.
