ABB 3BSE052604R1

Description

Product Description

Product Parameters

• Brand & Model: ABB, 3BSE052604R1
• Device Type: Universal Digital I/O Module for PLC
• Power Supply: 24V DC, with ±10% voltage tolerance
• Number of Channels: 22 configurable channels (switchable between input and output)
• Signal Type: Differential digital signals (NO/NC configurable)
• Response Time: ≤ 0.6 ms (for both input and output signals)
• Operating Temperature: -40°C to +70°C
• Protection Rating: IP20 (per IEC 60529 standard)
• Communication Interfaces: Profinet, Ethernet/IP, Modbus TCP
• Dimensions (W × D × H): 72 mm × 106 mm × 139 mm
• Weight: 0.28 kg
• Compatible PLC Systems: ABB AC 800M, ABB AC 800XA, ABB Freelance 4000
• Maximum Contact Current: 2.3A per channel
• Certifications: CE, UL, CSA, ATEX, IECEx

Advantages and Features

1. Flexible 22-Channel Configuration: Each channel of ABB 3BSE052604R1 can be freely switched between input and output modes, allowing the module to adapt to diverse scenarios—from monitoring temperature, pressure, and proximity sensors to controlling valves, relays, and small motors—without requiring additional I/O hardware.
2. Ultra-Fast Signal Response: With a response time of ≤ 0.6 ms, ABB 3BSE052604R1 ensures real-time transmission and processing of industrial signals, which is critical for time-sensitive processes such as high-speed assembly lines, precision machining, and automated sorting systems.
3. Superior Environmental Resilience: Equipped with EMC Class 3 electromagnetic interference protection and a wide operating temperature range, the module maintains stable performance in harsh settings like chemical plants, outdoor power stations, and high-vibration manufacturing workshops.
4. Seamless Cross-Platform Integration: Support for three mainstream industrial protocols enables ABB 3BSE052604R1 to connect smoothly with various PLC controllers, HMIs, and upper-level management systems, eliminating compatibility barriers in complex automation networks.
5. Cost-Efficient and Low-Maintenance: The compact design reduces electrical cabinet space occupation, while clear channel labeling and plug-and-play functionality simplify installation and troubleshooting. Its robust construction also lowers long-term maintenance costs and extends service intervals.

Application Cases in Industry

• Energy Sector: ABB 3BSE052604R1 is widely used in hydropower stations, thermal power plants, and solar energy farms to monitor and control circuit breakers, transformer cooling systems, and auxiliary equipment (pumps, fans). It ensures stable energy generation and efficient power distribution.
• Automotive Manufacturing: In automotive stamping and assembly lines, the module connects robotic arms, conveyor belt position sensors, and quality inspection devices. It coordinates sequential production operations, improving assembly precision and overall production efficiency.
• Chemical Industry: At chemical processing plants, ABB 3BSE052604R1 controls the on/off of reaction vessel valves, monitors gas leakage detectors, and regulates mixing equipment, adhering to strict safety standards to prevent operational hazards.
• Food & Beverage Industry: In automated food production lines, the module manages filling machines, packaging equipment, and temperature-controlled storage units. It ensures compliance with food safety regulations and maintains consistent product quality.

Comparison with Competitors

Selection Suggestions

1. Match Channel Requirements: ABB 3BSE052604R1 is ideal for medium-scale projects requiring 18–22 flexible channels, such as integrated production lines and regional control systems, eliminating the need for multiple fixed input/output modules.
2. Confirm System Compatibility: Verify that your existing PLC system is ABB AC 800M, AC 800XA, or Freelance 4000 to ensure plug-and-play integration with ABB 3BSE052604R1 and avoid communication compatibility issues.
3. Evaluate Operating Conditions: If the module will be deployed in extreme temperatures, high-vibration areas, or environments with strong electromagnetic interference, its rugged design makes it a more reliable choice than competitors with narrower operating ranges.
4. Consider Long-Term Scalability: The 22 configurable channels and multi-protocol support of ABB 3BSE052604R1 allow for easy system expansion, such as adding new field devices or integrating with IIoT platforms, making it a cost-effective long-term investment.

Precautions

1. Installation: When installing ABB 3BSE052604R1, keep it away from high-power equipment (e.g., frequency converters, motors) to avoid electromagnetic interference. Use only genuine ABB cables and terminals to ensure stable signal transmission and prevent connection failures.
2. Configuration: Utilize ABB’s official Control Builder M software for channel configuration (input/output mode switching). Incorrect configuration may cause device damage or system malfunctions.
3. Maintenance: Regularly inspect the module’s connection terminals for looseness or corrosion, and clean the surface with a dry, soft brush. Avoid using water or chemical cleaners to protect internal components.
4. Storage: Prior to installation, store ABB 3BSE052604R1 in its original packaging in an environment with a temperature of 5°C to 35°C and relative humidity ≤ 60%. Protect it from mechanical impact, moisture, and direct sunlight.
5. Certification Compliance: For use in explosive environments (e.g., oil refineries, chemical plants), confirm that the module holds valid ATEX and IECEx certifications to meet on-site safety regulations.
